USER MANUAL
Glide-Aside®
Motorised Track
Compatible with Glide-Aside® 2nd generation motors from January 2023
A
OPEN
STOP
CLOSE
BLUE LED
Dual Channel Remote
Model: 16GAAT1W
Remote Battery Insertion/Replacement*
Use a tool (such as a sim card pin,
paper clip or mini screw driver)
to press the small release button and
push the battery cover down to open.
Back of
Remote
Battery Type: CR2450 3V
Working temperature: -10°C~50°C
*Please read Battery Warning & General Usage Advice on the last page of these instructions.
Tel 0113 250 4499 • Email sales@rca-uk.com • Visit rca-uk.com
B
OPEN
STOP
CLOSE
Battery Life: 2 Years Approx.
Transmitting Power: -10mW
LCD
A
OPEN
STOP
CLOSE
Channel
Down
BLUE LED
LCD 15-Channel Dual Remote
Model: 16GAAT15W
Back of
Remote
Radio Frequency: 433.05~434.79MHz
Radio Range: 200m Outdoors or 35m Indoor Use
B
OPEN
STOP
CLOSE
Channel
Up
Advertisement
Table of Contents
Summary of Contents for Renaissance Glide-Aside 16GAAT1W
- Page 1 USER MANUAL Glide-Aside® Motorised Track Compatible with Glide-Aside® 2nd generation motors from January 2023 OPEN OPEN OPEN OPEN STOP STOP STOP STOP CLOSE CLOSE CLOSE CLOSE Channel Channel Down BLUE LED BLUE LED Dual Channel Remote LCD 15-Channel Dual Remote Model: 16GAAT1W Model: 16GAAT15W Remote Battery Insertion/Replacement*...
- Page 2 USER MANUAL Glide-Aside® Motorised Track Pairing Remotes to Glide-Aside Battery Power Motor 1. Choose the left or right channel you want to pair on your Remote. For LCD Multi-Channel Remotes you will also have to select a channel No. from 1 to 15 too. Note Channel 0 is not an option! NOTE: Make sure you press the left or right buttons on the Dual Channel Remotes!
- Page 3 USER MANUAL Glide-Aside® Motorised Track Pairing Remotes to Glide-Aside Mains Power Motor 1. Choose the left or right channel you want to pair on your Remote. For LCD Multi-Channel Remotes you will also have to select a channel No. from 1 to 15 too. Note Channel 0 is not an option! NOTE: Make sure you press the left or right buttons on the Dual Channel Remotes!
- Page 4 USER MANUAL Glide-Aside® Motorised Track Battery Warning & Remote General Usage Advice 1. Do not expose your remote to moisture. 2. Do not drop or strike the remote as it may cause damage. 3. Ensure to use ONLY the battery type stated within these instructions. 4.
