Summary of Contents for Voxson HD50
- Page 2 VOXSON HD50...
-
Page 3: Table Of Contents
CONTENTS SAFETY AND WARNINGS ...1 CONTENTS AND EQUIPMENT ...2 Package Contents ...2 Front Panel ...3 Rear Panel...3 Remote Control Unit ...4 CONNECT YOUR EQUIPMENT...5 BASIC OPERATION...9 MAIN MENU ...12 MENU TREE ...13 INSTALLATION...13 Auto Scan (Recommended) ...14 Manual Scan...14 PROGRAM EDIT ...15 SYSTEM SETUP ...17 A/V Settings...17 Local Time Setting ...17... -
Page 4: Safety And Warnings
• Do not open the main body. • Do not insert metals or inflammable objects inside the product. • Do not touch the power plug with a wet hand. • Disconnect the power cord in case of lightening. VOXSON HD50... -
Page 5: Contents And Equipment
The normal RS-232 cable can damage the receiver. Please contact your supplier when upgrading. Package Contents • Please check all package contents before using your receiver Remote Control YPbPr Cable CVBS Cable Owner’s manual Voxson HD50 Set Top Box VOXSON HD50... -
Page 6: Front Panel
CVBS output to connect to your TV. ⑧ YPbPr High definition video output to connect to your TV. ⑨ Video output to connect a VGA display monitor. ⑩ RS-232 Serial port for software upgrade. ⑪ POWER Switch ON/OFF. VOXSON HD50... -
Page 7: Remote Control Unit
OK To confirm the choice with the highlighted menu item / to open the program list and select the program by moving upward/downward. RECALL returns to view the previous channel. PAGE- To Page down (5-). FORMAT To switch the different resolution (1080i, 720P, 576P supported). VOXSON HD50... -
Page 8: Connect Your Equipment
AUDIO R and AUDIO L connections on the rear of the box. Be sure that the colour matches the plugs. 3. Using a S-VHS cable (not provided), connect the STB to the TV. The audio connection is as above (Item 2). VOXSON HD50... - Page 9 Be sure that colour matches the plugs. 3. Using the white and red cable, connect the audio to the TV. METHOD 3. Connect the STB via VGA connection (for high definition viewing) VOXSON HD50...
- Page 10 1. Connect your terrestrial antenna to Antenna IN socket on the rear of your receiver. 2. Using a HDMI cable to connect HDMI connection on the rear of the box. (This cable is not provided in the package). VOXSON HD50...
- Page 11 1. Connect your terrestrial antenna to Antenna IN socket on the rear of your receiver. 2. Using a COXIAL cable, connect to the TV 3. Also using SPDIF cable, connect to the TV 4. Also using the 3 RAC cable (white, red for audio) provided, connect to the TV. VOXSON HD50...
-
Page 12: Basic Operation
Languages are available only when the program provides them, so are the types of the audio. CHANGE SCREEN ASPECT Press Aspect key to switch screen mode (16:9 full screen, 16:9 letter box, 4:3 full screen, 4:3 letter box, 4:3 panscan supported). VOXSON HD50... - Page 13 VIEW SIGNAL INFO 1. Press SIGNAL key to view the signal level and quality of the playing channel. 2. Press EXIT/SIGNAL key to exit view. 3. Press INFO key to view the signal info too. VOXSON HD50...
- Page 14 The message box will pop up. Use this to select the time zone, set the daylight savings and set the TV screen type. After this is set an option to auto scan will be offered. VOXSON HD50...
-
Page 15: Main Menu
User Preferences For setting up the user interface according to your preference, such as the menu language, on screen display transparency, timeout for the information box, PIN code as well as menu lock. VOXSON HD50... -
Page 16: Menu Tree
System Setup User Preference Scan selected channels Auto scan Edit FAV Browse Lock Skip Delete Rename Move A/V setting Local time setting System information Default setting OSD Language OSD Transparence CH info bar time out Volume bar time out VOXSON HD50... -
Page 17: Auto Scan (Recommended)
3. Repeat step1, 2 to select other channels. 4. Press the RED key to start scanning the selected channels, a list box will be shown at the same time. 5. Press the EXIT key to exit if you want to exit during the scan. VOXSON HD50... -
Page 18: Program Edit
Skip this channel. At this time an arrow icon shown on the screen. 4. Press OK again to cancel the selection. The arrow icon will disappear. 5. Press EXIT key to exit all menus or press MENU to return to the previous menu. VOXSON HD50... - Page 19 6. Press EXIT key to exit all menus or press MENU to return to the previous menu. SWITCH TV/RADIO LIST Press BLUE key to switch between the TV channel list and the radio channel list. VOXSON HD50...
-
Page 20: System Setup
Press OK and input the correct the PIN code and confirm your selection, the factory default data will be loaded. NOTE: Factory default PIN is “0000”. All data you have saved will be discarded if you use this function. VOXSON HD50... -
Page 21: User Prefrences
2. Press ▲▼ to move the cursor to the timeout setting that you want in the list box, and press OK. 3. Press EXIT key to exit all menus or press MENU to return to the previous menu. VOXSON HD50... -
Page 22: Trouble Shooting
• To manipulate the equipment with the remote control, the control’s emitting part should be directly pointing towards the receiving part (IR Sensor) of receiver. • Check the batteries in the remote control. NOTE: If the problem is still unsolved after going through this procedure please contact customer support. VOXSON HD50... -
Page 23: Technical Specification
4 Mb CVBS, AUDIO R/L, YPbPr AC3,Fiber-Optic connection(Digital Audio Output) RS232C D-sub female type VGA, HDMI AC 100~240V, 50HZ Switching Mode Power Supply Operation mode: TYPE.10w, MAX.15w 360X235X43mm 2.2kg 0 C to +45 C -10 C to +70 C VOXSON HD50... -
Page 24: Glossary Of Terms
A colour system consisting of Red, Green and Blue being used to create a full spectrum. RS232 Serial data port. S-Video Y/C output for a S-VHS or Hi-Fi Video Recorder S/PDIF Digital audio output SMPS Switching Mode Power Supply Set Top Box VOXSON HD50... - Page 25 VOXSON Pty Ltd VOXSON HD50...
