Summary of Contents for Vizio L6
-
Page 2: Table Of Contents
Precautions Quick Installation (PC-DVI) Installation of Wall Mount (Optional) Using the Display Setting the Timing Mode (DVI Input) Switching Sources (DVI, Component, AV, S-Video, TV) Modes Adjusting the Screen Image Remote Control Top Keypad Controls OSD Menu Picture Adjust menu... -
Page 3: Product Registration
Your local waste disposal company may provide information about proper disposal. Product Registration For Your Records Product Name: V Inc. Vizio L6 20” LCD TV Model Number: LT20BAN28AAB Serial Number: Purchase Date: VINC.COM... - Page 4 Important Safeguards • Read all the Safety Instructions and the User Manual before using the Display. Keep these instructions in a safe place for future reference. • To avoid the risk of electric shock or component damage, switch off the power before connecting other devices to the Display.
-
Page 5: Getting Started
Getting Started Congratulations on your purchase of the V Inc.® Vizio L6 20” LCD TV. Important! Save the original box and all packing material for future shipping needs. Package Contents Your Vizio L6 20” LCD TV package includes: 20” LCD TV... -
Page 6: Quick Installation (Pc-Dvi)
Quick Installation (PC-DVI) 1. Remove the two rear panel covers. 2. Connect the power cord. 3. Connect the DVI-D cable. Make sure both the LCD display and computer are turned OFF. Connect the DVI-D cable from the LCD display to the computer. 4. -
Page 7: Installation Of Wall Mount (Optional)
Installation of Wall Mount (Optional) To obtain a wall-mounting kit, contact V Inc. or your local dealer. Refer to the instructions that come with the Wall Mount kit. To convert your LCD TV from a desk-mounted to a wall-mounted display, do the following: Four screw holes for wall mount 1. -
Page 8: Using The Display
1. Turn on the power of the connected video equipment. 2. Press the Sources button on the Remote Control or the TV/Video button on the LCD TV to step through the selections, or select the source directly by pressing the DVI, YPbPr, AV, S-Video or TV... -
Page 9: Adjusting The Screen Image
Adjusting the Screen Image Use the buttons on the Top Keypad Controls (or Remote Control) to display and adjust the On Screen Display (OSD). The OSD controls are explained at the top of the next page and are defined in “Main Menu Controls”... -
Page 10: Remote Control
The Remote Control is range is up to 16ft (5m). 1. POWER Switch the power On/Off 2. SOURCES Select the input source 3. TV Select TV mode 4. ASPECT Select picture ratio 5. DVI Select digital video mode 6. YPbPr Select component mode 7. -
Page 11: To Adjust The Screen Image
To adjust the screen image: 1. To display the OSD main menu, press the Menu on the Top Keypad or on the Remote Control. The four arrow buttons can be used to move the marker. Pressing the MENU key when in the menu will exit the OSD menu. -
Page 12: Top Keypad Controls
Power button makes the TV turn off. When the TV is off, pressing the Power button makes the TV turn on and it will show the input source that was last shown before it was turned off. Note that TV turns off if this button is pressed at Power Save status. -
Page 13: Osd Menu
TV, AV and S-Video modes Figure 1 Picture Adjust menu (TV, AV and S-Video) The Picture Adjust menu will be as shown in Figure1 when the input source is TV, AV or S-Video. Adjustments can be made using the Remote Control or Top Keypad. - Page 14 5. Press the Exit button on the Remote Control or the Menu button on the Top Keypad to return to the main menu and then press the button again to exit the OSD or wait for the time out to exit. Function Name BRIGHTNESS Adjust the brightness of the TV CONTRAST H POSITION...
- Page 15 DVI mode Picture Adjust Menu The Picture Adjust menu will be as shown in Figure 3 when the input source is DVI. Adjustments can be made using the Remote Control or Top Keypad. 1. Press the Menu key to display this Menu 2.
-
Page 16: Input Setup Menu
OSD or wait for the time out to exit. Function Name COMPONENT Select the Component (YPbPR) input source S-VIDEO Figure 4 Input Setup menu Explanation Select the DVI (Digital Video) input source Select the AV (Composite [CVBS] Video) input source Select the S-Video input source Select TV VINC.COM... -
Page 17: Pip Setup Menu
PIP Setup menu Figure 5 PIP Setup menu Figure 6 PIP menu Figure 7 POP menu VINC.COM... - Page 18 6. Press the ► button on the Remote Control or the ▲VOL button on the Top Keypad to select the PIP or POP Mode. 7. Press the OK button on the Remote Control or the TV/Video button on the Top Keypad to select the input. The PIP or POP sub screen will now be shown with the main screen.
-
Page 19: Tv Tuner Setup Menu (Tv Only)
TV Tuner Setup menu (TV only) Figure 9 TV Tuner Setup menu (The current channel is deleted) When the main input is TV the menu will appear as shown in Figure 8. This menu is used to set some TV functions. - Page 20 Function Name SOUND Select MTS type include: Stereo, Sap, Mono, Dual TV CABLE Select input: Cable / TV CHANNEL SEARCH Auto scan channel (Press “Right” key to execute) SET CHANNEL Change channel ADD/DELETE ADD or DELETE the Channel. This works as a switch.
-
Page 21: Audio Adjust Menu
Audio Adjust menu The Audio Adjustment menu shown in Figure 10 is used to set audio parameters including volume, bass, treble, balance, loudness and mute. 1. Press the Menu key to display the OSD Menu 2. Press the ► button on the Remote Control or the ▲VOL button on the Top Keypad to select the Audio Adjustment menu. - Page 22 Function Name VOLUME Adjust the Volume level BASS Adjust the Bass level TREBLE Adjust the Treble level BALANCE Adjust the Left and Right speaker balance LOUDNESS The low-pitch and high-pitch of sound will be enhanced simultaneously if this setting is on. MUTE Audio mute switch on or off If switch is on means that the audio is muted, as in Figure 11.
-
Page 23: Parental Controls Menu
Parental Controls menu Figure 12 Parental Controls menu Figure 13 Access code menu Figure 14 Access code incorrect warning message VINC.COM... - Page 24 The Parental Controls menu shown in Figure 12 is used to set the Password, TV rating and Movie rating. As shown in Figure 14, a window will be displayed that requests a password before entering this menu. If the password is correct then entry to the Parental Controls menu is permitted, otherwise a warning message will appear as shown in Figure 14.
-
Page 25: Access Code Edit Menu
2. Key in the new password. 3. Key in the new password again for confirmation. 4. Press the OK button on the Remote Control or the TV/Video button on the Top Keypad to select choice. 5. Press the Exit button on the Remote Control or the Menu button on the Top Keypad to return to the main menu and then press the button again to exit the OSD or wait for the time out to exit. -
Page 26: Tv Rating Menu
1. Press the ▼ button, (▲ button to go back), on the Remote Control or the ▼CH, (▲CH button) on the Top Keypad, to change the selected function. 2. Press the OK button on the Remote Control or the TV/Video button on the Top Keypad to select choice. -
Page 27: Movie Rating Menu
1. Press the ▼ button, (▲ button to go back), on the Remote Control or the ▼CH, (▲CH button) on the Top Keypad, to change the selected function. 2. Press the OK button on the Remote Control or the TV/Video button on the Top Keypad to select choice. -
Page 28: Special Features Menu
Special Features menu The Special Features menu shown in Figure 18 is used to change OSD parameters. 1. Press the Menu key to display the OSD Menu 2. Press the ▼ button on the Remote Control or the ▼CH button on the Top Keypad to enter this menu 3. -
Page 29: System Information Menu
System Information menu A typical System Information menu is shown in Figure 19. Actual information may be different. Press the Exit button on the Remote Control or the Menu button on the Top Keypad to return to the main menu and then press the button again to exit the OSD or wait for the time out to exit. Function Name MODEL NUMBER MAIN INPUT... -
Page 30: Volume Osd
Volume OSD Press the Volume▲ or Volume▼ button the Remote Control or the ▼VOL or ▲VOL button on the Top Keypad and the Volume OSD will be displayed at the bottom of the screen (Figure 20). 1. Press the Volume▲ button on the Remote Control or the ▲VOL button on the Top Keypad to increase the audio volume. -
Page 31: Channel Number Osd
Press the Audio button on the Remote Control and the Audio OSD will be displayed on the bottom of the screen (Figure 22) 1. Press the Audio button on the Remote Control to display the OSD. 2. Press the ▼ button, (▲ button to go back), to select the function. 3. - Page 32 1. When in the TV mode, the channel can be changed directly by pressing the Number buttons on the Remote Control. 2. Before the channel is changed the current channel number is shown and the CA prefix color is yellow as shown in Figure 23.
-
Page 33: Source Message Osd
Source Message OSD The Source button on the Remote Control can be used to step through all of the inputs for the main screen. The input source name will be displayed in the top left corner of the screen as shown in Figure 1. -
Page 34: Sleep Timer Message
Sleep Timer message The Sleep button on the Remote Control can be used to directly access and set the Sleep Timer. The message displayed on the screen is shown in Figure 27. 1. Press the Sleep button on the Remote Control to display the Sleep Time message. 2. -
Page 35: Channel Scanning Message
Figure 30 Channel Scanning message OSD (Channel is deleted for “no signal”) When the Channel Search function is chosen in the TV Tuner setup sub menu, the Channel Scanning message will be displayed in the top left corner of the screen, (Figure 29). The system scans the channels automatically and when it finds channels with a signal it adds them to the channel list. -
Page 36: Warning Message
Warning message When the main input source is DVI and no Multi screen function is active, the LCD TV will go into the power saving mode if there is no signal input. The message shown in Figure31 will be displayed for approximately five (5) seconds and then the LCD TV will power off to the power save mode. -
Page 37: Other Information
Other Information Specifications Panel Type Color Viewing angles Horizontal Vertical Input signal Video Sync Compatibility Macintosh Resolution Supported Recommended Power Voltage Operating conditions Temperature Humidity Altitude Storage conditions Temperature Humidity Altitude Dimensions Physical Weight Regulations Power saving 20.1" (full 20.1" viewable diagonal), TFT (Thin Film Transistor), Active Matrix VGA LCD, 640RGBx480 vertical stripe Anti-reflective coating + Anti-glare coating 160°... -
Page 38: Troubleshooting
• Make sure the video cable supplied with the Display is tightly secured to the video output port on the back of the LCD TV. If the other end of the video cable is not attached permanently to the Display, tightly secure it to the LCD TV. - Page 39 Telephone & Technical Support Products are often returned due to a technical problem rather than a defective product which may result in unnecessary shipping charges billed to you. Our trained support personnel can often resolve the problem over the phone. For more information on warranty service or repair, after the warranty period, please contact our Support Department at the number below.
-
Page 40: Cleaning The Display
Cleaning the Display • Make sure the display is turned off. • Never spray or pour any liquid directly onto the screen or case. To clean the screen: 1. Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles. 2. -
Page 41: Safety Guidelines
Safety Guidelines Warning: This device must be operated with the original power supply, part number: ADP-60CFA. CAUTION: The socket-outlet should be installed near the equipment and should be easily accessible. CAUTION: Use a power cable that is properly grounded. Always use the appropriate AC cord that is certified for the individual country. -
Page 42: Compliance Information For U.s
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Warning To assure continued FCC compliance, the user must use grounded power supply cord and the provided shielded video interface cable with bonded ferrite cores. -
Page 43: Incorporated Limited Warranty
V, Inc.’s responsibility (see above) will be provided without charge. Other service is at the owner’s expense. You must provide the model, serial number and date of purchase. Before you ask for warranty service, read your User Manual. You might avoid a service call. For Technical Support Call (714)962-4388 or E-mail Techsupp@vinc.us For VIZIO LCD Displays...
