OWNER'S MANUAL
INSTALLATION INSTRUCTIONS
MIRADA™ LIGHT FRAME KIT
MOUNTING INSTRUCTIONS FOR 24V DC LIGHT FRAME
LK0480 / LK0640 / LK0760
Includes:
•
Light Frame
•
115 V Connection set for one LED light frame - ON/OFF/dimming operation with transformer/dimmer/
switch (CK0400)
250 West Laurel Street, Colton CA 92324 • WWW.WILLIAMSCOMFORT.COM • 1-888-444-1212
VISITEZ NOTRE SITE WEB POUR LA VERSION FRANÇAISE DE CE MANUEL
VISITE NUESTRA PÁGINA WEB PARA LA VERSIÓN EN ESPAÑOL DE ESTE MANUAL
https://www.williamscomfort.com/product/mirada-infrared-heated-mirror/
Advertisement
Table of Contents
Summary of Contents for Williams MIRADA LK0480
- Page 1 OWNER’S MANUAL VISITEZ NOTRE SITE WEB POUR LA VERSION FRANÇAISE DE CE MANUEL INSTALLATION INSTRUCTIONS VISITE NUESTRA PÁGINA WEB PARA LA VERSIÓN EN ESPAÑOL DE ESTE MANUAL https://www.williamscomfort.com/product/mirada-infrared-heated-mirror/ MIRADA™ LIGHT FRAME KIT MOUNTING INSTRUCTIONS FOR 24V DC LIGHT FRAME LK0480 / LK0640 / LK0760 Includes: •...
- Page 2 SAFETY AND GENERAL INFORMATION • Read all instruction before use. • In the event of improper use or use not in accordance with the intended purpose, the manufacturer accepts no responsibility for safety or functionality. • All electrical connections must be made by a trained and certified electrician •...
- Page 3 MOUNTING OF THE LIGHT FRAME KIT The light kit is attached to the ceiling or wall OPERATING UNIT TRANSFORMER TF0400 before the mirror is mounted. To do this, the holes for (ON/OFF /DIMM operation via voltage sink) heater installation must first be drilled in the ceiling/wall. The positions of the drill holes can be found in the operating instructions for the Mirada Heated Mirror.
- Page 4 MOUNTING OF THE LIGHT FRAME KIT Attach the light kit (as shown) to the ceiling or wall according to option A or option B using the adhesive strips and connect it to the main voltage. If the light kit is positioned differently, please check the maximum length of the socket cable (secondary side) before- hand and observe the (hatched) areas must be observed! Attention: The light kit must not be fixed within the hatched area! Temperature...
- Page 5 MOUNTING AND CONNECTION OF THE LIGHT FRAME KIT Caution: The light kit must be disconnected from the power supply again for the next steps. 90° Magnets can be pivoted on this side. Turn 2x/3x swiveling magnets and place/ position frame on heater. Magnets are in fixed position on this side.
- Page 6 www.williamscomfort.com | 888-444-1212 | 250 West Laurel Street, Colton CA 92324 USA Subject to change without notice | © 2023 D113412_A 1/24...
