Geevon W22146 User Manual

GEEVON COLOR WEATHER STATION
Item No.W22146
User Manual
Thank you for purchasing W22146 Color Weather Station
Please take a moment to read this guide and store it for future reference.
Features & Benefits:
DISPLAY UNIT & OUTDOOR SENSOR
1. SNOOZE and light
2. Alarm
3. SNOOZE
4. Calendar
5. Weekday
6. Time display
7. Low battery display
8. Indoor temperature
9. Indoor humidity
10. Channel 1 temperature and humidity
11. Set button
12. Alarm button
13. Max/min button
14. CH button
15. Down button
16. Up button
17. Pressure display
18. Weather forecast
19. Outdoor signal icon
20. Channel 3 temperature
21. Channel 3 humidity
22. Channel 2 humidity
23. Wall mount hole
24. Compartment 3xAAA batteries (batteries not included)
25. USB charging port
26. External power supply socket
27. SENSOR temperature and humidity
28. Wireless signal indicator
29. Hang hole
30. Channel for outdoor sensor
31. Compartment 2xAAA batteries (batteries not included)
Main features:
• 7 function keys: , ,
• Time display 12/24Hr format optional;
• Double alarm and snooze function;
• Low battery detection function;
• 3 channels of outdoor temperature and humidity are
displayed on the same screen;
•Comfort display;
• Indoor temperature range -9.9℃～+50℃ (14.2℉～122.0℉),
resolution 0.1℃/℉
• Outdoor temperature range -25℃～+50℃ (-13℉～122.0℉),
resolution 0.1℃/℉
• Humidity range 20~95%, resolution 1%;
• Air pressure range: 850hPa ~ 1100hPa;
• 6-level weather forecast pattern display: sunny, cloudy,
cloudy, light rain and heavy rain and snow;
• ICE Alert;
• The pressure unit mb/hPa or inHg is optional;
• Backlight function, 5 levels backlight;
Setting up power supply Base device
1. Insert the DC connector into the connection socket of the
base station.
2. Insert the mains plug into the power outlet.
3. The device is energized directly.
NOTICE! For permanent operation, mains power supply
is recommended. Alternatively a power supply with
batteries is also possible, to keep the time setting in case
of power failure.
Proceed as follows: Remove the battery compartment cover.
Insert the batteries into the battery compartment. Ensure that
the battery polarity (+/-) is correct. Replace the battery
compartment cover.
Remote sensor:
1. Remove the battery compartment cover.
2. Insert the batteries into the battery compartment. Ensure
that the battery polarity (+/-) is correct.
3. Set the channel selector switch to the desired channel.
4. Replace the battery compartment cover.
NOTICE! This weather station can be operated with one
or more remote sensors. Each remote sensor being
connected must be operated on a different channel. If
only one remote sensor is connected, it should be
operated on channel 1.
Time setting
1.In the standard mode, press and hold the
seconds to enter the time setting mode, and the set item will
flash and display. The sequence is as follows:
, , , ,SNZ/LIGHT;
for approx. 3
