Page 1 Operating instructions Heat pump dryer Suisse 8 WPT 16...
Page 2 Symbols Please read the instructions. Warnings are marked with a warning triangle! The text gives information how a dangerous situation can be avoided! Signal words indicate the severity of the danger, if not avoided. Warning means that possible personal injuries, and potentially life-threatening injuries may occur Important...
Page 3 Please read these instructions carefully to enable you to use all the possibilities and advantages of your new dryer. Please note in particular the safety informations and the enclosed guarantee and customer services booklet. We hope you will be very happy with your new HUWA dryer. Your HUWA Waschmaschinenfabrik R. Hunziker AG...
Page 4: Table Of Contents
Contents Safety and safety measures ..........6 Disposal .
Page 5 Cleaning and Maintenance ..........34 Cleaning the machine .
Page 6: Safety And Safety Measures
Safety and safety measures Do not let children carry out clean- ing and user maintenance without The enclosed documents contain supervision. important information on the instal- Safety while handling lation, use and safety of the dryer. and operating Keep the documents safe for other users or subsequent owners.
Page 7 Always unplug the machine from If a puddle forms on the floor near ► the power source before carrying the appliance (hose tear, leak, etc.), out maintenance work. wipe it dry and eliminate the cause (see Problems). If the machine is not needed for ►...
Page 8 Safety for children Safety during installation Warning Warning Risk of injury! Risk of injury! Children are in danger of injury or If the machine is to be placed on a life-threatening situations, when plinth, it must be mounted accord- playing with the machine. ing to the installation instructions, ►...
Page 9: Disposal
Disposal Observe when drying The fluff filters must be inserted Packaging from your new machine when operating this machine. All packaging materials used are environ- ► Never operate the machine with mentally friendly and reusable. All card is damaged fluff filters. made of 80 –...
Page 10: Tips For Drying
Tips for drying Sorting the laundry Drying the laundry Follow the care symbols in the fabrics. Remove easy care laundry from the ► To achieve even drying results, sort the dryer in a slightly damp state if possi- laundry by fabric type and desired level of (Slightly dry) and allow to finish dryness.
Page 11: Environmentally Compatible Drying
Environmentally Observe before first use compatible drying Install the machine according to the ► Notice installation instructions. Wringing wet laundry: waste of energy! Wipe the inside of the drum with a ► damp cloth. Remove as much water as possible from ►...
Page 12: Machine Description
Machine description Control and display area Loading door Cooling grid...
Page 13 Cotton Extra dry Cotton Cabinet dry Easy Care Cabinet dry On / Off Drying in the basket Back in the menu Mixed laundry Scroll backwards Additional programmes Scroll forwards Time preset Start programme Open the door Standard programme Settings Page number programme menu...
Page 14: Drying
Drying Preparing the appliance Selecting programme and starting Check whether the fluff filters are ► in place (see Drying / Clean fluff filters). Cotton Extra dry Switch on the power supply. ► Cotton Cabinet dry Turn on machine On / Off Easy care Slightly dry Press button ►...
Page 15: Changing The Programme
Changing the programme Selected options change colour and are ► shown in the upper part of the display. If necessary, cancel the selection by ► Changing the programme before tapping the light bar again. programme start Return to the main menu with the ►...
Page 16: Interrupting The Programme
Interrupting the programme Cotton 0:01 h max. 8.0 kg Cabinet dry On / Off Press button until the ► Gentle following window is displayed: Programme stopped Cancel Forward Return to the main menu with the ► button Back in the menu.
Page 17: Adding More Laundry
Programme end 0:01 h Cotton 0:01 h max. 8.0 kg max. 8.0 kg Cabinet dry The programme end is shown. Gentle Programme end Cancel Forward The programme will end. Adding more laundry When crease protection is turned on, Open the door Press button ►...
Page 18: Cleaning The Fluff Filters
Cleaning the fluff filters When fabrics are used, the fibres are rubbed (laundry fluff), which are released when the fabrics are dried, collecting in the fluff filters in the door opening. Clogged fluff filters may affect the Rub your hand over the inside of the ►...
Page 19 Switching off the machine On / Off Press button until ► the display turns off. Unplug the machine, when not used ► for longer periods of time. Rub your hand over the inside of the ► filter to remove the fluff. Replace the fluff filter and make sure it ►...
Page 20: Programme Survey
Programme survey max. Wash Type / Care washing Programmes symbol load drying target Fabric Most efficient programme for cotton textiles The following standard programme (marked with ) is suitable for drying normally wet cotton 8,0 kg Cotton Terry towels, tea towels, hand towels, Cabinet dry bed linen, underwear, cotton socks Programme settings for testing and energy labelling according to directive 2010 / 30 / EU...
Page 21 Always check the care symbols on the fabrics Approx. Approx. Spun in washing duration power cons. Comments machine at rpm min. according to regulation (EU) no. 932 / 2012 n textiles and is most efficient regarding the combined energy consumption. ►...
Page 22: Easy Care Laundry
max. Wash Type / Care washing Programmes symbol load drying target Fabric Easy care laundry Non-iron synthetic and mixed fibres and cotton with non-iron trim, e.g. viscose, cupro, modal, polyester 4,0 kg Easy care Anoraks, covers Iron damp 4,0 kg Easy care Shirts, blouses , sportswear, bed and table Slightly dry...
Page 23 Approx. Approx. Spun in washing duration power cons. Comments machine at rpm min. ► For laundry to be ironed ► For laundry which will not be ironed or only lightly ironed ► For laundry which will not be ironed ► For particularly thick or multilayered fabrics ►...
Page 24: Additional Programmes
max. Wash Type / Care washing Programmes symbol load drying target Fabric Additional programmes 3,0 kg Shirts, blouses Shirts and blouses Iron damp (max. eight pieces of clothing) 4,0 kg Jeans Jeans Cabinet dry Synthetics 3.2 kg Silk, delicates, lingerie, curtains and the likes Cabinet dry 2,6 kg Wool finish...
Page 25 Approx. Approx. Spun in washing duration power cons. Comments machine at rpm min. ► The programme reduces creasing, is gentle to the laundry and facilitates ironing ► Jeans are dried completely ► Remove the laundry immediately after the programme has ended and place it on a flat terry towel for drying ►...
Page 26: Special Programmes
Special programmes Insert the basket Pressing the symbol button the menu of the respective programme group is called up. Drying in the basket Insert the feet of the basket into the ► Damp wool must be moved as little as holders.
Page 27: Mixed Laundry
Trousers / Put rolled towel into the basket making ► Skirts Pullovers an inclined surface. Put in the shoes with heels on towel. Notice Use the basket only for the special ► Drying in the basket programme (Programme survey / Drying in basket).
Page 28: Programme Options
Programme options By also selecting one or more options, First select the desired programme. ► ► Time a wash programme can be specifically After this select the option ► preset. tailored to the particular characteristics of the laundry. 1:52 h Program end 04.09.
Page 29: Drying
Drying + Express With this option the dryness level can For drying reduced laundry loads or be increased temporarily – for the single items made of cotton, synthetic duration of the selected programme. or mixed fabrics. Notice To increase the dryness level in gen- eral (for all programmes), the function Dryness level increased must be...
Page 30: Settings
Settings Your dryer has basic settings from the factory. The settings can be adapted to Settings the users individual needs either when Language first used or later using the following functions. Date The settings can only be changed if no Time wash programme is running.
Page 31: Menu Settings
Menu Settings Display programme time Duration * ► * = Default setting The display shows the remaining time of the programme. Language ► English * ► The display shows when the programme ..► will be finished. Additional menu pages can be opened arrow buttons by pressing the Brightness display...
Page 32 Dryness level raised Crease protection Off * ► ► 30 min * ► ► ► ► At the end of the programme a crease ► The dryness level can be adjusted as protection phase (loosening up of a general setting. Then it affects all laundry) for 30 minutes or 6 hours can programmes until the next change in be set.
Page 33 Standby ► No function. (Only for machines with payment system) Waking up machine Press button On / Off ► Automatic door opening Off * ► ► If this function is switched on, the door will open automatically at the end of the programme.
Page 34: Cleaning And Maintenance
Cleaning and Maintenance Caution Cleaning the fluff filters Drying / Cleaning the fluff Danger of electric shock! filters. Switch off the power supply to the ► machine before cleaning. Cleaning the filter support Under no circumstances spray the ► machine with water. Do not use a steam cleaner.
Page 35: Cleaning The Moisture Sensor
Cleaning the moisture sensor Self-cleaning After longer operation, small deposits (lime, fabric refiner) can form on the The dryer is equipped with an automatic front inner side of the drum on both self-cleaning function. sides of the longish moisture sensors. At the end of each programme and also With moisture controlled programmes, during the drying process, if necessary,...
Page 36: Problems
Problems Warning Improper repairs can result in severe accidents, damages and operation malfunctions! Do not make any changes, manipulations or attempt repairs using tools such as screw- drivers, etc. Minor problems which you can rectify yourself ER R O R MES S AG E S ON T H E D I S PL AY (is not lit!) and at the Child lock active...
Page 37 Programme stopped Button On / Off was pressed during a running programme. Press the light bar next to Continue. ► E R RO R ME SSAG E S F – – «Error F ––» Acknowledge the error message with OK. ►...
Page 38 The drying target When warm, laundry feels more moist than it actually is! was not achieved Remove the laundry from the dryer and let it cool. ► When still moist: Drying / Cleaning the fluff Clean the fluff filters (see ►...
Page 39: Technical Specifications
Technical specifications Product data sheet for household washing dryer according to EC regulation no. 392 / 2012 HUWA Model name / label Suisse 8WPT 16 Nominal capacity kg 8,0 Dryer type Heat pump dryer Energy efficiency class A +++ (highest efficiency) to D (lowest efficiency)
Page 40: Customer Service
Customer service Check whether you can correct the fault Give customer services the error message yourself before you call customer service F –– and the product and appliance number (see chapter Problems). of your washing machine. You will find this If advice is required, costs may be incurred information on the type label inside the if a service technician is required, even...
Page 41 Notes...
Page 42 Notes...
Page 44 Hauptsitz und Service-Zentrale R. Hunziker AG Waschmaschinenfabrik CH-5728 Gontenschwil Tel. + 41 (0) 62 773 11 70 www.huwa.ch Brief instruction Follow the safety instructions in this manual! Turn on the power switch and open the water tap. ► Press button On / Off ►...
