.edge
Spare Parts
Accessories
Version: 1.0.13/1
Part Number
.edge_144x144
.edge_288x288
.edge_576x576
.edge_1152x1152
*The number of crosspoints is specified for SD and HD operation (at 25G). Each bundle is a
complete multi-frame system, with a HOME server cluster. The HOME cluster license supports up
to 50 devices.
A00/10-54
A00/40
A00/50-11
PSU sparepart Murata
PSU sparepart 48V DC
A00/10-55
.edge_frame_blind_plat
e_front
Exported on: 22 February, 2024
Description
.edge Bundle 144x144*
Includes: 6 x .edge_gateway + 12
x .edge_sdi + 2 x .edge_frames (ac
or dc) + 1 x HOME cluster license
+ 3 x Dell R340 servers.
.edge Bundle 288x288*
Includes: 12 x .edge_gateway + 24
x .edge_sdi + 3 x .edge frames (ac
or dc) + 1 x HOME cluster license
+ 3 x Dell R340 servers.
.edge Bundle 576x576*
Includes: 24 x .edge_gateway + 48
x .edge_sdi + 6 x .edge_frames (ac
or dc) + 1 x HOME cluster license
+ 3 x Dell R340 servers.
.edge Bundle 1152x1152*
Includes: 48 x .edge_gateway + 96
x .edge_sdi + 12 x .edge_frames
(ac or dc) + 1 x HOME cluster
license + 3 x Dell R340 servers.
1 x .edge frame (fitted with
removable fan tray + blanking
panels).
1 x .edge processing blade
(hardware only; no software
licenses).
1 x .edge rear I/O plate.
1 x .edge AC power supply.
1 x .edge DC power supply.
1 x .edge fan tray.
1 x blanking panel for the front
(processing blade) slots.
Notes
Spare part only.
New systems must be ordered
using the frame variants listed
above (to ensure they include
PSUs and a rack-mounting kit).
Spare part only.
To expand a partially-fitted frame,
use .edge_gateway.
A frame must be fitted with two
identical power supplies (as
described earlier).
Spare part only.
