Summary of Contents for RuggON CHASER
- Page 1 CHASER RuggedTouchMonitor User's Manual Model: RTD S11 Ver.: 1.2...
- Page 2 © 2020 RuggON Corporation. All rights reserved. TRADEMARKS RuggON logo is a trademark of RuggON Corporation, registered in the United States Patent and Trademark Office and in other countries. All brand and product names are trademarks or registered trademarks of their respective owners.
-
Page 3: Table Of Contents
Table of Contents About This Manual Related Information ..................1 Conventions....................1 Safety Information Intended Use ....................2 Maintenance and Operation Overview ............2 Safe Environments of Use ................3 Distractions ....................3 Safety ......................3 Electrical Hazards..................3 Security Guidelines for Mounting..............3 Environmental....................3 Cleaning and Servicing.................4 Touchscreen Care ..................4 Regional Compliance ...................5 Chapter 1. - Page 4 Chapter 3. Operations LED Indicators ....................24 Enabling and Disabling Black Out Function ..........24 Adjusting Volume ..................25 Adjusting Brightness ...................26 Switching Video Sources ................27 Muting Audio ....................28 Enabling and Disabling Night Mode Function..........28...
-
Page 5: About This Manual
Related Information Current information and manuals are available for download at the following website: https://www.ruggon.com Conventions Bolded or Underlined text is used to emphasize the designated information. Note: A Note is used to provide additional information for the device or settings. -
Page 6: Safety Information
For important safety and health information as well as Limited Warranty terms applicable to the ® RuggON Rugged Touch Monitor, read the document prior to using the device. Failure to follow the instructions, the proper setup, use, and care of this device may increase the risk of serious injury or death, or damage the device. -
Page 7: Safe Environments Of Use
Electrical Hazards Use only Supplied Power Cables Use only supplied power cables from RuggON. Environmental Hazards Do not use the Rugged Touch Monitor in locations near/with flammable gases or vapor. The use of electrical equipment in explosive environments can be dangerous. -
Page 8: Cleaning And Servicing
The prolonged use of alcohol on the chassis and front panel keys can lead to █ discoloration „ It is recommended to not use an alcohol cleaning solution on the RuggON logo to avoid █ discoloration „ Never clean the Rugged Touch Monitor with compressed air, a pressure washer or a vacuum █... -
Page 9: Regional Compliance
Europe European Declaration of Conformity According to ISO / IEC Guide 22 and EN 450 14 Manufacturer’s Name: Ruggon Corporation Manufacturer’s Address: 4F, No. 298, Yang Guang St., NeiHu. Taipei, Taiwan Declares, under our sole responsibility, that the product: Product Name: Rugged Touch Monitor, Model Number: RTDS11, conforms to the following Product Specifications: „... - Page 10 █ E-Mark Supplementary Information In addition, the power supply provided with this product has been certified to IEC 62368-1: 2014 2nd edition and/ or EN 62368-1: 2014 +A11: 2017. As manufacturer, we declare under our sole responsibility that the equipment follows the provisions of the Standards stated above.
-
Page 11: Chapter 1. Introduction
This document is not intended to replace the training and expertise of the end-user. Unpacking the Device Before you begin the installation or configuration process make sure to inspect all components and accessories. Contact your representative if there are missing or damaged items. Visit the following website to contact us: https://www.ruggon.com/en/contact.php... -
Page 12: Parts List
Introduction Parts List The Rugged Touch Monitor ships with the following accessories. For additional information, contact your local RuggON sales representative by visiting the following website: https://www.ruggon.com/en/contact.php Rugged Touch Monitor 1 x USB Type C to Metal Brackets for Exterior... -
Page 13: Technical Specifications
Introduction Technical Specifications Table 1. Technical Specifications Item Description Monitor 11.6” TFT LCD Full HD (1920 x 1080) Contrast Ratio: 1000:1 Viewing Angle: 85°/85°/85°/85° „ █ Projected capacitive touchscreen with 10-point multi-touch Touch Screen „ █ Anti-reflective and anti-fingerprint coatings Brightness 1000 nits high brightness Power Consumption... -
Page 14: Identifying The Device
Introduction Item Description Shock and Vibration MIL-STD 810H Environmental Operating Temperature -20°C to 60°C (-4°F to 140°F) Storage Temperature -30°C to 70°C (-22°F to 158°F) Humidity 95%, non-condensing Identifying the Device Overview Figure 1. Overview Table 2. Overview Item Description Left view Left side of the device. - Page 15 Introduction Front View Figure 2. Front View 1 2 3 4 5 6 7 Table 3. Front View Item Description Mute button with Enable or disable speaker audio Volume down* Lowers audio volume button with LED Table 4 LED indicators, see page 12. Volume up* button Raises audio volume with LED...
- Page 16 Introduction Table 4 LED Indicators Function Color Description Power off None Device is powered off No video Video source button Green Video signal not acquired source Black out button Amber HDMI signal Mute button Video signal acquired Brightness up button Brightness down button Black out button Volume up button...
- Page 17 Introduction Top View Figure 3. Top View Table 5 Top View Item Description USB cover Open to access the top USB port. USB 2.0 Type A Connect USB devices to the Rugged Touch Monitor. Note: The USB connector located on the top of the device is protected with a rubberized cap.
-
Page 18: Dimensions
Introduction Rear View Figure 5. Rear View Table 7. Rear View Item Description VESA mount holes M5 screw holes for hardware mounting Speaker 2 x 3W stereo speakers with amplifier Bracket securing Securing holes for metal bracket holes Anchors Strain relief anchors for zip ties Dimensions The following image lists the device dimensions. -
Page 19: Touch Screen
Introduction Touch Screen Caution: Never use an actual pen, pencil, or sharp/abrasive object on the touch screen. Warning: The screen on the device is made of glass and can, potentially, break when dropped or sustains an impact with a hard surface. In the event of screen damage, do not attempt to remove the broken glass or any shards. -
Page 20: Chapter 2. Getting Started
Getting Started This section provides an outline of the steps necessary to setup a Rugged Touch Monitor. A detailed guide follows the listed items. For additional technical assistance, contact your RuggON representative by visiting the following website: HTTP://www.ruggon.com/en/contact.php Note: It is recommended to installing or remove accessories on a clean, well-lit work surface. - Page 21 Getting Started To secure a cable: Once the cable is properly installed in the device port, gently tug on the cable to remove any excess slack. Locate the bracket and position it over the intended cable. Insert the bracket over the cable aligning both the grooved end over the cable and the screw slot on the bracket over the screw hole on the device.
- Page 22 Getting Started Use the provided Zip ties to secure the cable to the strain relief anchor on the device. Figure 9. Secure Cable to Strain Relief Anchor In this manner the cable can be secured in place to prevent it from accidentally being unplugged or damaging the device port.
- Page 23 Getting Started Note: Due to the size of the USB type C cable head design, a securing bracket is not necessary for this cable type. Use the provided Zip ties to secure the cable to the strain relief anchors on the device. Figure 11.
- Page 24 Getting Started When connecting a USB cable to the top of the panel, pry open the rubber cover over the USB port. Take care to not use excessive force on the rubber cover to prevent damaging it. The cover can be torn if pulled back too far or excessive force is used. Figure 13.
-
Page 25: Connecting The Power Supply
Getting Started Locate the metal bracket and position it over the HDMI cable. Insert the bracket over the cable and secure with the provided screw. Use the provided Zip ties to secure the cable to the strain relief anchors on the device. Figure 15. - Page 26 Getting Started Warning: Refer to the following instructions for battery powered vehicles: + is for the positive battery terminal „ █ - is for the negative battery terminal „ █ GND must be connected to the vehicle chassis ground „ █...
-
Page 27: Mounting Hardware
Getting Started Mounting Hardware The Rugged Touch Monitor is designed with standard VESA mounting support. Standard M5 mounting screws are provided for the mounting installation. The screws are designed for standard mounting brackets. If a bracket design is not a standard bracket, additional screws may be required. -
Page 28: Chapter 3. Operations
Operations Chapter 3. Operations This section provides information and guidance for the correct operation of the Rugged Touch Monitor. Note: To prevent damage to the device, connect all cabling and accessories before powering up the device Note: Considering RTD-S11 Rugged Touch Monitor as a passive device that requires a host system for proper operation, its self-protection mechanism includes backlight adjustment when the system is overheated. -
Page 29: Adjusting Volume
Operations quickly turns on/off. See “LED Indicators” on page 24 for further information about the LED indicator. Figure 18. Enabling Black Out Black Out Button Adjusting Volume Locate the front side of the Rugged Touch Monitor. See “Front View” on page 11. Locate the Volume buttons on the device. -
Page 30: Adjusting Brightness
Operations information about the LED indicator. Figure 19. Adjusting Volume Volume Down Volume Up Adjusting Brightness Locate the front side of the Rugged Touch Monitor. See “Front View” on page 11. Locate the Brightness buttons on the device. Press the down button to decrease the brightness or the up button to increase the brightness level. -
Page 31: Switching Video Sources
Operations Figure 20. Adjusting Brightness Decrease Increase Switching Video Sources Locate the front side of the Rugged Touch Monitor. See “Front View” on page 11. Locate the Source Switching button on the device. Press the button once to cycle through the available sources. The LED indicator on the button lights when activated. -
Page 32: Muting Audio
Operations Muting Audio Locate the front side of the Rugged Touch Monitor. See “Front View” on page 11. Locate the Mute button on the device. Press the button once to enable the mute function. Press it again to disable the mute function.
