Yeastar TG100 - GSM Gateway

Quick Guide

Version 1.000 (07. December 2022)

info@avt-nbg.de

www.avt-nbg.de

Table of Contents

Need help?

Do you have a question about the Yeastar TG100 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVT Yeastar TG100

Page 1 Yeastar TG100 - GSM Gateway Quick Guide Version 1.000 (07. December 2022) info@avt-nbg.de www.avt-nbg.de © AVT Audio Video Technologies GmbH...
Page 2: Table Of Contents
Content Yeastar TG100 ▪ Configuration ▪ ▪ System Status ▪ MAGIC Telephone Hybrid Configuration ▪ ▪ VoIP Status ▪ Operation Troubleshooting ▪ Support ▪...
Page 3: Yeastar Tg100
Yeastar TG100 Configuration of the Yeastar TG100 ▪ Web GUI ▪ Password LAN settings ▪ GSM port ▪ VoIP account ▪ Call routes ▪ info@avt-nbg.de www.avt-nbg.de © AVT Audio Video Technologies GmbH...
Page 4 Enter the default IP address of ▪ the Yeastar TG100 in a web browser. ▪ IP: 192.168.5.150 ▪ If the connection cannot be established, you need to configure the network card in your PC to be in the same subnet as the Yeastar TG100.
Page 5 It is highly recommended to ▪ change the password after the first login. Click on System on the top ▪ right corner of the Web GUI. On the left, open System ▪ Preferences and select Password Settings. ▪ Enter a new password. Password Settings...
Page 6 Changing the IP address of ▪ the Yeastar TG100 is possible under System > Network Preferences > LAN Settings. Enter IP address parameters ▪ that match your local network. LAN Settings...
Page 7 Manage GSM port and SIM ▪ card under Gateway > Mobile List > Mobile List. Click on the Edit button to ▪ change the parameters of the GSM Port, e.g.: ▪ Audio Gain Rx/Tx SIM Pin Code ▪ Carrier ▪ GSM Port...
Page 8 The Yeastar TG100 has an ▪ integrated SIP-Server. Create a VoIP account or edit ▪ one of the preconfigured accounts under Gateway > VoIP Settings > VoIP Trunk. The MAGIC telephone hybrid ▪ connects to that VoIP account. ▪ Account settings: ▪...
Page 9 Configure the GSM to VoIP routes ▪ under Gateway > Routes Settings > Mobile to IP. ▪ The route defines that an incoming call via GSM is routed directly to the corresponding VoIP account. ▪ Edit the preconfigured route and set the parameters.
Page 10 Configure the VoIP to GSM routes ▪ under Gateway > Routes Settings > IP to Mobile. ▪ The route defines that an incoming call via VoIP is routed directly to the corresponding GSM port. ▪ Edit the preconfigured route and set the parameters.
Page 11: System Status
Yeastar TG100 System Status ▪ GSM / VoIP Status ▪ Network Status info@avt-nbg.de www.avt-nbg.de © AVT Audio Video Technologies GmbH...
Page 12 Open Status > System Status > ▪ Trunk Status. Find the status of the GSM port at ▪ the top. SIGNAL: GSM signal strength. ▪ ▪ Red / no bar: No signal. ▪ Green / 1 - 4 bars: Poor - excellent signal ▪...
Page 13 Open Status > System ▪ Status > Network Status. The IP parameters currently ▪ used by the TG100 are displayed. Network Status...
Page 14: Magic Telephone Hybrid
MAGIC Telephone Hybrid Configuration of a MAGIC telephone hybrid ▪ The example is based on MAGIC TH2plus. info@avt-nbg.de www.avt-nbg.de © AVT Audio Video Technologies GmbH...
Page 15 Enter the IP address of the ▪ Yeastar TG100 as SIP-Server. ▪ Enter the account created on the Yeastar TG100 in the column User Name. ▪ Enter the password configured on the Yeastar TG100 in the column Password.
Page 16: Voip Status
SIP USER: The SIP account used for registering. MAIN SIP SERVER: The ▪ registration status of the line on the SIP server of the Yeastar TG100. ▪ REGISTRATION DONE SUCCESSFULLY: The VoIP line is registered. OTHER: The line could not ▪...
Page 17: Operation
Operation Yeastar TG100 GSM Gateway and MAGIC TH2plus info@avt-nbg.de www.avt-nbg.de © AVT Audio Video Technologies GmbH...
Page 18 GSM port: SIP-Account: Nr.: +49 151 200 300 Nr.: 20001 VoIP Mobile phone: +49 151 555 123 To call the mobile phone, dial +49 151 555 123. To call the TH2plus, dial +49 151 200 300. Operation...
Page 20 If the Yeastar TG100 does not ▪ respond to SIP messages of the telephone hybrid, check the Blacklist Rules under System > Security Center > Security Center. Press IP Blacklist to check ▪ the Blacklist Rules and the status. IP Blacklist (1)
Page 21 Blacklists at the top if the telephone hybrids is incorrectly blocked. IP BLACKLIST: IP addresses ▪ blocked by the Yeastar TG100 based on the blacklist rules are listed here. ▪ Check whether the IP address of the telephone hybrid is listed here.
Page 22: Support
Support Hotline Support-Portal Support E-Mail +49 911 2571 110 avt-nbg.zammad.com support@avt-nbg.de Support info@avt-nbg.de www.avt-nbg.de...
