User Manual FOR TOUCH MONITORS FROM: 55" TO 80" Manuale Utente PER MONITOR TOUCH DA: 55" A 80" Manual de usuario PARA MONITORES TÁCTILES DE: 55"A 80" EB-TSTR-033...
Page 3
Index Package contents Installation of the poles at the base Installation of telescopic mounting poles Shelf installation Installation of the support VESA mounting plans Monitor assembly diagram Monitor mounting on the stand Installing the webcam stand Cable installation Product specifications...
Page 4
Warning! Read the following manual carefully before starting. Improper installation or as- sembly could cause serious personal injury and property damage. If you have difficulty assembling or have questions, contact a qualified installer. Do not install or assemble the product in case there are damaged or missing par- ts, if spare parts are needed, contact the dealer.
Page 6
Installation of the poles at the base Note Make sure that the windows for the management and for the passage of the cables are turned towards the back of the base. Caution Make sure the screws are securely fastened.
Page 7
Installation of telescopic mounting poles Step1 Unscrew the screw located on the lower right part of the pole, using J (Allen key). Save the vine. As shown in Fig-1. Step2 Use both hands to raise and rotate the right pole to the desired height. Then ro- tate the pole again until the holes match and insert the spring ball.
Page 9
Caution Make sure the screws are securely fastened. Choose the height of the shelf and screw to lock. Installation of the support...
Page 10
Caution Make sure the screws are securely fastened. VESA mounting plans VESA 200x200 mm - 800x500 mm...
Page 11
Monitor assembly diagram safety tips Caution Make sure the screws are securely fastened. Note To avoid damage, use a plastic spacer when the depth of the mounting holes is minimal...
Page 12
Monitor mounting on the stand Caution Make sure the screws are securely fastened. Note Move the Monitor towards the center.
Page 13
Installing the webcam stand Caution Make sure the screws are securely fastened. Note Height adjustable...
Page 14
Cable installation Step1 If you need to change the height of the monitor, the operation must be carried out by 2 people. A person holds the monitor from the bottom, as shown in Fig -1. Step2 the other person unscrews the safety screws from both the right and left pole, so that the desired height can be chosen, as set in Fig-2.
Page 16
Product specifications Maximum load capacity 90.9 kg Maximum shelf load 11.4 kg Maximum load webcam support 4.5 kg VESA 200 x 200 - 800 x 500 mm...
