Summary of Contents for AOODOR 800-052
- Page 1 Assembly&Instruction Manual SKU:800-052 3 SEAT SWING BED wing Installation Guide Save this manual for future reference...
- Page 2 INTRODUCTION Thank you for purchasing Aoodor s Patio Swing Bed ! We hope you will find joy in our products for many years to come. To ensure your personal safety during installation and to get the most out of your investment, please read this entire manual before beginning the installation process.
- Page 3 Par ts Desc Ref No Par ts Desc Ref No 800 052 001 800 052 015 800-052-002 800-052-016 800-052-003 800-052-017 800-052-004 800-052-018 800-052-005 800-052-019 800-052-006 800-052-020 800-052-007 800-052-021 800-052-008 800-052-022 800-052-009 800-052-023 800-052-010 800-052-024 800-052-011 800-052-025 800-052-012 800-052-026 M6x1 800-052-013...
- Page 4 A ssembly Step1:Joint the top cross beam together and fasten them by using bolt(P),washer(W),nuts(V),plastic cap(Z) Step2:Insert the top cross beam into the upright supports(A)(B) and fasten them by using bolt(R),washer(W), nuts(V),plastic cap(Z)
- Page 5 Assembly Step3:Joint the rear cross brace together and fasten them by using bolt(O),washer(W),nuts(V),plastic cap(Z) Step4.1:Fasten the rear cross brace to the rear upright supports by using bolt(R),washer(W) nuts(V), plastic cap(Z). 4.2:Fasten the lateral cross braces to the upright supports by using bolts (Q),washer(W),nuts(V), plastic cap(Z)
- Page 6 Assembly Step5:Joint the arm(I)and(I1)with beam(K)and(L) fasten them by using bolt(S).Pay attention to the beam(L),there are two locks for locking the seat back. Locking the seat Step6:Assembly the seat(J) with the bed frame and fasten them by using bolt(T), plastic washer(U),washer(W),nuts(V) and plastic cap(Z) Noted:There are two latches to locking the seat to the bed frame.
- Page 7 Assembly Step7.1:Assembly the tube(E1) to the arm and fasten them by using bolt(S) washer(W) nuts(V) and plastic cap(Z). 7.2:Assembly the hanging springs to the tube(E1). Step8:Hanging the seat frame onto the swing.
- Page 8 Assembly Step9:Assembly the canopy(M) to the swing using the plastic bolt(Y). Step10:Place the cushions on the bed and insert the latches to locking the bed.
- Page 9 Assembly Step10:released the latches and insert the cushion back support to the locking system to becoming a swing chair Please don’t hesitate to contact us for any further questions, your satisfaction is guaranteed. customerservice@aoodor.com https://www.aoodor.com/...
