OPPLE Sparrow Manual

Table Lamp Sparrow
Assemble
Warning:
Do not connect to power until assembly is
complete.

Product Accessories

LED lamp head
Pole
DC Plug
Touch Control Panel
DC socket
Packing List: User's manual 1PC, Power adapter 1PC, Lamp base 1PC,
Lamp holder & Lamp Pole 1 PC, Screw 1PC.

Rotation Angle Diagram

The maximum rotation angle is 120°.
30°

Assemble Steps

1.Insert the light
pole vertically
the base of the
lamp.
Power adapter
Insert vertically
4.Connect to the power
adapter.
Note: The lamp pole should be fully inserted into the lamp base as
shown in the following figure.
90°
2.Pay attention to
3.Tighten a screw
the alignment of
with a screwdriver.
the port.
Tighten the
screw vertically
5.Plug the adapter into a power
outlet and it's ready to use.
When assembling, if it is When the lamp pole is
found that the clip of the fully inserted into the
lamp pole is exposed, it lamp base and the clip
means that the lamp pole is on the lamp polet is not
not completely assembled visible and assembly is
to the base and the lamp completed.
may not work.
