- Page 1 WWW.FUHR.DE SmartTouch Access control system with KeylessGo technology Art. no.: 9411577/Reference: VNB968 Installation, operating and maintenance manual Sensor Smart radio module Master-SmartKey 1.0 These instructions are to be passed on by the fitter to the user. www.fuhr.de...
-
Page 2: General Information
SmartTouch 1.0 is a state-of-the-art access control system with KeylessGo technology. It allows the convenient, keyless opening of front doors equipped with the FUHR motorised locks autotronic 834, autotronic 836 or multitronic 881. The motor locks are unlocked just by touching the sensor in combination with an active Smart- Key. - Page 3 The SmartKey is intended for regular door opening via the KeylessGo function or optionally via the transmit button. The other buttons can be tuned in to additional Smart radio modules by using the separately available FUHR SmartConnect. This allows, for example, the control of a garage door or a radio socket.
-
Page 4: Installation
LED with the plug socket on the back of the Smart radio module. The motorised lock can then be inserted into the door leaf profile. Please ensure that there are no kinks in the cables and that they are not squeezed or pulled. WWW.FUHR.DE... - Page 5 M3x8: 2,6 - 2,7 mm M3x8 for Al- uminium PVC profiles 3x20 for timber profiles plastic cas- Hole Ø 8 mm connecting stainless steel cable cover Fit the cover with the recess pointing Connecting cable downwards Cable A WWW.FUHR.DE...
- Page 6 The tuning in process is finished and the SmartKey can be used for door opening. Note: If you exceed the 20 seconds or use the wrong master SmartKey, the tuning in process will be cancelled. WWW.FUHR.DE...
- Page 7 The green LED of the Smart radio module lights up for 4 seconds and afterwards turns off automatically. The deleting process is completed. Check by pressing the transmit button on the user SmartKey if the deleting process was successful. WWW.FUHR.DE...
- Page 8 As soon as the push-button is released, the green LED lights up for 4 seconds and afterwards turns off automatically. The deleting process is completed. Check by pressing the transmit button on one user SmartKey if the deleting process was successful. WWW.FUHR.DE...
-
Page 9: Radio Range
The radio range of the 4 remote control buttons strongly varies with the environmental conditions. The range is at least 10 m and cannot be changed. However, depending on the door material this range varies. Objects between the SmartKey and the Smart radio module may reduce this distance. WWW.FUHR.DE... -
Page 10: Security Functions
Please await this blocking period for using the KeylessGo function again or just use the transmit button on the SmartKeys. Attention. These blocking periods do not apply if your door is equipped with a cable run. WWW.FUHR.DE WWW.FUHR.DE... -
Page 11: Troubleshooting
– Is the SmartKey battery flat? (If there is still charge in the battery, the SmartKey will light up once when the transmit button is pressed briefly.) • If the motorised lock opens by pressing the opening button of the SmartKey, check the KeylessGo function. Please consider the blocking times between the door openings. WWW.FUHR.DE... - Page 12 Insert a narrow object (such as a flat-head screwdriver) into the slot at the back of the SmartKey and gently lever the cover up. Replace the battery, making sure the polarity is correct (the positive pole must be visible). Close the case. Batterie CR2032 WWW.FUHR.DE...
-
Page 13: Disposal Information
All components must be protected against moisture. They are not suitable for use in areas with high humidity or for exposure to chemical substances. • Only genuine FUHR accessories may be used. • No liability will be accepted in case of incorrect installation or operation. -
Page 14: Technical Specifications
Channels: Power supply: 1x 3V battery CR 2032 Temperature range: 5°C to 50°C, non-condensing Dimensions: 61,5 x 37 x 10,5 mm 10.3 SmartTouch sensor Power supply: 12 VDC Cover material: High-quality stainless steel Cover dimensions: 30 x 50 mm WWW.FUHR.DE... - Page 15 SmartTouch WWW.FUHR.DE...
- Page 16 SmartTouch CARL FUHR GmbH & Co. KG Carl-Fuhr-Straße 12 D-42579 Heiligenhaus Tel.: +49 2056 592-0 Fax: +49 2056 592-384 www.fuhr.de · info@fuhr.de...
