Dawnway UVC100 User Manual

Uv-c led disinfection faucet, sgs test-approved disinfection rate 99.9%
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

UVC100
UV-C LED Disinfection Faucet
SGS Test-approved disinfection rate >99.9%
User's Manual

Specifications

 Power supply：Input 100VAC~240VAC / Output DC12V-2A
 Water Quality：Light penetration rate >=90%
Impurity Particle Size <= 10 μM
 Water Temperature：5 ~ 40 ℃
 Water
Pressure：
Max. 100 psi
 Flow Control：Max. 2LPM
 Ambient
Temperature：
0 ~ 55 ℃
Indicator Light
[INCH]
UNIT :
( Fig. 1 )
mm
UVC Module
Mounting
Hole
( Fig. 2 )
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UVC100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dawnway UVC100

  • Page 1 UVC100 UV-C LED Disinfection Faucet SGS Test-approved disinfection rate >99.9% User's Manual Specifications  Power supply：Input 100VAC~240VAC / Output DC12V-2A  Water Quality：Light penetration rate >=90% UVC Module Indicator Light Impurity Particle Size <= 10 μM Mounting Hole  Water Temperature：5 ~ 40 ℃...
  • Page 2 Installation Steps (Please refer to Fig. 3, Fig. 4) 1. Ensure a ∮35mm mounting hole in the countertop. Lock Nut(8) 2. do not remove or loosen the lock nut (8). Inlet Threaded Tube(1) 3. Ensure that the waterproof O-ring (7) is attached to the base plate Horseshoe Gasket(2) of the faucet, remove the horseshoe gasket (2) and set it aside, Hex Lock Nut(3)
  • Page 3 7. Connect the black plug (6) of the adapter with the black socket (4-1) of the power cable, and connects to power supply. When the power cord is plugged into the power supply, the red and blue lights will flash once indicate that the faucet function is in normal standby state.
  • Page 4 Safety Guidelines 1. Please follow the instructions of the installation steps. It is recommended that you hire a qualified professional to complete the installation to prevent personal injury or damage. 2. Please consult your local dealer or official after-sales service personnel for any inquiry. 3.
  • Page 5 Troubleshooting Guide Problem Cause Remedy Check if the water source is completely turned on Insufficient water pressure No water or low water pressure, Check if the water purifier is working the blue light is not on properly Contact the local dealer or official after- Faucet failure sales service personnel Power supply failure...
  • Page 6 Dawnway Enterprise Co., Ltd 69, Lane 466, Siangshang Road, Sec.9, Wuchi, Taichung, 43547, Taiwan www.dawnway.com.tw...
