- Page 1 Atim Cloud Wireless ® Current temperature sensor User guide Models concerned : ACW/LW8-CTS...
-
Page 2: Table Of Contents
Table of contentss THIS USER GUIDE APPLIES TO THE FOLLOWING REFERENCES ..........4 VERSION HISTORY OF THIS DOCUMENT ................4 DISCLAIMER ........................5 TRADEMARKS AND COPYRIGHTS ..................5 DECLARATION OF CONFORMITY ..................5 ENVIRONMENTAL RECOMMENDATIONS ................6 ................................6 NVIRONMENT ..................................6 ADIO TECHNICAL SPECIFICATIONS ..................... - Page 3 TECHNICAL SUPPORT ......................34 ATIM_ACW-CTS_UG_EN_V1.1...
-
Page 4: This User Guide Applies To The Following References
This user guide applies to the following references Product version Product references (Visible on product label) LoRaWAN ACW/LW8-CTS Version history of this document Software version Version Date Description Author concerned /Revision 07/12/2023 Correction of exemple frame errors V1.0.7 / A1... -
Page 5: Disclaimer
ATIM Sarl in France. Other trademarks mentioned in this document are the property of their respective owners. Declaration of conformity All ACW (Atim Cloud Wireless®) products comply with the regulatory requirements of R&TTE Directive 1999/5/EC Article 3 : 1 Safety (Article 3.1a of Directive 1999/5/EC) NF EN60950-1 Ed. -
Page 6: Environmental Recommendations
Environmental recommendations a. Environment Observe the product's storage and operating temperature ranges. Failure to do so could disrupt operation and even damage the equipment. This equipment is not designed for outdoor use! Follow the precautions and instructions below to ensure your safety and that of your environment, and to prevent damage to your equipment. -
Page 7: Technical Specifications
Technical specifications a. Product Antennas Integrated (¼ wave) -20°C to +55°C (operating) Temperature -40°C to +70°C (storage) Power None (energy recovery) Weight 130g Frequency 863 – 870 MHz Power 25 mW (14 dBm) Sigfox : NA Radio version LoRaWan : v1.0.4 Sigfox : NA Flow LoRaWAN : 250 bit/s à... -
Page 8: Dimensions
a. Dimensions Dimensions in mm b. Installation CLIC 1. Open the sensor's movable 2. Position the sensor so that the 3. Close the movable jaw again jaw by lifting the tab on the side conductor passes between the until the tongue snaps into place of the sensor. -
Page 9: Identification
c. Identification The product's LoRaWAN identifier is printed on the sensor and in the status bar of the ACW configurator. It can also be read by scanning the QR-Code. For LoRaWAN modems, the communication keys are automatically given by the network (pairing by "Over The Air Activation", or OTAA). -
Page 10: Operating Diagram
For currents above 40ARMS, charging time does not drop below 10mn. In normal operation, if the line current drops below 1ARMS, the energy recovery stage is deactivated. The sensor will continue to operate on stored energy for approximately 30 minutes. When the current in the phase is restored, the time required to restart is given by the graph below : In continuous operation, a line current of amplitude 1.2ARMS is sufficient to supply the transducer with the energy required by the system without using the energy stored in the storage element. - Page 11 ATIM_ACW-CTS_UG_EN_V1.2...
-
Page 12: Acw Configurator
ACW Configurator a. Compatible configurator versions For a sensor with the following application software Use the ACW Configurator version version LoRaWan: V1.0.5 (revision A0) V1.0.4 or higher Download and install the setup software ''setupACW.exe'' at : https://www.atim.com/wp-content/uploads/documentation/CONFIGURATEUR/ACW/configurateur-acw.exe When the ACW Configurator is launched, the waiting window appears on the screen. WARNING Connection to the configurator is only possible in local mode (BLE). -
Page 13: Egreensensor Configuration
b. eGreenSensor configuration Transmission period and frame samples The transmission period corresponds to the time interval between each transmission of a measurement frame. This period can be configured from : 1 min to 255h for a LoRaWan product The default transmission period is 10min. - Page 14 frame n-1, n-2 or n-3 can be sent again in frame n following the new measurement samples (the most recent sample first in the frame and the oldest last). For example, for a history depth of 3, data from the last 2 frames will be sent, in addition to new data, in the next frame.
-
Page 15: Communication Interface
Communication interface The product has two communication interfaces : LoRaWAN The BLE interface can be activated or deactivated using the parameter LoRaWAN interface cannot be disabled. WARNING If the BLE interface is deactivated, it will no longer be possible to connect to the configurator. The configurator can only be accessed via BLE. -
Page 16: Radio Module Configuration
Radio module configuration The product can operate in three different ways For a LoRaWAN product 1. LoRaWAN Class A : The product is modulated in LoRa using the LoRaWAN Class A protocol. This is the product's default mode. This mode requires a private LoRaWAN network (private gateway), or an operated network to view the data sent by the product. -
Page 17: Product Clock
Product clock Each time you connect to the configurator, the product clock is updated (based on the computer clock) and displayed. In addition, an offset in seconds can be applied if required. Product versions When connected to the product, the configurator retrieves all product software versions (product software and radio module software) and the network identifier. -
Page 18: Sensor Configuration
Sensor configuration Here are the configuration parameters available for this sensor Thermocouple activation The ACW-CTS has a connector for type K thermocouples. If such a thermocouple is used, the thermocouple must be activated in the configurator, so that the measurement is carried out, and the temperature is also transmitted via the LoRaWAN interface. By default, the thermocouple is not activated. -
Page 19: Factory Settings
c. Factory settings Radio frame parameters - Radio frame transmission period : 10 minutes - Number of samples : 1 - History depth : 1 General parameters Communication interface: LoRaWAN and BLE Timestamp : disabled Radio parameters: LoRaWAN Class A (for a LoRa product) Sensor parameters Thermocouple Status: Off... -
Page 20: Acw Update
d. ACW update Feature not available in version A0 of the product ! ATIM_ACW-CTS_UG_EN_V1.2... -
Page 21: Uplink Frame Format
UPLINK frame format a. Description Uplink frame Byte 1 Byte 2 . . . Byte n Frame header Frame-specific data Three types of frame can be distinguished : Classic frame ; New generation : Very similar to the old frames, the difference is that you can ... -
Page 22: The Different Types Of Frame
The different types of frame Frame type Data size Frame description 0x00 Reserved 0x01 4 bytes Life frame. 0x02 0 bytes Downlink request for network test. 0x03 Reserved 0x04 Reserved 0x05 1 byte Test frame with counter. 0x06 Variable (Cfg box) Response to configuration frame. 0x07 Variable (Cfg box) Response to a command frame. - Page 23 Byte 2 Channel header Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Reserved = 0 Lane number Measurement type Possible type of measurement Measuremen Unit Data size Data type Descriptions t type Temperature in hundredths of degrees Celsius 2 bytes Resolution: 0.01°C ...
-
Page 24: Measurement Alert Frame
Measurement alert frame Byte 1 - Header Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Timestamp Measuremen Reserved generation t frame= 0 Alert frame (= 0x0d) (Off = 0, On = 1) If Timestamp is enabled, 4 bytes with the Timestamp value will be preceded by the header (byte 1). For each alert channel, a header is inserted as follows : The alert type field identifies whether the alert has exceeded the high threshold, the low threshold or a return between thresholds. -
Page 25: Error And General Alarm Frame
Error and general alarm frame Byte 1 - Header Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Timestamp Measuremen Reserve generation Error frame = 0x0e t frame = 0 d = 0 If Timestamp is enabled, 4 bytes with the Timestamp value will be preceded by the header (byte 1). For each error message, a header is inserted as follows : Byte 2 - Header Error message Bit7... - Page 26 Byte 3 - Header Error message Error code Nature of error Description 0x81 ERR_UNKNOWN Data table is full, impossible to write additional data to 0x82 ERR_BUF_SMALLER ERR_DEPTH_HISTORIC_OUT_OF_RAN History depth is too large or too small for the frame 0x83 Number of samples too large or too small for the frame 0x84 ERR_NB_SAMPLE_OUT_OF_RANGE Number of channels in frame header too large or too small...
-
Page 27: Example Frames
b. Example frames Measurement frame With timestamp disabled, no history and a sample count of 1 (Current and Voltage only) : Byte 0xA0 0x0B 0x0A (new-generation (channel 0, measurement 0x03 0xA8 (channel 0, measurement 0x10 0x38 measurement frame, no type: current) type: voltage) history, 1 sample) In this example, the sensor returns values of 0x03A8 (9.36A) for current and 0x1038 (4.152V) for voltage. - Page 28 With timestamp disabled, no history and a sample count of 1 with thermocouple activated : Byte 0xA0 0x08 0x0B 0x0A (new-generation (channel 0, (channel 0, (channel 0, 0x09 0xE8 0x03 0xA8 0x10 0x38 measurement frame, no measurement type: measurement type: measurement type: history, 1 sample) temperature)
-
Page 29: Measurement Alert Frame
Measurement alert frame If the low threshold (voltage) is exceeded on channel 0, the frame will be : Byte 0x8A 0x8D (Channel 0 low threshold exceeded, voltage 0x0E 0x89 (New generation alert frame) measurement) The sample that triggered the threshold is 0x0E89 (3.721V) ATIM_ACW-CTS_UG_EN_V1.2... -
Page 30: Downlink
Downlink This feature is available on ACW-CTSs meeting the following conditions: Application software LoRaWAN version V1.0.5 Downlinks provide two product functions : Changing parameters Sending commands Downlink operation is explained in document ATIM_ACW-DLConfig_UG_EN_v1.4, relating to version V1.2.0 of the ATIM Downlink Protocol (see this document for all parameters and commands common to all ACW products). -
Page 31: Parameter Modification
a. Parameter modification The configurator can be used to generate downlinks for remote parameterization of a product. These downlinks can then be sent via the Sigfox or LoRaWan network. To do this : Open the product configuration page (a virtual page can be opened if the product is not ... - Page 32 Simply select the parameter(s) you wish to apply via downlink and build the associated downlink. Here, for example, we wish to modify the data logging, communication interface and current measurement offset parameters. The downlink to be sent will then be 94000004003B115E0000 ATIM_ACW-CTS_UG_EN_V1.1...
-
Page 33: Send Downlink Command
b. Send downlink command. Downlink commands are explained in document ATIM_ACW-DLConfig_UG_EN_v1.4, relating to version V1.2.0 of the ATIM Downlink Protocol ATIM_ACW-CTS_UG_EN_V1.1... - Page 34 Technical support Pour tout renseignement ou question technique, nous vous invitons à ouvrir un ticket sur notre For any information or technical question, please open a ticket on our dedicated support web page: Support technique | ATIM ATIM_ACW-CTS_UG_EN_V1.1...
