- Page 1 Technical Specifications ® DECTRIS EIGER 2 S 500K-RW Document Version v1.7.4 DECTRIS Ltd. 5405 Baden-Daettwil Switzerland www.dectris.com...
- Page 2 Document Version v1.7.4 © Copyright 2022 DECTRIS Ltd.
-
Page 3: Table Of Contents
Mounting the Detector Control Unit ........24 ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4... - Page 4 Cleaning and Maintenance ......... . 28 TROUBLESHOOTING ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4...
-
Page 5: Document History
Update technical drawings. v1.7.2 2022-02-24 Improve instructions on water cooling and cable handling. v1.7.3 2022-02-24 Add manual for EIGER2 9M-V-RW. v1.7.4 2022-04-14 Fixed EIGER2 vacuum operation and updated trademarks. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 iii | 31... -
Page 6: General Information
1. GENERAL INFORMATION 1.1. Contact and Support Address: DECTRIS Ltd. Taefernweg 1 5405 Baden-Daettwil Switzerland Phone: +41 56 500 21 02 Fax: +41 56 500 21 01 Homepage: http://www.dectris.com/ Email: support@dectris.com Should you have questions concerning the system or its use, please contact us via telephone, mail or fax. -
Page 7: Warranty Information
(in particular information, images or ® materials), unless otherwise indicated. Without the written permission of DECTRIS it is prohibited to integrate the protected contents in this publication into other programs or other websites or to use them by any other means. -
Page 8: Use Of The Eiger2 S 500K-Rw
® We recycle DECTRIS detector systems that are no longer suitable for use. If you are not using your DECTRIS detector system any more, send it back to us. We will make sure that your system is responsibly and safely recycled. This is free for ®... -
Page 9: Technical Specifications
Weight 3.7 kg Overvoltage category Means of protection I (power supply) Pollution degree Maximum operating altitude 2000 m a.s.l. Single threshold. Using two thresholds halves the frame rate. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 4 | 31... -
Page 10: Ratings
11.5 A 138 W AC connector IEC-320-C14 input inlet Case dimensions (W x H x D) 72 mm x 35 mm x 175 mm Weight 0.7 kg ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 5 | 31... -
Page 11: Detector Control Unit
Dimensions (W x H x D) 270 mm x 393 mm x 436 mm Weight 17.5 kg −1 Typical flow 3 L min Maximum operation pressure 3 bar ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 6 | 31... -
Page 12: Ambient Conditions
• Make sure the temperature and the humidity inside the transport box does not exceed the specified range (use of a drying agent is required). • Ensure that no condensation moisture develops if the detector is stored at low temperature. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 7 | 31... -
Page 13: Detector Dimensions And Connectors
Information ® 3D step files of the EIGER2 S 500K-RW detector are available on request. Please contact DECTRIS technical support for more information. Figure 4.1: Drawing of the EIGER2 S 500K-RW Detector (also printed separately in the user documentation folder) ®... -
Page 14: Front Side Of The Detector
Do not apply any force on the screws, the screws do not need to be tightened to hold the cover in place and excessive force can damage the housing. Figure 4.2: The EIGER2 S 500K-RW Detector with the Cover Removed (front view) ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 9 | 31... -
Page 15: Back Side Of The Detector
4.1.3. Back Side of the Detector Figure 4.3: The EIGER2 S 500K-RW Detector (back view) ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 10 | 31... -
Page 16: Status Leds
Do not replace the optical transceivers, as proper function of the detector system cannot be guaranteed otherwise. Please contact support@dectris.com if you need replacement transceivers. Caution There must be a 1 x LC/UPC duplex fiber optic con- nectors point-to-point connection between detector and detector control unit. -
Page 17: Detector Control Unit
Using the web front end, it is possible to restart the EIGER2 control service, trigger an update, and to shut down and to reboot the detector control unit. Any further control of the detector is carried out via the SIMPLON API (see separate documentation). ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 12 | 31... - Page 18 Briefly pushing the power button on the front panel will shut down the detector control unit. May take up to 1 min. Figure 4.5: Back view of detector control unit with labeled network interfaces. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 13 | 31...
-
Page 19: Connectors
Table 4.4: Operating Conditions Condition Definition Operating temperature The thermal stabilization unit has to be set to a temperature of 23 °C for normal operation. Maximum operating pressure 3 bar ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 14 | 31... -
Page 20: In-Vacuum Operation
The water connectors use an 1/8 inch ISO parallel thread. Before opening the cooling circuit always remove the coolant to avoid dripping. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 15 | 31... - Page 21 Prior to powering up and operating the detector in-vacuum the thermal stabilization unit has to be set to a temperature of 17 °C for at least 30 min. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 16 | 31...
-
Page 22: Installing The Detector System
Caution ® ® The screws holding the Mylar frame are close to the Mylar foil, be careful that the screw driver does not slip and damage the frame. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 17 | 31... - Page 23 For mechanical protection the cover can be mounted, but the sensors are still unprotected from humidity and dust. ® Figure 5.1: The EIGER2 S 500K-RW Detector without the cover and Mylar frame in place (front view). ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 18 | 31...
-
Page 24: Mounting
MEC-006280 Freigegeben Title Date of Issue EIGER2 500K-RW Outline 17.03.2020 DECTRIS Ltd. Taefernweg 1 5405 Baden-Daettwil, Switzerland Comment / Item number Sheet We reserve all rights in connection with this 2 / 2 document. Without our agreement it may be neither copied nor made accessible to a third party. -
Page 25: Mounting From Below
The detector should be mounted using all four outer 7 mm holes (indicated with yellow circles). Caution Make sure the mounting brackets are mounted and properly tightened using the screws provided. The placement of the screws is indicated with diamonds in figure 5.4. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 20 | 31... -
Page 26: Grounding Of The Detector
For information on system connections, refer to the section 4.1.5 and for storage of the detector system refer to the section 7.5. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4... -
Page 27: In-Vacuum Use
LC/UPC duplex fiber optic connectors. Detectors used in vacuum need different optical cables. For information about vacuum cables, refer to the vacuum ® feedthrough set specifications or contact DECTRIS support. 5.6.1. Installing the Cables The fiber optic cables come with a pulling eye to make cable installation easier and a cable sock to protect the connectors. -
Page 28: Checking The Connection
Do not add any component other than those supplied by DECTRIS to the cooling circuit. Using the wrong material in the ® cooling circuit leads to galvanic corrosion, which can permanently damage the detector. Contact DECTRIS support at support@dectris.com in case the supplied components are not compatible with your setup. -
Page 29: Mounting The Detector Control Unit
The mains plug of the detector control unit has to be connected to a grounded power outlet. The detector control unit can be mounted in a standard 19 inch rack, which has to be properly grounded. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4... -
Page 30: Temperature And Humidity Control
5.5. Then restart the software. Information A free-flowing air stream is mandatory in order to properly cool the electronics inside the detector. Do not cover any ventilation holes. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 25 | 31... -
Page 31: Operation Procedure
• Do not remove the nitrogen/dry air connection. It is a requirement that it is left at the recommended flow rate according to section 5.5. Warning As long as the detector power cable is connected, the detector has to be considered under power. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 26 | 31... -
Page 32: Vacuum Operation
To see if a detector is vacuum compatible, check whether the vacuum compatibility option is included in the order confir- ® mation received from DECTRIS 7.4.1. Ambient Conditions for In-Vacuum Use For in-vacuum operation of the detector following conditions must be fulfilled: Table 7.1: In-Vacuum Operating Conditions... -
Page 33: Storing The Detector
® ® The Mylar foil must not be touched or cleaned. If it is damaged, please contact DECTRIS technical support. The detector housing can be cleaned with a soft tissue. The EIGER2 S 500K-RW detector does not require any mainte- nance. -
Page 34: Troubleshooting
Table 8.1 provides an overview of possible problems with the detector system and instructions in order to solve the problems. If the problem you are experiencing is not listed below or if the instructions do not help, please contact support@dectris.com. - Page 35 Ambient humidity around the detector Shut down the detector immediately exceeds the operating conditions. and check the humidity. Power up the detector only when the ambient hu- midity has been reduced. ® DECTRIS EIGER 2 S 500K-RW Technical Specifications v1.7.4 30 | 31...
