Contents
General: ......................................................................................................................................................... 2
Warning ......................................................................................................................................................... 2
Safety Instructions ........................................................................................................................................ 2
Carts Operation process: .............................................................................................................................. 2
Running-in of new car: .................................................................................................................................. 2
Tips for better experience ......................................................................................................................... 3
Rules of safe using/operation: ...................................................................................................................... 3
Storage Instructions ...................................................................................................................................... 4
Charger using Instructions: ........................................................................................................................... 4
Vehicle Warranty: ......................................................................................................................................... 5
Warranty Terms and Conditions: .............................................................................................................. 5
Warranty period:....................................................................................................................................... 5
Warranty Coverage ................................................................................................................................... 5
Warranty Void if: ....................................................................................................................................... 5
Warranty Excludes: ................................................................................................................................... 5
The vehicle structure and appearance ......................................................................................................... 6
1.
The Z Series ....................................................................................................................................... 6
2.
The WIND S Series ............................................................................................................................. 7
3.
The WIND T Series ............................................................................................................................. 8
Main technical parameters ........................................................................................................................... 9
1.
The Z series ....................................................................................................................................... 9
2.
The WIND S Series ........................................................................................................................... 10
3.
The WIND T Series ........................................................................................................................... 11
Structure and appearance parameters of the whole vehicle ..................................................................... 12
1.
The Z series ..................................................................................................................................... 12
2.
The WIND S Series ........................................................................................................................... 15
3.
The WIND T Series ........................................................................................................................... 16
Maintenance items and cycle ..................................................................................................................... 17
1.
The Z series ..................................................................................................................................... 17
2.
The WIND S series ........................................................................................................................... 17
3.
The WIND T series ........................................................................................................................... 17
Advertisement
Table of Contents
Summary of Contents for raya Z Series
-
Page 1: Table Of Contents
Warranty Coverage ........................... 5 Warranty Void if: ............................5 Warranty Excludes: ........................... 5 The vehicle structure and appearance ......................6 The Z Series ............................6 The WIND S Series ..........................7 The WIND T Series ..........................8 Main technical parameters ........................... 9 The Z series ............................ -
Page 2: General
General: The Information in this car is to show the best ways to use your carts. Warning • Personnel who do not have the driving qualifications shall not drive the vehicle! • The accelerator pedal and brake pedal cannot be pressed at the same time, otherwise it will damage the control system, burn the motor, and even a serious accident! •... -
Page 3: Tips For Better Experience
– Servicing the vehicle The procedure of running-in should be done to the parts of the motor before it works with the maximum load to guarantee the reliability of the cart to extend its life. The period of running- in is one month and procedure should be undergone as follows: •... -
Page 4: Storage Instructions
Storage Instructions • Electric cart should be placed in a cool and dry place • Place blocks behind the tires and disengage the parking brake, this relieves pressure on the brakes while in storage • Check tire pressure to confirm that they are at the correct tire pressure before storing. This will ensure that the tires maintain their shape •... -
Page 5: Vehicle Warranty
Vehicle Warranty: Warranty Terms and Conditions: Raya Auto guarantees the carts against manufacturing defects, during the warranty period indicated in the cart‘s warranty card. Warranty period: Warranty period starts with purchase date up to the expiry date mentioned in the cart‘s warranty card. -
Page 6: The Vehicle Structure And Appearance
The vehicle structure and appearance 1. The Z Series... -
Page 7: The Wind S Series
2. The WIND S Series RY-EZ-401C 401C/OFFROAD RY-EZ-601C RY-EZ-601C/OFFROAD... -
Page 8: The Wind T Series
3. The WIND T Series L2A Golf cart2+2 L2A Golf cart4+2... -
Page 9: Main Technical Parameters
Main technical parameters 1. The Z series Model Z2CJ Z4CJG WIND, Z series, Golf WIND, Z series, Golf WIND, Z series, Golf WIND, Z series, Golf Model Description Cart, 2+2, Normal Cart, 2+2, Off-road Cart, 4+2, Normal Cart, 4+2, Off-road... -
Page 10: The Wind S Series
2. The WIND S Series Model RY-EZ-401C RY-EZ-401C-Off RY-EZ-601C RY-EZ-601C-Off WIND, Golf Cart, WIND, Golf Cart, WIND, Golf Cart, WIND, Golf Cart, 2+2, Model Description 2+2, Normal 4+2, Normal 4+2, Off-road Off-road Suspension Suspension Suspension Suspension Price xxxxx xxxxx xxxxx xxxxx Specs Passenger Capacity... -
Page 11: The Wind T Series
3. The WIND T Series Specs/ vehicle 4 Seaters- Normal Suspension 6 Seaters- Normal Suspension Motor 6.7HP (5KW) AC MAHLE® motor Controller Curtis AC 48V/400A Charger On-board, Input 230V, Output 48V25A Dimension 2375*1206*1920mm Ground Clearance 105mm Battery 6*8V/170AH, flooded batteries Wheelbase front 870mm/ rear 990mm Range*... -
Page 12: Structure And Appearance Parameters Of The Whole Vehicle
Structure and appearance parameters of the whole vehicle 1. The Z series 1. Rear view mirror 10. Charging socket 2. Folding glass 11. Side guard 3. Front bracket 12. Seat 4. Headlight right 13. Top Roof 5. Tire 14. Back bracket 6. - Page 13 Dashboard and control operation Dashboard 1. vehicle USB 4. Forward and back switch 2. ignition switch 5. Panel block cover 3. Round instrument Round instrument...
- Page 14 Keyswitch Turn off the power supply of the whole vehicle at the OF F position, and the electric vehicle stops working, Turn to ON position to power, the electric vehicle enters working state. Headlamp and turn signal switches Rotate twice, lift up, and turn on the high beam, rotate twice, turn on the low beam, rotate once, turn on the driving light USB charging port Tow switch...
-
Page 15: The Wind S Series
2. The WIND S Series Interior LED Screen Battery Indicator Speedo Meter, Voltage Indicator Power Indicator, Start Speedometer MP3/FM player, Switch Odometer Speaker Trip-meter Screen Headlight USB Port Switch & Horn Steering Wheel Direction Switch Glove Box with Key Lock Glove Box with Key Lock Audio System... -
Page 16: The Wind T Series
3. The WIND T Series Interior Multi Media, 9 Inch Screen, SOS Indicator, Voltage Indicator, Start Switch USB Portal odometer, Trip-meter Direction Glove Box with Switch key lock Steering Wheel Speedo Meter, Power Indicator, MP3/FM player, Speaker Parking Pedal Lock 4 Cup Holder Brake Pedal Acceleration Pedal... -
Page 17: Maintenance Items And Cycle
Maintenance items and cycle 1. The Z series 2. The WIND S series 3. The WIND T series 1 month or 3 months or 6 months or 12 months or Maintenance items Weekly 1,000 KM 3,000 KM 6,000 KM 12,000 KM Electrolysis level height ●...
