ZORN D plus
The ZORN D plus is made for the wireless handling of your Light
Weight Deflectometer ZFG and serves the generation of com-
plete test reports on your Android or iOS device (from Android
5.1 and iOS 11.0 on).
Before using the ZORN D plus, also read the operating instruc-
tions for your Light Weight Deflectometer.
Technical Data
•
Dimensions: approx. 100 x 50 x 10 mm
•
Weight: approx. 100 g
•
Connection sensor: 6,35 mm stereo audio jack
•
Connection mobile device: Bluetooth (Low Energy)
•
Energy supply: Lithium Polymer Batterie (rechargeable)
•
Control Indicator: two LEDs
•
Languages: German/English
Read the operating instructions carefully before using the ZORN D plus!
Latest version of the
D plus app loaded?
