- Page 1 OWNER’S MANUAL KJ-8000 PRO PROFESSIONAL SERIES DIGITAL KARAOKE MIXER IMPORTANT INFORMATION: Thank you for purchasing the KJ-8000 Pro. To make full and effective use of this unit, please read this Owner ’s Manual carefully before operating.
- Page 2 GENERAL WARNING RISK OF ELECTRIC SHOCK CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Congratulations! And thank you for purchasing the VocoPro KJ-8000 PRO. This unit has been designed with the professional KJ and DJ in mind to assist in providing the highest quality Karaoke entertainment available. With proper care and handling, this unit will continue to operate optimally for years. Please read this manual carefully before getting started. -
Page 4: Before You Start
VocoPro WARNING: To avoid shock or serious injury do not attempt to connect any external devices or cables to the KJ-8000 Pro... -
Page 5: Rear Panel Hookup (Cont.)
Master Control Section Stereo/Music Control Section Connecting a Sub Woofer Locate the Sub Bass section of the Master control section on the back of the KJ-8000 Pro Use Out 1 and or Out 2 to connect your external (powered) sub woofer. Use the Frequency control to select the crossover point, between 50Hz and 200Hz, for the sub-bass section. All frequencies below the crossover point are output through Out 1 and Out 2. -
Page 6: Parts And Functions (Microphone Input Module)
PARTS AND FUNCTIONS (Microphone Module) 1. Gain: This controls the input level for the “LINE” and “XLR” microphone inputs for the channel. It can be adjusted from 20dB to 60 dB. High EQ: This controls the level for a preset high frequency range. Use this control to boost to reduce the high end frequencies in the microphone signal. -
Page 7: Parts And Functions (Music Module)
PARTS AND FUNCTIONS (Stereo/Music Module) 1. Source Selector: Phono/Line This allows the user to connect two players without video output. The source selector switch makes it possible to switch easily between players by “toggling” it to the desired position. 2. Source Selector: DVD/LD/CD This allows the user to connect up to three players with video output. -
Page 8: Parts And Functions (Master Control Module)
PARTS AND FUNCTIONS (Master Control Module) and expandability module... Monitor 1. DC 12V Lamp Connector 2. Power On/Off LED Level Meter: Displays sound or cue levels from the music sources. Digital Key Control & Multiplex: The digital key control feature works in the Master 2 mode. -
Page 9: Expandability Module
EXPANDABILITY MODULE The KJM-7900 Pro Expandability Module (KJ-Module) can be purchased separately through your authorized VocoPro dealer. One KJ-Module can be used to add three additional mic channels OR three additional music channels to your KJM-7900 mixer.. AND SPECIFICATIONS KJ-8000 Pro...
