8 7
D
BA
ROUTE CAMERA CABLE
7
BEHIND SHOWER
C
ROUTED THROUGH
7
FLOOR IN THIS AREA
1 2
CABLE ASM-MONITOR
B
8 423F ROUTING.
7 423A ROUTING.
6 REMOVE ANTENNA FROM CHASSIS CAB ROOF AND RELOCATE
TO MAIN ROOF. USE ANTENNA EXTENSION BETWEEN CHASSIS
ANTENNA CABLE AND ANTENNA WHEN RELOCATING ANTENNA.
SECURE BOTH ENDS OF ANTENNA EXTENSION WITH TAPE.
5 ROUTE CAMERA CABLE, 6-PIN HSG, AND FUSE THROUGH
HOLE IN CABINET. CONNECT TO MONITOR POWER SUPPLY.
A
4 ROUTE CAMERA WIRE ABOVE HEADLINER.
3 ROUTE CAMERA CABLE UP B-PILLAR.
2 ROUTE REAR MONITOR CAMERA CABLE ALONG FRAME RAIL
WITH WIRE ASM-CHASSIS. SEE WIRING INSTL-CHASSIS
FOR ADDITIONL INFORMATION.
1 SEE WIRE ASM-CHASSIS FOR ADDDITIONAL INFORMATION.
NOTES:
8 7
6 5
ROUTE CAMERA CABLE
8
BEHIND SHOWER
ROUTED THROUGH
8
FLOOR IN THIS AREA
3
CIRCUITS
1
TR,UR,KE
ROUTE CAMERA
CABLE BELOW
BEDBOARD
6 5
4 3
ANTENNA-
SATELLITE RADIO
(CHASSIS SUPPLIED)
PLATE-SATELLITE PREP
177256-06-CHT 6
177256-06-CHT
SCREW
G11-08-08U (4)
EXTENSION-ANTENNA,
SAT RADIO
6
181908-04-000
MONITOR-POWER SUPPLY
AA
DETAIL
WIRE ASM-
CHASSIS
MONITOR-WINDSHIELD MOUNT
000026027 / 315477-01-000 4
FOR ELECTRICAL
TORQUE
SPECIFICATIONS X-X
SEE DWG NO.
128783-01-000
4 3
2 1
MONITOR-POWER SUPPLY
SCREW
G67-08-12U (2)
5
AA
DETAIL
265 CODES/STANDARDS-CSA/CMVSS
1B1 CODES/STANDARDS USA
1B1 265
