MW TOOLS LA1801 Manual

Welding fume extractor
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
M1.3.LA1801.NLFREN 19122019
Aspirateur de fumée de soudage
P.02 Gelieve te lezen en voor later gebruik bewaren
NL
P.06 Veuillez lire et conserver pour consultation ultérieure
FR
P.10 Please read and keep for future reference
EN
HANDLEIDING - MODE D'EMPLOI - MANUAL
LA1801 (829000140)
Lasrookafzuiger
Welding fume extractor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LA1801 and is the answer not in the manual?

Questions and answers

Related Manuals for MW TOOLS LA1801

Summary of Contents for MW TOOLS LA1801

  • Page 1 M1.3.LA1801.NLFREN 19122019 HANDLEIDING - MODE D’EMPLOI - MANUAL LA1801 (829000140) Lasrookafzuiger Aspirateur de fumée de soudage Welding fume extractor P.02 Gelieve te lezen en voor later gebruik bewaren P.06 Veuillez lire et conserver pour consultation ultérieure P.10 Please read and keep for future reference...

  • Page 2: Table Of Contents

    M1.3.LA1801.NLFREN 19122019 Inhoud 1 Veiligheid ................................2 1.1 Veiligheidsvoorschriften ..........................2 2 Omschrijving ................................. 3 3 Technische specificaties ............................3 4 Installatie................................3 4.1 Het toestel uitpakken en controleren ......................3 4.2 Veiligheid bij de installatie .......................... 4 4.3 De afzuigslang assembleren ........................4 4.4 Elektrische aansluiting ..........................

  • Page 3: Omschrijving

    M1.3.LA1801.NLFREN 19122019 2 Omschrijving 2.1 DESCRIPTION AND OPERATION The fume extractor is designed to provide high efficiency filtration of fume generated during welding processes. De rookafzuiger is ontworpen voor een zeer efficiënte filtratie van de rook die tijdens het lassen vrijkomt. De verontreinigingen contaminants are captured at the source through the extraction arm hood, clean air is then recirculated back to the worden bij de bron door de slang opgevangen, en schone lucht wordt vervolgens naar de werkruimte geblazen.

  • Page 4: Veiligheid Bij De Installatie

    M1.3.LA1801.NLFREN 19122019 4.2 Veiligheid bij de installatie Deze rookafzuiger bestaat uit een afzuigslang en een mobiele afzuiger op wielen, en moet geassembleerd worden voor gebruik. Lees de volgende veiligheidsvoorschriften voor de installatie en het gebruik dan uw rookafzuiger. WAARSCHUWING! •...

  • Page 5: Onderhoud

    M1.3.LA1801.NLFREN 19122019 ear appropriate protective clothing. llected particulate may be hazardous. Consult proper authorities for handling and disposal. 6 Onderhoud sposal of collected particulate must be according to federal, state and local regulations and all appropr authorities.

  • Page 6: Sécurité

    M1.3.LA1801.NLFREN 19122019 Table des matières 1 Sécurité .................................6 1.1 Consigne de sécurité ..........................6 2 Description ................................7 3 Spécifications techniques ............................7 4 Installation ................................7 4.1 Déballage et inspection de l’appareil ......................7 4.2 Sécurité lors de l’installation ........................8 4.3 Assemblage du tuyau d’aspiration ........................8 4.4 Branchement électrique ..........................8...

  • Page 7: Description

    M1.3.LA1801.NLFREN 19122019 2.1 DESCRIPTION AND OPERATION 2 Description The fume extractor is designed to provide high efficiency filtration of fume generated during welding processes. L’aspirateur de fumée est conçu pour offrir une filtration très efficace de la fumée dégagée pendant le soudage. Les contaminants are captured at the source through the extraction arm hood, clean air is then recirculated back to the contaminants sont capturés à...

  • Page 8: Sécurité Lors De L'installation

    M1.3.LA1801.NLFREN 19122019 4.2 Sécurité lors de l’installation Cet aspirateur de fumée est composé d’un tuyau d’aspiration et d’un aspirateur mobile sur roues, et doit être assemblé avant son utilisation. Lisez les consignes de sécurité suivantes avant d’installer et d’utiliser l’aspirateur de fumée.

  • Page 9: Entretien

    M1.3.LA1801.NLFREN 19122019 llected particulate may be hazardous. Consult proper authorities for handling and disposal. sposal of collected particulate must be according to federal, state and local regulations and all appropr 6 Entretien authorities. • Coupez l’alimentation électrique avant de commencer l’entretien.
  • Page 10 M1.3.LA1801.NLFREN 19122019 Contents 1 Safety ................................... 2 1.1 Safety instructions ............................2 2 Description ................................3 3 Technical specifications ............................3 4 Installation ................................3 4.1 Equipment off loading and inspection ......................3 4.2 Installation safety ............................4 4.3 Extraction arm assembly ..........................4 4.4 Electrical installation ...........................

  • Page 11: Description

    M1.3.LA1801.NLFREN 19122019 2.1 DESCRIPTION AND OPERATION 2 Description The fume extractor is designed to provide high efficiency filtration of fume generated during welding processes. The fume extractor is designed to provide high efficiency filtration of fume generated during welding processes. Contaminants contaminants are captured at the source through the extraction arm hood, clean air is then recirculated back to the are captured at the source through the extraction arm hood, clean air is then recirculated back to the working area.

  • Page 12: Installation Safety

    M1.3.LA1801.NLFREN 19122019 4.2 Installation safety This fume extractor consists of an extraction arm and mobile fume extractor on casters and requires some assembly before operation. Please review and consider the following safety information prior to installing and operating the fume extractor.

  • Page 13: User Servicing Instructions

    Consult proper authorities for handling and disposal. M1.3.LA1801.NLFREN 19122019 sposal of collected particulate must be according to federal, state and local regulations and all appropr authorities. 6 User servicing instructions • Disconnect electrical power prior to servicing equipment.

  • Page 14: Déclaration De Conformité Ce

    M1.3.LA1801.NLFREN 19122019 9 EG conformiteitsverklaring 9 Déclaration de conformité CE 9 EC declaration of conformity Vynckier Tools sa Fabrikant/Invoerder Fabricant/Importateur Avenue Patrick Wagnon, 7 Manufacturer/Retailer ZAEM de Haureu B-7700 Mouscron Verklaart hierbij dat het volgende product : Déclare par la présente que le produit suivant :...
