Instruction Manual for
Broadway Thin Bezel Series Fixed Frame
MODELS: BT169***, BT1610***, BT239***
Thank you for purchasing a Severtson projection screen. Before use, please read the instructions
carefully. After installation, store the instructions for future reference.
Rev 220803
Advertisement
Summary of Contents for Severtson Broadway BT169 Series
- Page 1 Instruction Manual for Broadway Thin Bezel Series Fixed Frame MODELS: BT169***, BT1610***, BT239*** Thank you for purchasing a Severtson projection screen. Before use, please read the instructions carefully. After installation, store the instructions for future reference. Rev 220803...
- Page 2 Instruction Manual for Broadway Thin Bezel Series Fixed Frame Overview Parts Included...
-
Page 3: Installation Instructions
Instruction Manual for Broadway Thin Bezel Series Fixed Frame Installation Instructions Take out all the parts from the packaging and verify that all the parts have been included. Then follow the steps below to install the screen. 1. Locate top, bottom, and side inner frame pieces (the bare aluminum pieces with no velvet) (Fig. - Page 4 Instruction Manual for Broadway Thin Bezel Series Fixed Frame each frame piece (Fig. 2.1). Slide one large and one small corner bracket, and one square support bar nut for each provided support bar into the bracket slots at each angled end of the side frame rails (Fig.
- Page 5 Instruction Manual for Broadway Thin Bezel Series Fixed Frame [Figure 3.1] 4. Move the square support bar nuts along the frame to evenly space the support bars along the width of the screen (Fig. 4.1). Screw the support bar brackets to each end of the support bars, and attach them to the support bar nuts in the frame.
- Page 6 Instruction Manual for Broadway Thin Bezel Series Fixed Frame upper/lower rods into the upper and lower pockets of the screen material (Fig. 6.3). Ensure the rubber caps on the top and bottom rods are toward the corners of the screen. Note 6.2: Sometimes it can be difficult to slide the longer rods completely through the pockets.
- Page 7 Instruction Manual for Broadway Thin Bezel Series Fixed Frame corner notches, work toward the center of the frame until the entire screen is tensioned and secured evenly to the frame at all of the plastic lugs (Fig. 7.3). [Figure 7.1] [Figure 7.2] [Figure 7.3] 8.
- Page 8 Instruction Manual for Broadway Thin Bezel Series Fixed Frame [Figure 8.1] Note 8.1: If some of the frame bezel pieces get attached incorrectly please see Appendix B: Bezel Removal Instructions in this guide for steps to remove the misaligned pieces before attempting to attach them again.
- Page 9 Instruction Manual for Broadway Thin Bezel Series Fixed Frame [Figure 9.1] [Figure 9.2]...
- Page 10 Instruction Manual for Broadway Thin Bezel Series Fixed Frame Table 9.1: Horizontal Bracket Spacing Distance Frame Width (B) 16” Stud Bracket Spacing (C) 24” Stud Bracket Spacing (C) Less than 90” 48” 48” 90” to 110” 64” 72” 110” to 135” 80”...
- Page 11 Instruction Manual for Broadway Thin Bezel Series Fixed Frame [Figure 11.1] 12. Hang the screen onto the upper brackets, fitting the upper edge of the bracket into the correct track on the frame (Fig. 12.1). Then let the screen hang vertically. The back of the lower frame rail should rest against the lower brackets.
- Page 12 Instruction Manual for Broadway Thin Bezel Series Fixed Frame Warnings 1. The frame is made with lightweight aluminum. Please handle with care. 2. Make sure the fasteners used are firmly secured to the wall to avoid any damage. 3. When installing the screen material onto the frame, make sure it is facing forward (viewing side toward the projector).
