Quick Guide: DB350
Warning:
Before beginning the startup of the Flex Cart, make sure the cart is in the proper place for
blasting. If blasting indoors, move the cart close to the blasted surface. If the blasted surface is
outdoors, leave the Flex Cart inside and cover the remaining distance with the blast hose. Once
the machine is situated in the proper spot and on a flat, smooth surface, be sure to lock all of the
caster wheels on the bottom of the cart to keep the machine in place during use. Operator is
responsible for reading and understanding all warnings and safety information listed in the blast
pot user manual and this Quick Guide before machine use.
Machine Component Overview
Flex Cart Start Up & Shut Down
®
Abrasive adjustment
mark/outlet pipe
Moisture trap
Filter
1
Blast pot connect
Quick-connect
Service ball-valve (for
tools or Radex filter)
Air inlet
Radiator/cooler
Advertisement
Table of Contents
Related Manuals for DUSTLESS BLASTING DB350
Summary of Contents for DUSTLESS BLASTING DB350
- Page 1 Quick Guide: DB350 Flex Cart Start Up & Shut Down ® Warning: Before beginning the startup of the Flex Cart, make sure the cart is in the proper place for blasting. If blasting indoors, move the cart close to the blasted surface. If the blasted surface is outdoors, leave the Flex Cart inside and cover the remaining distance with the blast hose.
- Page 2 Flex Cart Start Up Caution: Make sure the machine is off and depressurized before completing the startup steps. The air-inlet shutoff valve on the blast pot should be closed and the blow down valve should be open. Make sure the caster wheels are set to the locked position.
- Page 3 5. Connect the blast pot to the power supply as shown in the Figure below. Power supply cord (connect this cord) Redhead electric deadman power supply (do not Connect the power supply cord to the cord on the air cooling connect this cord) and drying system.
- Page 4 8. Turn on the compressor or other air source and let compressor idle for 10-15 seconds before allowing air to flow freely to the Flex Cart. Slowly open the lever on the accessory ball valve if applicable. Warning: Follow all safety procedures listed in your blast pot user manual before, during, and after active blasting.
- Page 5 Flex Cart Shut Down Caution: If using a compressor for air source, DO NOT turn the compressor off when starting the shut down process. Failure to leave the compressor running will cause a backflow of air, water, and media into the system and could damage the machine.
- Page 6 5. After each blast, drain the water from the moisture trap next to the air drying and cooling system by loosening the screw on the bottom of the trap. Loosen screw on moisture trap 6. After each blast, drain the water from the filter on the side of the air drying and cooling system by loosening the wingnut on the bottom of the device.
