Instructions

DP75

Microscope digital camera

Note

This instruction manual is for DP75.

To ensure safety, and obtain optimum performance of this product, we

recommend that you study this manual thoroughly before operating this

product, and always keep this manual at hand when this product is in use.

Optical Microscope Accessory

Retain this instruction manual in an easily accessible place near the work

desk for future reference.

For details of products included in the configuration of this system, see page

A M 5 5 5 4

12.

Table of Contents

Need help?

Do you have a question about the DP75 and is the answer not in the manual?

Questions and answers

Summary of Contents for Evident DP75

Page 1 DP75 Microscope digital camera Note This instruction manual is for DP75. To ensure safety, and obtain optimum performance of this product, we recommend that you study this manual thoroughly before operating this product, and always keep this manual at hand when this product is in use.
Page 2 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Responsible Party Name: EVIDENT SCIENTIFIC, INC. Address: 48 Woerd Ave Waltham, MA 02453, U.S.A. Phone Number: 781-419-3900...
Page 3: Table Of Contents
Contents 1. Introduction 2. Safety Precautions 2.1 General 2.2 Installation 2.3 Electric shock prevention 2.4 Electrical safety 2.5 Injury prevention 2.6 Preventing burn 2.7 Safety-related labels on the product 2.8 Cautions and labels 2.9 Handling Instructions 2.10 Cyber security 3. Restrictions 3.1 Specifications subject to restrictions depending on the combination 3.1.1 Restriction condition 3.2 Specifications subject to restrictions depending on usage conditions...
Page 4 8. Summary of steps to acquire the images 9. IR cut filter insertion/removal function 10. External triggering function 11. Maintenance 11.1 Cleaning each part 11.2 Cleaning IR cut filter 12. Troubleshooting 13. Specifications 13.1 Basic specification table 13.2 Table of setting items by software 13.3 Operating environment 14.
Page 5: Introduction
DP75 Introduction The Microscope Digital Camera DP75 is a product to acquire and process digital images, which is attached to our microscopes using a C mount camera adaptor made by our company. The product will not work if a C mount adaptor made by other manufacturer or the product is attached to a microscope made by other company.
Page 6 How to read this instruction manual This instruction manual is structured as follows. First level title ⚪⚪⚪⚪⚪⚪⚪⚪ ⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪ ⚪ Second level title 6.1⚪⚪⚪⚪⚪⚪⚪⚪ ⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪⚪ Third level title 6.1.1⚪⚪⚪⚪⚪⚪⚪⚪ Operating procedure Loosen the clamping screw with a screwdriver. 1.,2... refer to operating procedures. (A),(B)...
Page 7 DP75 Trademark Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Intel and Intel Core are trademarks of Intel Corporation or its subsidiaries in the United States and/or other countries.
Page 8: Safety Precautions
Safety Precautions Please use the product in accordance with this instruction manual. If the product is used in a manner not specified manufacturer, the protection provided by product may be impaired. And it may also cause the malfunction of this product.
Page 9: Electrical Safety
DP75 Keep the power cord and cables well away from the lamp house If the power cord or cables gets in contact with the high temperature part of the lamp house, the cord may melt, which could result in an electric shock.
Page 10: Safety-Related Labels On The Product
Avoid prolonged contact with the product The camera head heats up when used for a long time. To prevent low-temperature burns, avoid prolonged direct skin contact with the camera head. 2.7 Safety-related labels on the product The following symbols are placed on this product. Study the meaning of the symbols and always use the product in the safest possible manner.
Page 11: Restrictions
DP75 Restrictions 3.1 Specifications subject to restrictions depending on the combination 3.1.1 Restriction condition 1. Graphic cards Depending on the type of graphic card used, the highest frame rate for live images may not be ensured. 2. Controller The controller's installation software in the factory settings is in the scope of warranty. Malfunctions due to changes in PC environment settings (BIOS changes), OS updates, and installation of third-party software by the customer are not covered by the warranty.
Page 12: Specifications Subject To Restrictions Depending On Usage Conditions
2. When observing a sample with weak fluorescence with the IR cut filter removed (or without a sample), flare may be conspicuous that depends on the characteristics of the mirror unit if light sources that use a mercury lamp are combined. 3.
Page 13: Image Data
DP75 3.2.3 Image data Please bear in mind the following matters about image data. 1. The recorded image data may be lost (corrupted) in the following cases. Please note that we are not liable for any loss (damage) of recorded data.
Page 14 Part of the imaging range is off the created map Stage movement just before or after switching objectives In addition, switching optical elements such as mirror unit cassettes and condensers, and switching optical paths in components such as a trinocular tube etc., may be mistakenly detected as switching objective lenses.
Page 15: Pc Combination
DP75 3.2.5 PC combination 1. Requirement of PC to be combined item Specifications Intel Core i5, Intel Core i7, Intel Xeon, or equivalent 8GB or more (16GB or more recommended) Internal storage Free space: 5GB or more Graphics 1280x1024 or higher monitor resolution, video card capable of 32-bit color output *Onboard graphics also available USB 3.1 gen2(TypeA) gen1 (5Gbps) port also available...
Page 16: System Chart
System chart Power cord Monitor AC adapter IR cut filter Insertion/remo val knob Interface cable (USB) DP75 Camera head External trigger (Shutter unit etc.) C mount Camera adapter 4. System chart...
Page 17: Nomenclatures
DP75 Nomenclatures NOTE: Use products that are designated by our company or comply with the requirements of IEC60950 CISPR22.24 (international standard for equipment safety) when connecting them to this product. If other products are connected, complete performance cannot be guaranteed.
Page 18: Assembly
Assembly 6.1 Attaching the IR cut filter insertion/removal knob The assembly in this chapter is not necessary if you are not observing fluorescence in the NIR (near infrared) wavelength range. When using it, use a microscope that supports NIR observation. 1.
Page 19: Mounting The Camera Head
DP75 6.2 Mounting the camera head NOTE: Do not touch the C mount thread (c) because it has sharp edges. When attaching or removing the camera head or the C mount camera adapter, be careful not to drop them. Screw the C mount camera adapter into the camera head firmly. If it is attached loosely, the camera head may drop during operation or the sufficient performance may not be obtained when acquiring the image.
Page 20 TIP: Operate the screw (LOCK) (E) and screw (CENTERING) (D) when adjusting parfocality. Set the C-mount camera adapter to an appropriate direction so that the screw (CENTERING) is easy to operate. Be sure to adjust parfocality between the C-mount camera adapter and the eyepiece. Otherwise, either the image through the eyepiece or that of the camera may not stay in focus.
Page 21: Connecting The Interface Cables
DP75 6.3 Connecting the interface cables CAUTION: Be sure to turn off the power of the PC before connecting the interface cable. Be sure to use the interface cable that comes with this product. Only then can the functionality of the product and compliance with EMC basic standards be guaranteed.
Page 22: Connecting Ac Adapter
1. Insert the BNC cable connector of the external device into the DP75 BNC cable jack (A). NOTE: The software cellSens/PRECiV is necessary to use the external trigger function. 6.5 Connecting AC adapter 1. Plug the power cord (A) into the power cord connector (B) on the AC adapter.
Page 23: Installing Software
(For information on changing user accounts, refer to Windows® Help. ) 7.3 The TWAIN driver DP2-TWAIN This product does not include DP2-TWAIN. Download the installer from the Evident website to use it. When using DP2-TWAIN on a 64-bit OS, commercially available native 64-bit application software that supports TWAIN is required.
Page 24 PRECiV When selecting a device with PRECiV, make settings in the device list as shown below. The device list is displayed on the first run of PRECiV. Alternatively, select [Settings]->[Device]->[Device List] on the menu bar to display the list. Please refer to PRECiV help section for more information about settings. 7.
Page 25: Summary Of Steps To Acquire The Images
For details on the usage instruction, refer to the instruction manual or help section of the software used. In addition, DP75 can set an optimal imaging condition according to an observation method that is automatically identified by AI function. The identifiable observation methods are BF, FL, DIC, PH and PO. For details, see the help section of the software used.
Page 26 Fluorescent observation Examples of steps to acquire the images under fluorescence observation 8. Summary of steps to acquire the images...
Page 27: Ir Cut Filter Insertion/Removal Function
IR cut filter insertion/removal function In the DP75, by pulling the IR cut filter insertion/removal knob, the IR cut filter can be removed from the optical path and observation images at long wavelengths (up to approximately 1,000 nm) can be acquired. Do not stop pulling out the insertion/removal knob in the middle, and pull it until it cannot be pulled out anymore.
Page 28: External Triggering Function
External triggering function DP75 can acquire still images and control a commercially available shutter with external triggering signals. Trigger input By inputting a trigger signal from an external device, a still image can be captured with cellSens/PRECiV. When an edge signal is detected, images are captured with a pre-set exposure time. CellSens/PRECiV can be used to switch the signal between positive and negative logics.
Page 29: Maintenance
DP75 Maintenance 11.1 Cleaning each part Do not leave stains or fingerprints on the lenses and filters. If they get soiled, blow away dust with a commercially available blower and gently wipe the lenses or filters with a piece of cleaning paper (or washed-out clean gauze).
Page 30: Cleaning Ir Cut Filter
11.2 Cleaning IR cut filter If there is noticeable dirt such as dust on the IR cut filter Follow the steps below to clean the IR cut filter. 1. Use your Phillips screwdriver to remove the screws (2 M3 screws) (A). 2.
Page 31: Troubleshooting
DP75 Troubleshooting If problems occur, please review the following list and take remedial action as needed. If you cannot solve the problem after checking the entire list, please contact our local distributor for assistance. Phenomena Cause Remedy Page Software will not start.
Page 32 Phenomena Cause Remedy Page value. appropriate exposure correction value. A dark part of an image is set as Set a part of the image you (Online a photometry area. want to measure as the help) photometry area. The AE lock remains unchanged Release the AE lock.
Page 33 DP75 Phenomena Cause Remedy Page adjusted with manual white manual white balance so that help) balance. the color is appropriate. The black balance reference Select a blank black area as (Online area is not properly selected. the black balance reference help) area.
Page 34 Check the USB3.1 port on the PC and connect the camera to it. Flashing continuously There is a camera error. Contact an Evident distributor. No lighting up The camera is not connected to the PC with the USB cable, or the AC adapter is not connected.
Page 35 If you cannot solve your problem even after taking the actions listed in the troubleshooting section, contact an Evident distributor for assistance. At that time, please tell them the following information as well. Product name and abbreviation (A) (Ex.: Camera head (product name) DP75 (model name))
Page 36: Specifications
Specifications 13.1 Basic specification table Items marked with "★ " in the table below have different setting items depending on the software used. For details, refer to the setting item table for each software. Item Specifications Camera method Single chip color camera Image sensor Format 1.1 type 12.37 Mega pixel color CMOS...
Page 37 DP75 Item Specifications 2048 x 1500 (1 x 1): 44 fps 1920 x 1080 (1 x 1): 60 fps Still image capturing time (from start 8192 x 6000 (pixel shift): about 3 seconds of capturing to display) 4096 x 3000 (3CMOS mode): about 2 seconds 4096 x 3000 (1 x 1): about 1.2 seconds...
Page 38 Item Specifications Preview image quality mode (*1) Standard, Medium, High Movie <File format> AVI/VSI (Uncompressed, Motion JPEG, MPEG) <Number of recording frames*> 4096 × 2160: 58 flame 2048 × 1500: 232 flame 1920 × 1080: 344 flame *For uncompressed 8 bit RGB color *Recording time depends on frame rate Dimensions/mass Camera head...
Page 39: Table Of Setting Items By Software
DP75 13.2 Table of setting items by software function Interval shooting Color space designation External trigger Software Position navigator LiveHDR Image integration 10 bit still image capture Scene recognition Instant MIA cellSens ENTRY STANDARD (Ver.4.2.1 or later) DIMENSION PRECiV Capture Core (Ver.2.1 or later)
Page 40: Operating Environment
13.3 Operating environment Item Specifications Operating Indoor use environment Altitude: Max. 2000 meters Temperature: 5 to 40 °C Relative humidity: Up to 80% ( up to 31 °C) (no condensation) If over 31 °C, humidity in use environment decreases linearly through 70% (34 °C) to 60% (37 °C) to 50% (40 ℃).
Page 41: Proper Selection Of The Power Supply Cord
DP75 Proper selection of the power supply cord If no power supply cord is provided, please select the proper power supply cord for the equipment by referring to “Specifications” and “Certified Cord” below: Caution : In case you use a non-approved power supply cord for our products, we can no longer warrant the electrical safety of the equipment.
Page 42 Table 2 HAR flexible cord Approval organizations and cordage harmonization marking methods. Alternative marking utilizing Printed or embossed black-red-yellow thread harmonization marking (May be (Length of color section in Approval organization located on jacket or insulation of internal wiring) Black Yellow Comite Electrotechnique Belge CEBEC...
