Summary of Contents for Grundig GD-KB-AP1420P
-
Page 2: Table Of Contents
CONTENT 1 Getting Started ..........................1 1.1 Introduction ........................1 1.2 Activate Your Device ......................1 1.3 Login ........................... 2 2 Keyboard Operation .......................... 3 MAG by RS-422 ........................3 DVR by RS-485 ........................5 To Analog Device ........................ 6 Dome by RS-485 ...................... -
Page 3: Getting Started
1 Getting Started 1.1 Introduction Thank you for purchasing a GRUNDIG product. Before installing or connecting the product, please read first the documents: - Legal Disclaimer - Safety Instructions - Installation Manual for the respective product model Further information about the product like Data Sheets, CE Documents, etc. can be found on the web page www.grundig-security.com. -
Page 4: Login
Warning! STRONG PASSWORD RECOMMENDED–We highly recommend that you create a strong password of your own choosing (8 to 16 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend that you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product. -
Page 5: Keyboard Operation
2 Keyboard Operation This section describes how to control devices using the keyboard. On the keyboard, press the MODE button on the panel to enter the operation for different devices. See the following table for the description of each keyboard mode. Table 2-1 Description of Keyboard Mode Operation Mode Description... - Page 6 See the following figure: See the following figure as an example for the network cable (568B). The pin 3 and pin 4 are colored in green-white and blue. English 4...
-
Page 7: Dvr By Rs-485
Note: ⚫ You can also press the Num + CAM buttons to select the input channel, and operate the PTZ control. ⚫ For the initial use of MAG, you must use the configuration kits software to configure the input/output channel ID of the MAG. Please see the related user manual for details. The input/output channel ID is used for switching on the video wall or PTZ control during keyboard operation. -
Page 8: To Analog Device
Note: The baud rate, protocol and other parameters of RS-485 of the keyboard must be configured to 9600, 8, 1, and none parity. To Analog Device Dome by RS-485 The keyboard can connect with the analog dome or PTZ unit via RS-485 serial port, and realize PTZ control. -
Page 9: Dome By Rs-232
SITE: 3 Note: The address, baud rate, protocol, and other parameters of RS-485 must be configured the same with those of the dome. Dome by RS-232 The keyboard can connect with the analog dome via RS-232 serial port, and control the dome via VISCA protocol. -
Page 10: Analog Matrix By Rs-232
SITE: 3 Analog Matrix by RS-232 RS232 DEV: 1 MON: 2 CAM: 1 English 8... -
Page 11: Shortcut Operation
Shortcut Operation The device control via keyboard can be realized by shortcut operation. English 9... -
Page 12: System Menu Configuration
3 System Menu Configuration On the main menu after login, you can select System to check the version, and configure the system configuration, including network, user, RS-485, RS-422, hardware, time and maintenance. Version Select Version to check the version information of the keyboard, including the firmware version, panel version, hardware version, core version, and serial No. -
Page 13: Serial Port Settings
Serial Port Settings You can connect analog dome or DVR with the keyboard via RS-485 serial port, MVC/MAG via RS- 422 serial port and analog matrix via RS-232 serial port. Select Serial Port to enter the settings. You can configure the address bit (RS-485 only), baud rate, data bit, protocol, stop bit, parity, and copy all settings. -
Page 14: Time Settings
Time Settings Select Time to enter the system time settings interface. You can set the value of year, month, date, time format, hour, minute and second. Click OK button or the central button of joystick to save the settings. Maintenance Select Maintenance to enter the system maintenance settings interface. - Page 15 English 13...
