Magna MANO ULTRA MK3 Hardware Manual

Hide thumbs

Advertisement

Table of Contents

MANO ULTRA MK3
MUSIC PLAYER
High-End music
streaming for
HARDWARE
S/PDIF & I2S
DAC's
MANUAL
"Mano Music Streamer for high-end streaming developed to
connect via I2S to Audio-GD & Holo Audio or other I2 LVDS
compatible DAC's"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MANO ULTRA MK3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Magna MANO ULTRA MK3

  • Page 1 MANO ULTRA MK3 MUSIC PLAYER High-End music streaming for HARDWARE S/PDIF & I2S DAC’s MANUAL “Mano Music Streamer for high-end streaming developed to connect via I2S to Audio-GD & Holo Audio or other I2 LVDS compatible DAC’s”...
  • Page 2 Whilst every care is taken to ensure that the information in this document is correct, no liability can be accepted by Magna Hifi. For loss, damage or injury caused by any errors in, or omissions from, the information given.
  • Page 3 Table of Contents Introduction ....................................... 3 Front- & back panel connections ................................4 Install and 1 time operation.................................. 5 Replace micro SD-card .................................... 6 Replace Farad Super3 fuse ..................................6 Page 2...
  • Page 4 Introduction The Mano ULTRA mk3 music streamer is a open hardware device which supports both S/PDIF or AES/EBU and HDMI I2S (Holo Audio or PS-Audio Compatible) digital audio outputs. Several software solutions are available: • Logitech Media Server solution (piCore) •...
  • Page 5 Front- & back panel connections Mano ULTRA mk3 Power Button Blue LED = ON Farad PSU Power LED Blue = Normal operation Power Button ON/OFF with LED (BLUE) Indication (ON) LAN = Ethernet Connection USB = USB peripherals (Not for Audio purposes)
  • Page 6 When connecting your Mano for first time, please follow these instructions for proper setup. 1. Connect an Ethernet LAN cable from the Mano to your LAN/router.* 2. Connect DC cable from the Farad Super3 to the Mano ULTRA mk3 DC input 3. Connect main power cable to the Farad Super3 4.
  • Page 7 Replace micro SD-card The micro-SD card can be found at the bottom. (hole underneath Mano ULTRA mk3 unit) Turn off Mano ULTRA mk3 (disconnect DC cable) while replacing micro-SD Card Replace Farad Super3 fuse Note: The Fuse is located inside the Super3.
