SAUTHON easy TOKYO XV611A Technical Manual page 3

Advertisement

2
F29
5
F00
3
C11
LU
LU
LU
x4
6
F29
90°
90°
Avant de passer à l'étape suivante, vérifiez que le tiroir com-
porte bien 4 angles droits.
Before the next stage, check that the drawer has 4 right
angles.
4
MQ
MQ
LU
C12
LU
MQ
x4
7
90°
90°
LW
x4
F00
F29
Important : La fixation des coins plastiques permet le
bon maintien du tiroir !
Important : Fastening the plastic corners allows for
the proper holding of the drawer !
