H3 Group LCPSD-HV / EMPHV-SD Series Installation Instructions

H3 Group Inc. 1-800-967 5541
LED Emergency Conversion Power Pack
For Field or Factory Installation
LCPSD-HV / EMPHV-SD SERIES
1.To prevent high voltage from being present on yellow & orange output leads prior to installation,
converter connector must be open. Do not join converter connector until installation is complete and AC
power is supplied to the emergency driver.
2.This product is for use with an LED lighting load and supplies up to 7W / 12W / 25W constant power
voltage between 0 VDC and 5 20 0 VDC in emergency mode for a minimum of 90 minutes.
3.Make sure all connections are in accordance with the National Electrical Code or Canadian Electrical Code
and any local regulations.
converter connector of the emergency driver before servicing.
5.This emergency driver is for factory installation and
6.This product is suitable for use in damp locations where the ambient temperature is 5ºC minimum, +50ºC
maximum. Product is not suitable for heated air outlets and wet or hazardous locations.
8.Do not install near gas or electric heaters,Do not use outdoors.
9.Use with grounded, UL Listed, damp location rated fixtures and
10.The Driver is intended for ordinary locations and for permanent
emergency luminaires.
11.
Do not attempt to service the battery. It is sealed unit and the battery is not replaceable.
Contact the manufacturer for information on service.
12.The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition
13.Do not use this product for other than intended use.
14.Servicing should be performed by qualified service personnel.
15.Only apply to LED Driver with the output current less than 3A.
16. Equipment should be mounted in locations and at heights where it
will not be subjected to tampering by unauthorized personnel.
NOTICE:
The LCP/EMP/LEDRV Series LED Emergency Driver Power Packs are rated for operation with an internal
pack ambient between 5°C to 50°C. To meet this rating, warranty condition and ensure optimum
component life, it is recommended that the pack be mounted remotely from the light fixture or high
ambient temperatures. Where it is necessary to mount directly to the light fixture, the installer
should verify that the stabilized light fixture surface temperature rise does not contribute radiant
heat directly to the pack surface; resulting in the pack internal ambient temperature exceeding the
max. 50°C rating. Locate or space the pack as necessary.
INPUT
Output Voltage
LED Driver
Input Voltage Input Power
output current
LCPSD7HV
120-277VAC
3A max. 50~200VDC
4W max.
EMP7HV-SD 50/60Hz
LCPSD12HV
120-277VAC
3A max. 50~200VDC
5W max.
EMP12HV-SD 50/60Hz
120-277VAC
LCPSD25HV
3A max. 50~200VDC
6W max.
50/60Hz
EMP25HV-SD
(See electrical data table)
field Installation .
case should be grounding.
installation into one or more Listed
Contains LiFePO4
Rechargeable Battery.
Must be recycled or
disposed of properly.
OUTPUT
Emergency
Battery
Output Output
Operation
Range Current
Power
0.14A(@50Vdc) ~
LiFePO battery
4
7W 90 Minutes
0.035A(@200Vdc) 6.4V 3200mAH
0.24A(@50Vdc) ~
LiFePO battery
4
12W 90 Minutes
0.06A(@200Vdc)
9.6V 3200mAH
0.5A(@50Vdc) ~
LiFePO battery
4
25W 90 Minutes
0.125A(@200Vdc)
19.2V 3200mAH
Page 1 of 4

Verify LED Luminaire Compatibility

is eligible for field installation.
1. Ensure the LED load's rated power is greater than or equal to the power output of this emergency LED
driver. This is to ensure that this emergency product will not produce more power than the LED load can
handle, thus ensuring that the LED load will not be damaged when the system is in the emergency mode.
2. Verify that the forward voltage of the luminaire's LED array is within the limits of this emergency LED
voltage of the LED array is commonly designated as Vf and should be found on the
driver. The forward
with output
luminaire markings, in the luminaire
a voltage meter, it may be possible to directly measure the
from the AC driver.
3. Ensure the output current of the LED driver does not exceed 3Amps.This is the current into
doing the following:
be biven in lumens per watt (lm/w).
b.
load. In many cases the actual lumen output in emergency mode will be greater than this
calculation gives, however it will provide a good estimate for beginning the lighting design of the system.
C. Using the results of this calculation and industry standard lighting design tools, calculate the
a nticipated illumination levels in the path of egress.
Lumens In Emergency Mode = Lumens per Watt of Fixture * Output Power E
(Lumens)
________________
NOTE: This product has been designed to reliably interface with a wide selection of LED loads. . However,
compatibility cannot be guaranteed with all current
of. the end-use system is suggested. Please contact the factory with any questions.
NOTE: After installation, it will be necessary to measure the egress lighting illumination levels to ensure it
complies with national, state, and local code requirements.

Installation

Installation of this emergency LED driver will vary based on the luminaire type, however, generally
follow these steps:
STEP 1 INSTALLING THE EMERGENCY DRIVER
> Disconnect AC power from the LED luminaire.
Max. mounting > Mount the emergency LED driver by the mounting tabs using the supplied screws. The luminaire's
height
installaion instructions may provide guidance on the recommended mounting location.
The emergency driver with cable conduit is suitable for remote mounting from the luminaire;
>
21 Feet
the emergency driver without cable conduit is not suitable for remote mounting.
(6.4m)
23 Feet If used in conjunction with an AC driver, this distance is up to half the distance the AC driver manufacturer
(7.0m)
recommends remote mounting the AC driver from the LED Load. If used without an AC driver, consult
36 Feet
factory for remote mounting distances .
(11.0m)
forward voltage is within the limits of this product. Using
voltage across the LED arrays when operating
= (lm/W) *
________________
and future LED systems. Compatibility testing
Make sure the necessary branch circuit wiring is available. An unswitched
source of power is required. The emergency driver must be fed from the same
branch circuit as
Page 2 of 4
the blue wire.
mergency LED driver
(W)
