Summit 908300GA Owner's Manual

Capacity: 1,000 lbs. geared engine stand
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

OWNER'S MANUAL
CONTENTS:
Page 1 Specifications
3 Setup, Operating Instructions and Preventative Maintenance
4 Warranty
5 Exploded View Drawing and Replacement Parts
908300GA

SPECIFICATIONS

Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,000 Lbs.
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38.58"
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35.83"
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93 lbs.
GEARED ENGINE STAND
1
MODEL 908300GA
CAPACITY: 1,000 LBS.
© Copyright 2012, Summit Racing
rev. 06/11/12
