Summary of Contents for Soldano ASTRO-20
- Page 2 INSTRUCTIONS Please keep this instruction manual for future reference and for the duration of owning this Soldano Amplifier. Please carefully read and understand the instructions inside this user’s manual before attempting to operate your new amp. This instruction manual includes essential safety information regarding the use and maintenance of the amplifier.
- Page 3 8. Heat – Amplifier should be situated away from heat sources such as radiators, heat registers, stoves, or other amplifiers (including audio amplifiers) that produce heat. 9. Power Sources – This product should be operated only from the type of power source indicated on the rating label.
- Page 4 20. Accessories – Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product.
- Page 5 Thank you for choosing the SOLDANO ASTRO-20. The ASTRO-20 is an incredibly versatile, multi-channel and multi-function all-tube guitar amplifier, designed to be used in a multitude of ways including: 1) Full-featured 20W guitar amplifier 2) Stand-alone cab-less amplifier ideal for both live and studio recording sessions...
-
Page 6: Front Panel Controls And Connections
While some amps only sound good with the EQ in a small range, the ASTRO-20 offer LOTS of colors that can be dialed in with the powerful EQ. so use it! -
Page 7: Rear Panel Controls And Connections
Important - ALWAYS aet the master level to zero before powering ON and slowly turn the master up to avoid excessive sound pressure level (SPL) on your ears. 5. FOOTSWITCH/MIDI IN - Midi connector to control the ASTRO-20 amplifier with an external MIDI device or the provided 4-button footswitch. (Default channel is OMNI). - Page 8 It can be powered externally when using it with a 5 WIRE MIDI CABLE or when using it with another device. SOLDANO EDITOR SOFTWARE Please visit www.soldano.com to download the Soldano Editor software. The ASTRO-20 features an easy-to-use software that allows you to upload your own IR’S, program all MIDI presets and MIDI functionalities.
- Page 9 INCLUDED IR’S 412 V30 Handcrafted in epic purple the Soldano 412 stands ready for the stage. Fitted with the iconic Vintage 30 speaker it's a perfect pairing for Soldano tones. Mics used SM57 & 1973. UK 412 V30 This British 4x12 cabinet is a classic closed back cab with Baltic birch, tongue and groove construction. It features a balanced V30 tone great for any style of music.
-
Page 10: Top Panel Controls
IR BYPASS – this bypassed the internal IR cabinet simulation allowing you to use external simulation devices or software. MIDI CHANNEL SELECTOR will program the MIDI INPUT channel the ASTRO-20 will use. Default is OMNI mode (ASTRO-20 will listen to all channels) INCLUDED FOOTSWITCH MIDI CHANNEL IS 1. - Page 11 Soldano product, please refer to the warranty below. Soldano offers a limited 5-year warranty to the original purchaser that this Soldano product will be free from defects in material and workmanship. A dated sales receipt will establish coverage under this warranty, PLEASE KEEP YOUR PROOF OF PURCHASE TO USE YOUR WARRANTY.
- Page 12 INCIDENTAL OR CONSEQUENTIAL DAMAGE: In no event will Soldano be liable for any incidental or consequential damages arising out of the use or inability to use of any Soldano product, even if a Soldano dealer has been advised of the possibility of such damages, or any other claim by any other party. Some states do not allow the exclusion or limitation of consequential damages, so the above limitation and exclusion may not apply to you.
