Toddler Island 2306RS Manual

Kids rocker seesaw
Hide thumbs

Advertisement

Quick Links

Download this manual
FOR AGES:
WEI GHT LIMIT:
3-7
Manual en
español ubicado
en GQAlpha.com
Spanish Manual located
at GQAlpha.com
CUSTOMER SERVICE
GQAlpha.com • CustomerService@GQAlpha.com • 1-800-837-7732 • 12798 Perimeter Rd Ste C 106 Dallas Tx 75228
KIDS ROCKER SEESAW
MODEL# 2306RS
PRODUCT MANUAL - VERSION 5.23.01
TO BUILD:
150
Lbs
68 Kgs
TOOLS NEEDED:
1
X

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2306RS and is the answer not in the manual?

Questions and answers

Related Manuals for Toddler Island 2306RS

Summary of Contents for Toddler Island 2306RS

  • Page 1 KIDS ROCKER SEESAW MODEL# 2306RS PRODUCT MANUAL - VERSION 5.23.01 FOR AGES: WEI GHT LIMIT: TO BUILD: TOOLS NEEDED: 68 Kgs Manual en español ubicado en GQAlpha.com Spanish Manual located at GQAlpha.com CUSTOMER SERVICE GQAlpha.com • CustomerService@GQAlpha.com • 1-800-837-7732 • 12798 Perimeter Rd Ste C 106 Dallas Tx 75228...

  • Page 2: Customer Service Information

    KIDS ROCKER SEESAW warnings and product information can be found at: https://www.gqalpha.com / MODEL# 2306RS To order these parts, or if you have any other questions or Please do not return your item. Please report items that are concerns about this GQ Alpha product, please contact us at damaged or missing parts to the manufacturer GQ Alpha within 3days of delivery.
  • Page 3 Rocker Seesaw • DO NOT allow children to climb or hang hazard. instructions before use. from the steel tubing – this can cause serious injury. • Dispose of all packaging materials safely and per local ordinance. MODEL#2306RS...

  • Page 4: Parts List

    PARTS LIST Base Rails Foam Rocker Bar Handle Tube Backrest CustomerService@GQAlpha.com GQAlpha.com 1-800-837-7732...
  • Page 5 Seats M6 45mm Bolt M6 40mm Bolt M6 50mm Bolt 10 - 11 - 12 - 13 - Square Nuts Hex Nut Washer Safety Caps 14 - 15 - 16 - Flat Cap (Large) Flat Cap (Small) Round Cap MODEL#2306RS...
  • Page 6 ASSEMBLY INSTRUCTIONS How To Assemble Video Link: https://www.youtube.com/watch?v=BI6PL6P5oz0 STEP 1 Parts: Part 1 (x2) - Base Rails Part 6 (x1) - Seat Place both Base Rails (Part 1) in a flat surface free of obstructions. Place Seat (Part 6) with the flat surface facing the floor and align the side openings to the middle openings of the Base Rails (1).
  • Page 7 8) aligned by the Base Rail and Seat openings. NOTE: When Installing the Seats to the Base Rails, do not install to the 4 locations circled as shown. These are reserved to install the Handle Bars in Step 12. Do not Install MODEL#2306RS...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 4 Parts: Part 2 (x2) - Foam Rocker Bar Part 7 (x4) - M6 45mm Bolt Part 11 (x4) - Hex nut Part 12 (x4) - Washer NOTE: Round Cap (Part 16) is already installed on the Foam Rocker Bar (Part 12).
  • Page 9 Footrest Tube (Part 5). Tighten with a M6 40mm Bolt (Part 8), Hex Nut (Part 11), and Washer (Part 12). Repeat until you have 2x completed Handle Tubes with the Footrest Tubes installed. MODEL#2306RS...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7 Insert the Assembled Handles on the inside of the Seesaw. Align the upper openings of the Handle Tubes to the Base Rails, and bottom openings to the Foam Rocker Bars STEP 8 Parts: Part 9 (x4) - M6 50mm Bolt Part 11 (x4) - Hex nut Part 12 (x4) - Washer Locate the aligned middle openings in...
  • Page 11 (Part 12). Hide the head of the Bolt under the foam of the Foam Rock Bars. NOTE: Make sure the head of the Bolts are facing the outside of the Seesaw to avoid scratches or scrapes when in use. MODEL#2306RS...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP 10 Parts: Part 4 (x2) - Backrest Insert the Backrest (Part 4) from the outside of the Base Rails and slide the tips on the inside of the Rocker Seesaw. Align the openings of the tips to the Foam Rocker Bars to the Backrest to install the hardware in Step 11.
  • Page 13 STEP 13 Parts: Part 13 (x20) - Safety Caps Use the Safety Caps (Part 13) to hide any excess from the Bolts. NOTE: Failure to use the Safety may cause scratches, scrapes, or injury while when product is in use. MODEL#2306RS...

  • Page 14: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS Question: “A seat seems loose, what Question: “Something was missing Question: “How should I clean my should I do?” from the packaging,” “I need to seesaw?” purchase a replacement part” or “I Answer: Make sure the Bolts/Nuts discovered a damaged piece.
