SOtM tX-USBx10G Installation Manual

tX-USBx10G
Precaution
Please read these instructions carefully before use.
Do not attempt to disassemble or modify the product.
n
Keep the product away from external shocks or vibrations.
n
Do not use damaged or peeled cables.
n
Do not use the unit outdoors.
n
Product specifications and features are subject to change without notice.
n
Warranty Information
Free warranty service
n
In the case that a defect is found which is caused by a design or the production flaw while using the device properly, the manufacturer is
l
responsible for the faulty product. There is free warranty service for 1 year from the date of purchase.
Even during the warranty service period, malfunction or damage of products caused by inevitable incidents such as a natural disaster is not subject
l
to the free warranty service.
Charged Warranty service
n
The free warranty service period is expired.
l
Malfunction of the product is caused by the user.
l
Malfunction of the product is caused by incidents.
l
Malfunction of the product is caused by a natural disaster such as an earthquake, flood, lightning, etc.
l
In the case of a charged warranty service, the customer should cover the shipping costs.
l
n Examples of a user caused malfunction
Attempts to disassemble or modify the device.
l
Not following the instructions in this manual.
l
Please read these operating instructions and the Q&A board on our website carefully before asking for the warranty service.
n
Supplied Components
tX-USBx10G with slim size bracket
n
Standard size bracket
n
tX-USBx10G installation guide
n
Specifications
PCI express USB interface chip set
n
USB 3.2 Gen 2 x1 (Previously USB 3.1 Gen 2) host controller
-
Support SS(
- Up to 10 Gbps
PCIe Gen 3 x2 interface
-
User interface LED
n
Located underneath of USB type A connector
Green LED : Internal power on indicator
-
Red LED : USB type A port power on indicator
-
Amber LED : External power input indicator
-
Blue LED : Operating indicator
-
Internal SATA power input
n
Input voltage : +12.0V(+0.5V, -0.5V)
-
Input current : 3A
-
15pin SATA power connector
-
External power input
n
Input voltage : +7V ~ +9Vdc
-
Input current : 5A max
-
5.5mm OD, 2.1mm ID DC adaptor jack
-
USB Type A port output power
n
Output voltage : +5.0V(+0.5V, -0.25V)
-
Over current protection : 3.0A(Tolerance 20%)
-
Recommend output current : 2.0A >
-
Power on/off switch : S401
-
USB Type E port output power
n
Output voltage : +5.0V(+0.5V, -0.25V)
-
installation guide
), HS( ), FS( ), LS(
480 Mbps 12 Mbps 1.5 Mbps
Rev1.0
Over current protection : 2.0A(Tolerance 20%)
-
Recommend output current : 1.5A >
-
) Power on/off jumper : J402(Jumper on : off)
-
External clock jumper
n
Internal clock setting
-
Install two jumpers on J107
Uninstall jumper on J106
External clock setting
-
Uninstall two jumpers on J107
Install jumper on J106
Operating environment
n
Operating temperature : 0°C ~ 30°C
-
Storage temperature : -10°C ~ 50°C
-
Operating & storage humidity : 10% ~ 90%
-
OS support
n
Windows 10 or higher version
-
Linux kernel 5.xx or higher version
-
This operating instruction is available through the tX-USBx10G
product page, www.sotm-audio.com.
