Summary of Contents for Avance L12
- Page 1 System Assembly manual www avance com tw...
-
Page 2: Disassembly Of Rear Cover
Accessories # 6-32 head-Bl screws M2 head-Bl screws ODD Plastic rail Length mm Length 2mm Q`ty : 1pc ： Q`ty : 8pcs Q'ty 2pcs color : blue ： ： Color Nickel color Black use : ODD(*1) ： ： use M/B(*8) use ODD(*2) #6-32 screws M3 Step screw... - Page 3 Installation of 3.5" HDD A 3 ( .5”HDD x 1) user can Installation the 3.5"HDD at this location. please take out the black plastic HDD holder Re-fit the black plastic HDD holder after fitted the 3.5”HDD. HDD 180°SATA Power Cable HDD SATA Date Cable B 3 ( .5”HDD x 1) user can...
- Page 4 Installation of 2.5" HDD please fit this 2.5HDD under the ODD C (2.5”HDD x 1) This 2.5”HDD must be assembled before fitting the ODD fit the HDD on cradle , push and move Screwing the accessories open the cradle fitting 2pcs “ E” screw on 2.5”HDD it as the RED arrow direction “E”x1pc 0°SATA Power Cable...
- Page 5 Installation of ODD Disassemble the half- Assemble " C” onto ODD Slide the ODD into chassis Slides off the side cover punched metal cover to with 2pcs accessories "B" upwardly from front side take it out m-SATA Cable 0°SATA Power Cable Installation of Intrusion Switch cable(Optional) SHORT in Habit GREEN+WHITE...
- Page 6 Smart Card Reader(Optional) Smart Card Reader USB Cable Smart Card Reader Remove the half-punched metal cover fit the smart card reader Installation of L12 solenoid lock (optional) M3 head-Bl screws (optional) Fit the PCB with 2pcs M3 screw, L12 solenoid lock Length =4mm Q`ty : 6pcs the cable should be at the top side.
- Page 7 10.SOP for Installation the active speaker on L12 (Optional) Please tear off the sticker at the back side of PCB/speaker . L12 Speaker & PCB Stick the PCB/speaker on the inner side of top cover M/B side Cable From Front I/O...
