- Page 1 PANEL HEATER INSTRUCTION MANUAL (wall mounted only) - 1 -...
- Page 2 SYMBOLS Warning This signal word indicates a hazard with an average risk level which, if not avoided, can result in serious injury or death. Warning of electrical voltage This symbol indicates dangers to the life and health of persons due to electrical voltage. Symbols Meaning This symbol located on the device indicates that it is...
-
Page 3: Table Of Contents
CONTENT 1┃WARNING & PRECAUTION 2┃FEATURES 3┃TECHNICAL INFORMATION 4┃SCOPE OF SUPPLY 5┃DEVICE STRUCTURE 6┃INSTALLATION 7┃TROUBLESHOOTING 8┃MAINTENANCE & SERVICING 9┃STORAGE 10┃TECHNICAL ANNEX 11┃DISPOSAL - 3 -... -
Page 4: 1┃Warning & Precaution
1┃WARNING & PRECAUTION Read this manual carefully before starting or using the device. Always store the manual in the immediate vicinity of the device or its site of use! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and / or serious injury. - Page 5 supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance. Warning Do not use the device in small rooms if persons are present who cannot leave the room independently and...
- Page 6 • Do not use the device in potentially explosive rooms. • Do not use the device in aggressive atmosphere. • Set the device up in an upright and stable position. • Let the device dry out after a wet clean. Do not operate it when wet.
- Page 7 • Insert the mains plug into a properly secured mains socket. • Do not use the device when the socket or wire overloaded. • Observe the device's power input, cable length and intended use when selecting extensions to the power cable. Completely unroll extension cables.
-
Page 8: 2┃Features
• Do not place the device on combustible ground. • Do not transport the device during operation. • Do not touch the surface during the device working to avoid burns. • Allow the device to cool down before transport and / or maintenance work. -
Page 9: 3┃Technical Information
3┃TECHNICAL INFORMATION Heating element Carbon Heating way Far infrared heating Voltage 220-240V/50Hz Surface temperature Main 70-90℃ Surface Tempered Glass or mirror IP grade IP54 (exclude plug) Over heating protection Power cord length 1.9m 4┃SCOPE OF SUPPLY • 1 x heating device •... -
Page 10: 5┃Device Structure
5┃DEVICE STRUCTURE Designation 1 Surface(glass or mirror) 2 Heating element 3 rear metal sheet 4 Wall attachment 5 Power cord 6 Junction box - 10 -... -
Page 11: 6┃Installation
6┃INSTALLATION Make sure remove all the protective films(both on the front and back)! 1. Choose the mounting position, keep the required minimum distances. Distances required for device mounting front Minimum 30cm left Minimum 10cm right Minimum 10cm Minimum 50cm Mark the positions for the bore holes onto the drilling template (D) if there are no existing marks. - Page 12 4. Hang the infrared heating device (A) in. 5. Slid the device to make the screws into the correct positions as showing in below drawing. 6. Plug in to start using the heating device . Do pull out the plug when not in use . - 12 -...
-
Page 13: 7┃Troubleshooting
7┃TROUBLESHOOTING Problem Reason Measure It has noise when Due to the structure stress It is a normal original charged with of the heat insulator. phenomenon. electricity Don't worry about it. The surface of the 1. The voltage is low. 1. Install a voltage heating device isn’t 2. -
Page 14: 9┃Storage
• with a cover to protect it from invasive dust, if necessary • Place no further devices or objects on top of the device to prevent it from being damaged. 10┃TECHNICAL ANNEX Voltage Rated Power Model NO. Size(cm) Frequency Current G0606X 60*60*1.2 1.4A G0806X 80*60*1.2 2.0A 230V/50HZ G1006X 100*60*1.2 2.5A G1206X 120*60*1.2... - Page 15 (Pnom)/ (Pmax.c)/ (elmin)/ (Pmin)/ (elmax)/ (KW) (KW) (KW) (KW) (KW) aGT-G0606X 0.335 aGT-G0806X 0.470 aGT-G1006X 0.608 aGT-G1206X 0.732 aGT-G1008X 0.836 Information requirements for electrical local space heaters Item Unit Type of heat input, for electric storage local space heaters only (select one)
-
Page 16: 11┃Disposal
electronic room temperature control plus day timer [no] electronic room temperature control plus week timer [yes] Other control options (multiple selections possible) room temperature control, with presence detection [no] room temperature control, with open window detection [no] with distance control option [no] with adaptive start control [yes]...
