- Page 1 EPD-2501 Public Information Display (Digital Signage) Quick Reference Guide Ed – 15 August 2023 Copyright Notice Copyright © 2023 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017E511A0R...
- Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ 2 EPD-2501 Quick Reference Guide...
-
Page 3: Table Of Contents
1.2 Packing List ....................... 4 1.3 System Specifications ....................5 1.4 System Overview ...................... 7 1.5 System Dimensions ....................8 Hardware Configuration ..................9 2.1 EPD-2501 connector mapping ................10 2.1.1 Serial port connector (COM) ....................10 EPD-2501 Quick Reference Guide... -
Page 4: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x EPD-2501 Public Information Display (Digital Signage) ⚫ 1 x Power Adapter ⚫... -
Page 5: System Specifications
3 x LED indicator for power & Storage Mechanical Power Type Power Input: +12V/5A (60W) (accept +12V DC in) Power Connector Lockable DC Jack Type Dimension 594.7 x 349.7 x 38.8 mm Weight 4.4kg Color Black EPD-2501 Quick Reference Guide... - Page 6 Drop Test ISTA-2A, IEC-60068-2-32 (96.5cm) Operating 15 ~ 30°C Temperature Operating Humidity 30°C @ 95% Relative Humidity, Non-condensing Storage -25 ~ 60°C Temperature Other Test Front IP65 Note: Specifications are subject to change without notice. 6 EPD-2501 Quick Reference Guide...
-
Page 7: System Overview
Power Switch for LT1000 Power Switch for LT1000 DC-IN DC Power-in connector LED indicator 2 x LED indicator Serial port connector HDMI HDMI connector USB3.1 4 x USB3.1 connector 2 x RJ-45 Ethernet Power Switch Power Switch EPD-2501 Quick Reference Guide... -
Page 8: System Dimensions
EPD-2501 1.5 System Dimensions (Unit: mm) 8 EPD-2501 Quick Reference Guide... -
Page 9: Hardware Configuration
Quick Reference Guide 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw EPD-2501 Quick Reference Guide... -
Page 10: Epd-2501 Connector Mapping
EPD-2501 2.1 EPD-2501 connector mapping 2.1.1 Serial port connector (COM) Signal PIN PIN Signal NDCD# NDSR# NRXD NRTS# NTXD NCTS# NDTR# NRI# 10 EPD-2501 Quick Reference Guide...
