- Page 1 INSTRUCTION MANUAL The REPEX « Original » edge sander Reference 4 REPEX FLOOR SAS Tel : +33(0)1 46 80 03 92 2, Avenue de Roses Fax : +33(0)1 46 80 12 09 Parc D’activité des Petits Carreaux info@repex.fr 94380 - BONNEUIL-SUR-MARNE...
-
Page 2: Table Of Contents
SOMMRY 1.GENERAL _______________________________________________________________________________3 INFORMATIONS ABOUT THE INSTRUCTIONS ________________________________________________ 3 MANUFACTURER _________________________________________________________________________ 3 RESPONSIBILITY AND GUARANTEE _________________________________________________________ 3 THE PICTOGRAMS PRESENT ON THE MACHINE ______________________________________________ 4 _________________________________________________________________________________________ 4 2.THE "ORIGINAL" EDGE SANDER __________________________________________________________5 3.RECEPTION OF THE MACHINE ____________________________________________________________5 4.STORAGE _______________________________________________________________________________5 5.OVERVIEW ______________________________________________________________________________6 6.TRANSPORT ____________________________________________________________________________5 7.INITIAL OPERATION ______________________________________________________________________6 INSTRUCTIONS FOR THE ELECTRICAL CONNECTION ________________________________________ 6... -
Page 3: General
NOTE: The schematic representations of this manual may be slightly different from the model in your possession. MANUFACTURER Adresse : Contact : REPEX FLOOR Tél : +33 (0)1 46 80 03 92 2, Avenue de Roses Fax : +33 (0)1 46 80 12 09 e-mail : info@repex.fr... -
Page 4: The Pictograms Present On The Machine
Any claim must include details on the use of the item, the date of purchase. For machines, the guarantee means parts and labour after return to the factory REPEX Floor SAS Liability is limited only to goods supplied by REPEX Floor SAS and does not apply to damage, injury or loss of income from a defective component. -
Page 5: The "Original" Edge Sander
2. THE "ORIGINAL" EDGE SANDER The edge sander model "Light" is an easy to use machine for professional use. This machine is designed for sanding parquet on the edges of rooms and the underside of radiators. The motor is a universal type, so it is recommended to use it for 20 to 30 minutes at a time. It is also recommended not to put too much pressure on the machine. -
Page 6: Overview
Do not operate the machine if the power plug or power cord is damaged, as there is a danger of death from electric shock. If the cables or plugs are worn or damaged, have them replaced by the manufacturer or by the REPEX FLOOR customer service User Manual– The “ORIGNAL” Edge sander... -
Page 7: Cables, Extensions And Plugs
MACHINE WITH SINGLE-PHASE 230V MOTOR. ~50-60Hz For Europe, the power supply cable must be of type E/F approved CEE designation 7/7-3x2.5 mm For versions other than the European version, consult REPEX FLOOR or an authorized distributor. INSTRUCTIONS FOR PLACING THE SUCTION SKIRT DANGER : The sanding dust may spontaneously ignite and cause injury or damage. -
Page 8: Instructions For The Installation Of The Abrasive Disc
INSTRUCTIONS FOR THE INSTALLATION OF THE ABRASIVE DISC WARNING : The machines must not be connected to the electrical network to perform this manoeuvre. WARNING : The installation of the abrasive disc is made easier by the so-called Velcro base. Use only "... -
Page 9: Instructions For Sanding Surface
INSTRUCTIONS FOR SANDING SURFACE The two stabilizing rolls are adjustable in height and can be easily removed for cleaning by unscrewing the "PAL" type lock nuts on the top of the castor supports. This adjustment is carried out at the factory in such a way that the right front part of the machine is in contact with the floor. - Page 10 Make sure all signs, decals, warnings, precautions, and instructions are attached to the machine. Obtain new plates from REPEX FLOOR or any authorized REPEX distributor. Do not have any repairs carried out by unauthorized personnel there is a risk of CAUTION : personal injury or property damage.
-
Page 11: Instructions For The Correct Use Of The Machine
CAUTION : If stored in a damp building, the machine may be damaged. Store the machine in a dry building. INSTRUCTIONS FOR THE CORRECT USE OF THE MACHINE The machine is suitable for professional use. The information contained in this instruction manual highlights potentially dangerous conditions for the operator and/or the machine. -
Page 12: Information About The Machine
10. INFORMATION ABOUT THE MACHINE NON-CONSENSUAL USE CAUTION : The machine has been designed for sanding wooden floors only. 11. INSTRUCTIONS FOR STARTING UP THE MACHINE To start the machine, follow the steps below: 1. Familiarize yourself with the machine and read all instructions regarding hazards, warnings and precautions. -
Page 13: Regular Maintenance
While holding the adjustment firmly, tighten the two nuts by 13. 13. SPARE PARTS Always use original REPEX FLOOR spare parts. The guarantee and the consequent liability are invalidated if non-original spare parts are used and if repairs or adjustments are carried out by unauthorized persons. - Page 14 Burns on the work surface Worn sanding belt Replace the abrasive disc Excessive disc pressure Decrease the sanding pressure by pressing the machine less strongly Abrasive too fine Use a thicker abrasive User Manual– The “ORIGNAL” Edge sander...
