Summary of Contents for CRISTAL C903ASS
- Page 3 those in other rooms) due to back flow of combustion gases. These gases can potentially result in carbon o not try to use the cooker hood monoxide poisoning. After installation without the grease filters or if the filters of a range hood or other cooking fume are excessively greasy! o not install above a cooker with a high level grill.
- Page 4 maintenance shall not be made by ake sure the ducting has no bends children without supervision. sharper than 90 degrees as this will reduce the efficiency of the cooker hood. arning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.
- Page 5 ARNING: Danger of fire: do not EVER try to extinguish a fire with store items on the cooking surfaces. water, but switch off the appliance and then cover flame e.g. with a lid or a steam cleaner is not to be used. fire blanket.
- Page 6 1. Before installation, turn the unit off and unplug it from the outlet. 2. The cooker hood should be placed at a distance of 65~75cm above the cooking surface for best effect. See pic 1. 3. Install the hook on a suitable place once the installation height is fixed, and keep it in line.
- Page 7 6. Adjust the height of the inside chimney to the position of the inside chimney bracket and fix it by screws, after adjusting the position, fix the body with safety screws. Note: The two safety vents are positioned on the back housing, with a diameter of 6mm.
- Page 8 WARNING: For safety reason, please use only the same size of fixing or mounting screws which are recommended in this instruction manual. Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. LCD touch control Plug the hood;...
- Page 9 4. When the hood is not working; press “ ” button once. The hood will work at the speed it works last time and LCD will show “ ”. Press “ ” button again; the hood stop working and “ ”...
- Page 10 Fan switch turned off Select a fan switch position. Light on, but motor Fan switch failed Contact service center. does not work Motor failed Contact service center. House fuses blown Reset/Replace fuses. Light does not Refit mains power cable to work, motor does Mains power cable is loose or power outlet.
-
Page 11: Stainless Steel
STAINLESS STEEL The stainless steel must be cleaned regularly (e.g.weekly) to ensure a long life expectancy.Dry with a clean soft cloth. A specialized stainless steel cleaning fluid may be used. NOTE: Ensure that wiping is done along with the grain of the stainless steel to prevent any unsightly crisscross scratching patterns from appearing. -
Page 12: Bulb Replacement
3. Turn the carbon filter on both sides of the motor anti-clockwise. Replace the carbon filters with the new carbon filters. 4. Place the mesh filter. 5. Connect the power supply to the wall socket. NOTE: Make sure the filter is securely locked. Otherwise, it would loosen and cause danger. - Page 13 This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2012/19/EU.
- Page 14 SOLE AGENT Great Treasure (Building Supplies) Limited HONG KONG OFFICE (852) 3752 6111 (852) 2722 1856 WhatsApp (852) 9823 2471 Block E, 10/F, Mai Tak Industrial Building E-mail info@gtgroup.com.hk 221 Wai Yip Street, Kwun Tong Website www.gtgroup.com.hk Kowloon, Hong Kong MACAU SHOWROOM Em Macau, (853) 2872 3661...
