User Manual
DA-810DSP
SPECIAL DSP AMPLIFIER
Please read this manual carefully before using this product and keep it for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA-810DSP and is the answer not in the manual?

Questions and answers

Summary of Contents for ACADEMY DA-810DSP

  • Page 1 User Manual DA-810DSP SPECIAL DSP AMPLIFIER Please read this manual carefully before using this product and keep it for future reference...
  • Page 2 Please contact with professional engineer for checking to avoid accident happen. Packing List For every package including below items, Please noticed retailer and Factory if shortage: DA-810DSP unit User Manual Warranty Card Head Unit Cable 1PC (Option)

  • Page 3: Table Of Contents

    Contents User Manual Mobile Application Instructions....................1-4 1. Features 1.1 Audio specification、main audio signal process diagram………..5 1.2 Input and output side panel………..…………………………………..…...6 1.3 Software Introduction……………………………….…………........6 1.4 Function Introduction………………………………………….........7 2. Installation 2.1 System classic connecting reference………..……...…..………..……...8 2.2 Unit connection..……………….………….……..…….….........9 Low level RCA input/output………………………………………......9 USB2.0 Port……………….…..………………….……….........…10 The remote control function is introduced ..........11 3.

  • Page 4: Mobile Application Instructions

    Mobile Application Instructions Main volume adjustment Android mobile scan Qrcode on gift box to download the application to install DA-810DSP ● The main volume can be adjusted by app. Turn on the unit and plug in external pressing the main volume scale clockwise or counterclockwise by hand.
  • Page 5 The main / subwoofer volume is 0-66. 1、Click 【 Reset EQ 】 to restore the parameters of the 31-band equalizer to the Click【EQ】to enter EQ interface original. pass-through mode (the equalizer frequency, Q value and gain are restored to their initial values). DA-810DSP Special DSP amplifier...
  • Page 6 Output Signal Function ● Click [System] to synchronize the data,for Group/Noise-gate/Preset Setting. 2、Click 【 】to adjust the volume by sliding left and right. 2.Click phase for every output channel: In Phase or Out Phase（0 ゜/180 ゜） DA-810DSP Special DSP amplifier...
  • Page 7 CH1 to CH10 speakers. Mixer settings Click [Mixer] to enter Mixer interface, It can Perform 10 Output Channel adjustment. USB-L, USB-R, digital left and digital right, Bluetooth left and Bluetooth right mix selection and adjustment. DA-810DSP Special DSP amplifier...

  • Page 8: Features

    Low level Low level Low level Low level Low level Low level Low level Low level Low level level Output10 Output1 Output2 Output3 Output4 Output5 Output6 Output7 Output8 output 9 DA-810DSP Special DSP amplifier...

  • Page 9: Input And Output Side Panel

    10) PC Connection 11) Remote Control 1.3 Software Introduction DA-810DSP PC software control: (please check 3. Software Operation detail ) 1) Auotmetically detect whatever the hardware is connecting with USB cable, if ready and will connect with head unit autometically.

  • Page 10: Function Introduction

    Android/ Ios APP & PC Software for DSP Setup & Tuning for FLAC, WAV, MP3, WMA, AAC Lossless Audio Player (USB): 48KHz/24Bit Sampling rate: Optional Remote control: +12 V starting voltage output(0.2A) Turn-on REM output ≤0.1W Power consumption Mute, -59.9dB to 6.0dB Output signal gain range DA-810DSP Special DSP amplifier...

  • Page 11: System Classic Connecting Reference

    Figure 2.1 this connecting method is for two units input, please refer below: 1. Please use Plug & Play cable to connect original car unit and DA-810DSP for upgrade audio system effects. Please use OUT9 and OUT10 RCA output when Install bass amplifier or subwoofer 2.

  • Page 12: Unit Connection

    CH9 and CH10 is ultra-low left and ultra-low right, usually external bass amplifier, as bass strengthened. Of course,users can configure their own initiative RCA low level output to complete more high-end divided by two or three-way system. DA-810DSP Special DSP amplifier...

  • Page 13: Usb2.0 Port

    As shown in figure 1.2.1, the "10" indicator bit is the "USB2.0" position. Figure 2.3 Use Random accessories USB cable into this hole on a computer connected to the PC, open tuning software to debug the sound system. DA-810DSP Special DSP amplifier...

  • Page 14: The Remote Control Function Is Introduced

    : Press the knob to switch, select next song. : Press the knob to switch, select pause song. PLAYER Mode. Connect a USB device into the dedicated port. Press the knob to select SOURCE then press the knob to select USB. DA-810DSP Special DSP amplifier...

  • Page 15: Software Operation

    DA-810DSP provides only wired USB PC software connection. Wired USB connection: Ensure that DA-810DSP power state, with a USB cable to connect to a computer through the USB interface, the computer will find the new device and automatically install the update equipment, after a few seconds the installation is complete.

  • Page 16: Software Interface

    User Manual 3.3 Software interface Figure 3.2.2 Software interface DA-810DSP unit divided into the following functional: 1．as shown in figure 3.2.2, "1", input signal selection: high level,Bluetooth, AUX, optical and USB. 2．as shown in figure 3.2.2 "2", shows the main menu and connection status.

  • Page 17: Output Switch

    Select delay units, which are in milliseconds, centimetres, and inches. The range of milliseconds: 0.000~20;Range of mm: 0~692;Range of inches: 0 to 273; DA-810DSP processor output signal path can be any type of configuration freedom to any sound field point and the speaker type. The system defaults to...
  • Page 18 "empty" (no connection to any speaker , there is no output of), as shown below 3.3.4: Figure 3.3.4 The second step, the channel number beneath each, click on the type drop-down menu box, select the option in the pop-up users locate the type of DA-810DSP Special DSP amplifier...
  • Page 19 (Figure 3.3.6), click on the value of the input box next to the corresponding speaker can be entered after the delay value corresponding units. Figure 3.3.6 DA-810DSP Special DSP amplifier...

  • Page 20: Output Signal Equalizer And Crossover Operation

    Straight balanced: the button shown in Figure 3.3.4, the current channel as long as there is an equalizer in the open state, this button will appear highlighted in green state, indicating that you can click this button to make all the equalizer DA-810DSP Special DSP amplifier...
  • Page 21 Adjustment range: 20Hz ~ 20KHz. Slope(slope)settings:6dB/Oct,12dB/Oct,18dB/Oct,24dB/Oct,30dB/Oct,36dB/Oct, 42dB/Oct, 48dB/Off/Oct and other 9 options. Note: In 6dB / Oct, there is no type of algorithm, but a common type (displayed as NULL). DA-810DSP Special DSP amplifier...

  • Page 22: Output Signal Function Operation

    "Default" is to restore the initial system configuration, system configuration 4.1 sound field initial full frequency mode. "Cancel" is to cancel the click operation. DA-810DSP Special DSP amplifier...
  • Page 23 FBI logo be displayed. Mixer settings: click "mixer" in the "7" area in Figure 3.2.2, then you can switch to (Figure 3.3.14) the relevant parameter settings for the corresponding adjustment. figure 3.3.14 DA-810DSP Special DSP amplifier...

  • Page 24: Setting Introduce

    User Manual 3.4 Setting introduce Figure 3.4.1 As shown in Figure 3.4.1 DA-810DSP software of the scene in three major types of actions: the machine stored scene data, computer data stored scene and the whole scene data manipulation. 1．the machine data stored scene operation: refers to the scene data is now running...
  • Page 25 Group 4, and is also the current machine running scene, you can see the upper left corner of the software will display the current run of the name of the preset scene. Figure 3.4.3 DA-810DSP Special DSP amplifier...
  • Page 26 Step3: as dialog box of figure 3.4.5 , select the machine where the user wants to load a preset number (as selected on the 3rd), and then point below the "Load" button on the pop-up shown 3.4.6 loading data transfer progress shown in the wait window. Figure 3.4.6 DA-810DSP Special DSP amplifier...

  • Page 27: Load And Save The Whole Store A Scene

    This function is previously stored in the scene file on the computer the machine work load for the current scene step1: Click on the main interface to the top menu "Memory" button will pop up all the scenes action item (see Figure 3.4.1) DA-810DSP Special DSP amplifier...
  • Page 28 We recommend similar models when making audio system, for the whole replication functions. The specific operation method is basically the same as "loading the scene file on the computer", please refer to the operation by yourself. DA-810DSP Special DSP amplifier...

  • Page 29: Operations Introduction

    In the Options menu, click on "Reset" ,This operation will restore factory settings. 3.5.3 Input Vol In the Options menu, click on "Input Vol" ,It can adjust the range of Subwoofer volume and Bluetooth volume. Figure 3.5.3 DA-810DSP Special DSP amplifier...

  • Page 30: Information About The Inquiry

    3.5.５ Encrypt Setting In the options menu, click the " Encrypt" option with the mouse, and a message dialog box will pop up, in which you can set the password for encryption. shown in Figure 3.5.５. Figure 3.5.５ DA-810DSP Special DSP amplifier...

  • Page 31: Common Trouble Shouting

    1. pls check if turn on mute style No voice 2. pls check if input channel is correct? 1. pls check if USB cable is setting correct cannot link USB 2. pls cehck if find name as “ HID-compiling device”in the computer DA-810DSP Special DSP amplifier...
