Summary of Contents for MoreSense MSWB2213
- Page 1 MSWB2213 MSWB2213 MoreSense WiFi & BLE Module User Manual V1.2...
- Page 2 MSWB2213 Revision History Revision Description Release Date V1.0 MSWB2213 User Manual Initial Version V1.1 Revised The Dimension 2021-11-8 V1.2 Updated Internal And External Antennas 2021-12-3 Proprietary Statement: Shenzhen MoreSense Technology Co., Ltd. All Rights Reserved Copyright © 2021 by MoreSense...
-
Page 3: Table Of Contents
MSWB2213 Catalog 1 Product Description...................... 1 2 System Block Diagram....................2 3 Product Features......................3 4 Key Application......................4 5 Parameter for MSWB2213................... 4 6 Pin Definition........................6 7 Module Dimension....................... 9 8 Name Rules........................9 9 Precautions........................10 10 Hardware Typical Application................. 11 11 Package Information ....................12... -
Page 4: Product Description
▶ Perfect security mechanism-hardware encryption accelerator supports AES-128/256,Hash,RSA, HMAC,digital signature and secure boot-integrated hardware random number generator-support; ▶ Abundant communication interfaces and GPIO pins,which can support a variety of scenarios and complex applications. Physical Map Built-in Antenna: Shenzhen MoreSense Technology Co., Ltd. １... -
Page 5: System Block Diagram
MSWB2213 2 System Block Diagram Shenzhen MoreSense Technology Co., Ltd. ２... -
Page 6: Product Features
• Channel Selection Algorithm#2); • 32-bit RISC-V single-core processor with a main frequency of up to 160MHz; • 384KBROM; • 400KBSRAM (in which 16KB is dedicated to cache); • 8KBRTCSRAM; • Embedded Flash 4M. Shenzhen MoreSense Technology Co., Ltd. ３... -
Page 7: Key Application
• Consumer Electronics:smart watches,smart bands – OTT TV boxes,set top box devices – Wi-Fi and Bluetooth speakers,toys with data upload and proximity sensing toys •Smart Agriculture:smart greenhouse,smart irrigation,agricultural robots • Retail Catering: POS systems,service robots,cloud printers • Universal Low-powered IoT data logger 5 Parameter for MSWB2213 Type Parameter Value Certification Standards... - Page 8 Average (STA,1KB/s): 54mA Average (AP): 85mA Operating Temperature -40℃- 85℃ Storage Temperature -40℃- 125℃ Humidity <85% MSWB2213： DIM. 22mm x 13.5mm x 3mm Wireless Network Type STA/AP/AP+STA/BLE5.0 Security Mechanism WEP/WPA-PSK/WPA2-PSK Software Encryption Type WEP64/WEP128/TKIP/AES Shenzhen MoreSense Technology Co., Ltd. ５...
-
Page 9: Pin Definition
Parameters Local Wireless Upgrade Firmware Remote upgrade Customization Provide SDK for customer’s 2nd development Development Network Protocol IPv4,TCP/UDP/HTTP/MQTT AT+ command set,Web page User Configuration Android/iOS terminal Smart Link smart configuration APP 6 Pin Definition Shenzhen MoreSense Technology Co., Ltd. ６... - Page 10 MSWB2213 Table.1 MSWB2213 Pin Function Definition Name Type Description I/O/T GPIO4,if it does not use-NC I/O/T GPIO5,if it does not use-NC I/O/T GPIO6,if it does not use-NC I/O/T GPIO7,if it does not use-NC UART0 3.3V Communication Serial Port 0 Output...
- Page 11 Restore Default I/O/T GPIO10,can do PWM3 function Configuration(can be configured as GPIO10) IO20 I/O/T Debug_RX GPIO20 1021 I/O/T Debug_TX GPIO21 +3.3V Power Supply Power Ground Power I:Input O:Out T:It can be set as high impedance. Shenzhen MoreSense Technology Co., Ltd. ８...
-
Page 12: Module Dimension
MSWB2213 7 Module Dimension Unit: Millimeter (mm) 8 Name Rules Shenzhen MoreSense Technology Co., Ltd. ９... -
Page 13: Precautions
•MoreSense recommends that the MSWB2213 module be placed in the following areas of the user board,which aimed to reducing the impact on the antenna and wireless signals.At the same time, please ask MoreSense for technical support to assist in the placement of the module and the layout design of related areas. -
Page 14: Hardware Typical Application
MSWB2213 10 Hardware Typical Application Shenzhen MoreSense Technology Co., Ltd. １１... -
Page 15: Package Information
Table 1.Reflow Data Program Temp. (℃) Time(S) Re-fluxing Time Above 220℃ 35~55S Peak Temp. Highest 260℃ Note： : 1.It is recommended to use a nitrogen re-flux furnace; 2.The oxygen content is less than 300ppm. Shenzhen MoreSense Technology Co., Ltd. １２... -
Page 16: Instruction
Situation 2;The WIFI module is designed on the BOT side of the customer's PCB and follows the normal baking rules. Note:The window time means 168 hours from the end of the last baking to the beginning of the next reflow. 11.3 MSWB2213X Package Method Reel Packaging Dim.:340*340*50 mm Shenzhen MoreSense Technology Co., Ltd. １３... - Page 17 KDB 996369 D03 OEM Manual 2.2 List of applicable FCC rules The MSWB2213 is an BT Module with GFSK modulation and WIFI Module with DSSS and OFDM. BT module operates on the 2402MHz~2480MHz band and WIFI Module operates on the 2412MHz~2462MHz.
- Page 18 2.7 Antennas The MSWB2213 is an BT/WIFI Module beams signals and communicates with its antenna, which is PCB Antenna. The PCB Antenna gain is 1.5dBi. The module shall be only used with the internal antenna(s) that has been originally tested and certified with this module.The antenna must be either permanently attached or employ a 'unique' antenna coupler.
- Page 19 2.8 Label and complianceinformation Host product manufacturers need to provide a physical or e-label stating "Contains FCC ID: 2A86J-MSWB2213"with their finished product. 2.9 Information on test modes and additional testingrequirements Data transfer module demo board can control the EUT work in RF test mode at specified test channel.Additional testing, Part 15 Subpart B disclaimer.The module without unintentional-radiator...
