Page 1 BG-AVTPG-8K HDMI 2.1 8K Video Test Pattern Generator and Analyzer User Manual...
Page 2 BZBGEAR BG-AVTPG-8K PRODUCT MANUAL · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
Page 3: Table Of Contents
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL TABLE OF CONTENTS Statement Safety Precaution Introduction Features Packing List Speciﬁcations Operation Controls and Functions Connection Diagram Signal Generator Mode Signal Analyzer Mode HDCP Test Modes EDID Analysis Mode Tech Support Warranty Mission Statement Copyright ·...
Page 4: Statement
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Statement Please read these instructions carefully before connecting, operating, or conﬁguring this product. Please save this manual for future reference. Safety Precaution ● To prevent damaging this product, avoid heavy pressure, strong vibration, or immersion during transportation, storage, and installation.
Page 5: Introduction
PRODUCT MANUAL Introduction The BG-AVTPG-8K is an HDMI 2.1 signal generator and analyzer that is an essential and versatile tool designed for integrators. It supports the full bandwidth of HDMI 2.1 and HDCP 2.2 ensuring the installation and troubleshooting process is easier than ever before.
Page 6: Packing List
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Packing List ● 1x BG-AVTPG-8K ● 1x 12V DC Adapter ● User Manual Speciﬁcations Technical Speciﬁcations HDMI Compliance HDMI 2.1 and below HDCP Compliance HDCP 2.3 and below Up to 8K60 4:2:0 8 bits, 8K30 4:4:4, 4K2K@120Hz &...
Page 7: Operation Controls And Functions
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Operation Controls and Functions Front and Rear Panel 1. OUTPUT: HDMI output to Display or Sink device 2. INPUT: HDMI input from source device 3. USB: Connect to USB device for mouse control, uploading user created test patterns, EDID information, and ﬁrmware updates.
Page 8: Connection Diagram
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Connection Diagram · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
Page 9: Signal Generator Mode
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Signal Generator Mode After making the physical connections between BG-AVTPG-8K and the display device. Users can select diﬀerent generator functions to display on the sink device for testing purposes. 1. The “Signal Format” menu provides diﬀerent signal resolutions, frequency, and signal types (TV / PC) for the user to select.
Page 10: Signal Analyzer Mode
HDCP Test Modes Signal Analyzer 1. When the BG-AVTPG-8K is set as a signal analyzer it can verify HDCP of a video source or other devices under test. 2. There are 3 options: HDCP 1.4, HDCP 2.2, and No HDCP.
Page 11: Edid Analysis Mode
1. Ensure the connections between the BG-AVTPG-8K output and display/sink device are properly connected. 2. Connect a USB storage device to the USB port of the BG-AVTPG-8K 3. Select EDID from the “Sink Test” menu. 4. Touch the “Save” button to get the EDID information of the display device and save it to the connected USB drive.
Page 12 1. Save the EDID ﬁle to the root directory of a USB drive and name it as “edid_raw.bin (binary format)” 2. Connect the USB storage device to the USB port of the BG-AVTPG-8K 3. Select EDID from the “Sink Test” menu.
Page 13: Tech Support
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Tech Support Have technical questions? We may have answered them already! Please visit BZBGEAR’s support page (bzbgear.com/support) for helpful information and tips regarding our products. Here you will ﬁnd our Knowledge Base (bzbgear.com/knowledge-base) with detailed tutorials, quick start guides, and step-by-step troubleshooting instructions.
Page 14: Warranty
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Warranty BZBGEAR Pro AV products and cameras come with a three-year warranty. An extended two-year warranty is available for our cameras upon registration for a total of ﬁve years. For complete warranty information, please visit bzbgear.com/warranty.
Page 15: Mission Statement
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Mission Statement BZBGEAR is a breakthrough manufacturer of high-quality, innovative audiovisual equipment ranging from AVoIP, professional broadcasting, conferencing, home theater, to live streaming solutions. We pride ourselves on unparalleled customer support and services. Our team oﬀers system design consultation, and highly reviewed technical support for all the products in our catalog.
Page 16: Copyright
BZBGEAR BG-AVTPG-8K PRODUCT MANUAL Copyright All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product speciﬁcation and information in this manual is for reference only and subject to change...
