NINGBO YOUWON TECHNOLOGY ELECTRONICS CO., LTD
Features：
1．
Providing USB interface，highly integrated，can connect with transceiver equipment
directly.
2. Low power RF transmission：Maximum transmit power 10mW
3. GFSK/FSK modulation mode
4. Crystal frequency stabilization.
5. High-efficiency forward error correction channel encoding technology is used.
Main Application Areas：
1. AMR – Automatic Meter Reading
2. Wireless alarm and security systems
3. Wireless POS, PDA
4. Long-distance non-contact RF smart cards, RFID tags.
5. Wireless Field Bus、wireless conference voting system
ADDRESS ：#928, XUEYUAN ROAD, LUGANG VILLAGE, GAOQIAO TOWN, NINGBO
TELEPHONE：0574 88046201
ZF02-U Wireless Module
Operation Manual
Figure 1. ZF02-U wireless module
FAX：0574-88046202

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZF02-U and is the answer not in the manual?

Questions and answers

Summary of Contents for Ningbo ZF02-U

  • Page 1 1. AMR – Automatic Meter Reading 2. Wireless alarm and security systems 3. Wireless POS, PDA 4. Long-distance non-contact RF smart cards, RFID tags. 5. Wireless Field Bus、wireless conference voting system ADDRESS ：#928, XUEYUAN ROAD, LUGANG VILLAGE, GAOQIAO TOWN, NINGBO TELEPHONE：0574 88046201 FAX：0574-88046202...
  • Page 2 9600bps output power 10mW Interface data UART ,8E1/8N1 data format format Power supply DC 3.6V---5V overall 70 X 45 X 17 mm dimensions Figure2. interface and sizes ADDRESS ：#928, XUEYUAN ROAD, LUGANG VILLAGE, GAOQIAO TOWN, NINGBO TELEPHONE：0574 88046201 FAX：0574-88046202...
  • Page 3 NINGBO YOUWON TECHNOLOGY ELECTRONICS CO., LTD Interface Description： ZF02-U wireless module can be directly connected to PC computer by USB port, shown as Figure3. Wireless communication channel setting Figure3. ZF02-U wireless communication application diagram Channel setting There is one group of 5-bit short-circuiter wire (JP2) as shown in Figure 2, defined as A、...
  • Page 4 NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED UNAUTHORIZED MODIFICATIONS THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. ADDRESS ：#928, XUEYUAN ROAD, LUGANG VILLAGE, GAOQIAO TOWN, NINGBO TELEPHONE：0574 88046201 FAX：0574-88046202...
