Page 2: Table Of Contents
AKAI SERVICE MANUAL Model: LCT32Z4ADP 1. Safety Instructions………………...………………………………………………….1~2 2. Trouble Shooting manual of LCD…………………………………………………….3 3. Product Specification………………………………………………………………….4~7 4. Block Diagram….…………………………………………………………………….8 5. Circuit diagram……………………………………………………………………….9~22 6. Basic Operation of TFT-LCD…………………………………………………..……23~24 7. Main IC Information…………………………………………………………………25~96 8. Panel Information……………………………………………………………………97~122 9. Exploded View………………………………………………………………………123 10. Spare Part List………………………………………………………………………124~127 11.
Page 3: Safety Instructions
Safety Precaution The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to CAUTION alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclo sure that may be of sufficient magnitude to RISK OF ELECTRIC SHOCK DO NOT OPEN constitute a risk of electric shock to persons.
Page 4 PRODUCT SAFETY NOTICE 5. When replacing a MAIN PCB in the cabinet, always be certain that all protective are installed properly such as control knobs, Many electrical and mechanical parts in this adjustment covers or shields, barriers, isolation apparatus have special safety-related resistor networks etc.
Page 5: Trouble Shooting Manual Of Lcd
Trouble Shooting Manual of LCD 1 Do not power on Please check the AC cable if connect to AC plug. It is true that the connector doesn’t connect to AC plug. Please connect it. Please check the AC cable if connect to AC power. It is true that the AC cable doesn’t connect to AC power.
Page 6: Product Specification
Product Speciﬁcation Product Model LCT32Z4ADP TV System NTSC M, ATSC VIDEO System NTSC Screen Size 32” diagonal Active Area 697.685mm(H) x 392.256mm(V) Aspect Ratio 16:9 External Size (with stand) 815.05 mm (W) x 614.65 mm (H) x 240.00 mm (D) Gross Weight 20.85 kg...
Page 7 Remote Control (Note: 1. The set code of the unit is 218. 2. Details refer to AKAI TV Universal Remote Control Programming Guide.) S tandby( ): Press to turn on and off. Mute( ): Press this button to quiet the sound. Press again to reactivate the sound.
Page 8 Title: Press to display the DVD disc title. Repeat: When in DVD mode, press to cycle through the options: CHAPTER, TITLE, ALL and nothing. While in CD mode, the options are: TRACK, ALL. Subtitle: Press to select desired DVD subtitle. Setup: Press to display a setup page.
Page 9 Support the Signal Mode A. VGA Mode Horizontal Vertical Resolution Frequency Frequency (KHz) (Hz) 640 x 480 31.50 60.00 35.16 56.25 800 x 600 37.90 60.32 48.08 72.19 1024 x 768 48.40 60.00 B. YPbPr Mode Horizontal Vertical Resolution Frequency Frequency (KHz) (Hz)
Page 10: Block Diagram
POWER BOARD DTVS205CH201A MT5112BD Digital/Analog LCD panel Standby 5V DTV Demodulator Tuner CVBS/SIF 8Bit LVDS 24VA (For Class D) MAIN BOARD HDMI1 Two to one TMDS HDMI Switch COMB DVD HDMI2 Coaxial Output Loader Am5888 &Optical SL/F Pick up Motor COAXIAL Driver 24C16...
Page 11: Circuit Diagram
MT5372RAV6 MT5372 (PBGA) REFERENCE DESIGN - 4 LAYERS DV33 2,4,5,6,7,11,12,13,14 DV33 AMP_GND History DATE AMP_GND RA-V1 +24V POWER INPUT +24V RA-V0 INITIAL VERSION 2006/07/14 2,11 +12V +12V RA-V1 2006/07/31 2,7,8,9,11,13 +5VSB 2,7,10,11,12,13,14 +5VSB 1000pF/NC C0603/SMD DV33SB 2,5,6,7,10,11,12,13 DV33SB VS_ON G ND 2,3,4,5,6,7,8,9,10,11,12,13,14 SYS_P WR SYS_P WR...
Page 12 +5V_TUNER 1000mA AP1513/SOP-8 FB/75R/1A/0805 720mA AP1513 RA-V3 BEAD/SMD/0805 DV12 CB16 220uF/16V 0.1uF L7805 220uF/16V CB17 FB/75R/1A/0805 LTRH104R-270 FB/75R/1A/0805 100UF/220UF/SMD 0.1uF 100UF/220UF/SMD C0603/SMD TO220/DIP/SU BEAD/SMD/0805 CB18 S-LF125M CB19 BEAD/SMD/0805 C0603/SMD CB20 0.1uF/NC 0.1uF/NC 1.2K CB21 0.1uF R0603/SMD C0603/SMD C0603/SMD R0603/SMD 220uF/16V 0.1uF 220uF/16V OCSET...
Page 13 AGND_AFE 1,2,4,5,6,7,8,9,10,11,12,13,14 AGND_AFE +30V_TUNER +30V_TUNER DV33_DM DV33_DM 1,2,4,5,6,7,8,9,10,11,12,13,14 +5V_TUNER +5V_TUNER CVBS2 CVBS2 CVBS3 CVBS3 IF_AGC S Y0 IF_AGC S Y0 FAT_IN+ FAT_IN+ FAT_IN- S Y1 FAT_IN- S Y1 TUNER_SCL1 TUNER_SCL1 TUNER_SDA1 S Y2 TUNER_SDA1 S Y2 TUNER INTERFACE AV / SV VIDEO INPUT CVBS0 CVBS0 MPX1...
Page 14 DVDD33 DV33_DM DV33_DM DV18_DM DV18_DM 1,2,3,5,6,7,8,9,10,11,12,13,14 GLOBAL SIGNAL RESERVE HEAT-SINK SPACE MT5112_IF_AGC IF_AGC CB67 R0603/SMD 47nF IF_AGC IF_AGC C0603/SMD DV33 FAT_IN+ CLOSE TO MT5112 FAT_IN+ MT5112AD_BD/TQFP100 FAT_IN- FAT_IN- TUNER_SCL1 TUNER_SCL1 4.7K TUNER_SDA1 TUNER_SDA1 R0603/SMD FAT_IN- CB68 ADVDD33_1 TUNER INTERFACE ADVDD33 10nF DV33 GPIO1(P1.1)
Page 15 OPWRSB OPWRSB DV33 ORESET# 1,2,4,6,7,11,12,13,14 DV33 ORESET# AV33 2,6,10,11 AV33 DV26_DDR OPCTRL0 2,6,8 DV26_DDR OPCTRL0 AV12 OPCTRL1 RESERVE HEAT-SINK SPACE AV12 OPCTRL1 OPCTRL2 OPCTRL2 DV33SB OPCTRL3 1,2,6,7,10,11,12,13 DV33SB OPCTRL3 OPCTRL4 1,13 OPCTRL4 DV26_DDR DV33 OPCTRL5 1,2,3,4,6,7,8,9,10,11,12,13,14 OPCTRL5 OPCTRL6 OPCTRL6 OPCTRL7 GLOBAL POWER OPCTRL7 OXTALI...
Page 16 DV33 1,2,4,5,7,11,12,13,14 DV33 AV33 2,10,11 AV33 DV33SB AV12 AV12 AV33 AV33 DV26_DDR 2,5,8 DV26_DDR AV15 AV15 AVCC_SRV AVCC_HDMIPLL AVCC_ADCPLL AVCC_VAD0 AVCC_AADC AV12 AV12 FB/70R/500mA/0603 150uH/1A/DIP15 CB109 CB110 CB111 BEAD/SMD/0603 CB112 CB113 CB114 L/IND/DIP/P10.0 CB115 CB116 DV33SB 1,2,5,7,10,11,12,13 DV33SB 0.1uF 0.1uF 0.1uF 4.7uF/6.3V 0.1uF...
Page 17 POWER ON RESET# CIRCUIT DV33 DV33SB POWER DOWN RESET# CIRCUIT CE35 10Kx4 R398 R397 220uF/16V R0603/SMD R0603/SMD RN0603/SMD 4.7K 4.7K/NC 100UF/220UF/SMD ORESET# CE36 2N3904 R0603/SMD R0603/SMD ORESET# +5VSB 1,2,8,9,11,13 +5VSB 1,2,10,11,12,13,14 +5VSB 2N3904 47uF/16v JTAG_RST# R0603/SMD SOT23/SMD 100UF/220UF/SMD CB181 JTAG_TDI DV33 1,2,4,5,6,11,12,13,14 DV33...
Page 18 DV13_DDR DV13_DDR DV26_DDR DV26_DDR DV26_DDR DV26_DDR RWE# 22x4 MEM_WE# MEM_WE# 75x4 RDQ0 47x4 MEM_DQ0 75x4 R CAS# MEM_CAS# MEM_CAS# RDQ1 MEM_DQ1 R RAS# MEM_RAS# MEM_RAS# RDQ2 MEM_DQ2 RCS# RN0603/SMD MEM_CS# MEM_CS# RN0603/SMD RDQ3 RN0603/SMD MEM_DQ3 RN0603/SMD MEM_DQ0 MEM_DQ15 MEM_DQ16 MEM_DQ31 DQ15 DQ15 R A3...
Page 19 DIP2/W /H/P2.54 2x1 W /HOUSING AGND_AFE 1,2,3,4,5,6,7,8,10,11,12,13,14 AGND_AFE AVR_IN RCA3X3 AV1_IN NEARLY YPBPR CONNECTOR NEARLY MT5372 AV9-8.4-13BA 0.1uf R159 0603/SMD R153 R147 SO Y0 CB286 0R/NC RA-V1 0R/NC R0603/SMD R0603/SMD C0603/SMD R0603/SMD Y0_IN R148 CB287 YPBPR0R_IN R149 YPBPR0R_IN1 PR1_IN R394 R0603/SMD R395 Y1_IN...
Page 20 DEL: D17~D27_D60_P5_U20_Q10_Q19_CB340 DEL; CB339_R203_R206_R207_U19 DV33 1,2,4,5,6,7,11,12,13,14 DV33 DEL: R36_RR82_R83_R208_R209_R210_R211_R212_R216_R217_R218_R390_R408 1,2,7,8,9,11,13 AV33 AV33 DV33SB 1,2,5,6,7,11,12,13 DV33SB AV33 2,6,11 AV33 AV15 AV15 R204 R205 AGND_HDMI 1,2,3,4,5,6,7,8,9,11,12,13,14 AGND_HDMI R0603/SMD R0603/SMD OSCL2 OSDA2 AGND_AFE 1,2,3,4,5,6,7,8,9,11,12,13,14 AGND_AFE PULL HIGH AV33 HDMI HDCP EEPROM 2006.12.16 OSDA2 OSDA2 OSCL2 OSCL2...
Page 21 CB361 VGAR_IN1 4.7uF/6.3V C0603/SMD R247 VGAR CB362 R0603/SMD VGAL_IN1 4.7uF/6.3V C0603/SMD R248 VGAL DV33SB CB363 R0603/SMD DVDD +5VSB YPBPR0R_IN1 3.3uF/10V C0603/SMD R249 YPBPR0R +12V 1,13 +12V CB364 R0603/SMD DV33SB FB/NC DVDD 5V_A R258 1,2,7,8,9,13 YPBPR0L_IN1 4.7uF/6.3V C0603/SMD R250 YPBPR0L FB/NC SCL14 SIF_SCL DV33...
Page 22 DV33 DV33 1,2,4,5,6,7,11,13,14 AMP_GND AMP_GND 1 CB405 4.7uF/6.3V C0603/SMD +5VSB CB410 CE55 +5VSB 1,2,7,10,11,13,14 R2S15102NP CB409 R299 1000uF/35v QFp20 4.7uF/6.3V R298 10K +24V 150K R297 C0603/SMD +24V AO1AUXL CB408 C0603/SMD R0603/SMD CAP7X16\5 R0603/SMD 4.7uF/6.3V LOUT PWM1 R0603/SMD C0603/SMD CB411 R300 CB412 DV33SB DV33SB...
Page 23 +5VSB 1,2,7,10,11,12,14 +5VSB +5VSB DV33SB DV33SB 1,2,5,6,7,10,11,12 DV33SB +12V RA-V2 +12V LVDS OUT(Include PDP and 32' LCD LVDS interface) 1,2,7,8,9,11 AGND_LVDS 1,2,3,4,5,6,7,8,9,10,11,12,14 AGND_LVDS R326 R327 CPUGO /PDPGO :INPUT TO PDP 1,2,3,4,5,6,7,8,9,10,11,12,14 10K/NC 10K/NC R324 R325 IRQ /READY :PDP INPUT TO MT8202 Option1 CPUGO R328...
Page 24 Option: Only for HDMI 3 +5VSB HDMI+5V_A NC/FPC/20P/0.5mm/H DDC5V_A CB439 0.1uF FHBAT54C +5VSB NS/EEPROM 24C04 R416 WP_A GPIO_8 DDC_SCL_A DDC_SDA_A R417 P WR5V 0R/NC RX_A_2+ RX2+ DV33H DV33 NC/FHBAT54 RX_A_2- RX2- RX_A_1+ RX1+ EDID EEPROM for HDMI 1 RX_A_1- FB/70R/500mA/0603 DV33H RX1- R441...
Page 25: Basic Operation Of Tft-Lcd
Basic operation of TFT-LCD 1. After turning on power switch, PSU board sends 5Vst-by Volt to Main IC MT5371 waiting for ON signals from Key Switch or Remote Receiver. 2. When the ON signal from Key Switch or Remote Receiver is detected, MT5371 will send ON Control signals to Power.
Page 26 Parts Position Panel Power Board Key Board Inverter Board Speaker Speaker IR Board Main Board 24／137...
Page 27: Main Ic Information
Main IC Specifications - MT537x Application Note - MT5112BD CE2836 24-bit, 192KHz. CODEC: 6 ch DAC, 5 Input Mux Stereo ADC - R2S15102NP Digital Power Amplifier R2S15102NP 25／137...
Page 28 26／137...
Page 29 27／137...
Page 30 28／137...
Page 31 29／137...
Page 32 30／137...
Page 33 31／137...
Page 34 32／137...
Page 35 33／137...
Page 36 34／137...
Page 37 35／137...
Page 38 36／137...
Page 39 37／137...
Page 40 38／137...
Page 41 39／137...
Page 42 40／137...
Page 43 41／137...
Page 44 42／137...
Page 45 43／137...
Page 46 44／137...
Page 47 45／137...
Page 48 46／137...
Page 49 47／137...
Page 50 48／137...
Page 51 49／137...
Page 52 50／137...
Page 53 51／137...
Page 54 52／137...
Page 55 53／137...
Page 56 54／137...
Page 57 55／137...
Page 58 56／137...
Page 59 57／137...
Page 60 58／137...
Page 61 59／137...
Page 62 60／137...
Page 63 61／137...
Page 64 62／137...
Page 65 CE2836 Microelectronics 24-bit, 192 KHz. CODEC: 6 Ch DAC, 5 Input Mux Stereo ADC FEATURES DESCRIPTION • Six Channel Audio DAC. The CE2836 is a mixed signal CMOS monolithic audio Codec. It contains six multi-bit sigma delta DAC and a - 104 dB SNR (A eighted).
Page 66 CE2836 CE2836 Performance DAC PERFORMANCE SPECIFICATIONS Item Spec. Audio Output Level 1 Vrms Audio Bandwidth 20Hz - 20 KHz +/- 0.1 dB SNR (A-weight) >104 dB THD + NOISE (A-weight, 0 dB input) < -82 dB Dynamic Range 94 dB Channel Separation <...
Page 67 CE2836 Description (continue) The DAC support conversion rate from 32K to 192KHz while the ADC from 32K to 96K. The CE2836 support 32, 24, 20 and 16-bit input data. It also support multiple sampling frequency data. Each DAC has its own individual volume control. XCK REQUIREMENT The CE2836 supports 32K, 44.1K, 48K, 96K and 192K sampled audio in DAC operations and32K, 44.1K, 48K and 96K sampled audio in ADC operations.
Page 68 CE2836 Table 2. Sampling ADC XCK Requiremen Rate DACDIV==0 DACDIV==1 XCK Freq 12.288 MHz 8.192 Mhz. 24.576 Mhz 16.384 Mhz 32 K SRC[1:0] [10], 384 fs (#), 256 fs [10], 768fs (#), 512 fs XCK Freq 16.934 Mhz 11.29 Mhz. 33.869 Mhz 22.579 Mhz 44.1K...
Page 69 CE2836 PIN ASSIGNMENT AOR1 DIN1 AOL1 DIN2 AOR2 DIN3 AOL2 DOUT AOR3 CE2836 AOL3 AVDD ADFS AGND ADBCK ADVCM ADXCK AGND ADVRF AGND AINR5 PIN DESCRIPTION Pin Name Pin # Type Description DIGITAL No connection. It can be tied to GND. Serial command port data line.
Page 70 CE2836 PIN DESCRIPTION (Continued) Pin Name Pin # Type Description DIN3 DAC Channel 3 serial audio data input. DOUT Serial ADC output +3.3V Digital power supply, 3.3 Volt. Digital ground ADFS ADC left/right channel clock pin. Please refer to Figure 1 PCM data format for its definition.
Page 71 CE2836 PIN DESCRIPTION (Continued) Pin Name Pin # Type Description ADVCM ADC comment mode voltage. It should be decoupled to AGND with a 22 uF in parallel with a 0.1 uF. Signal level is AVDD/2. AGND Analog ground pin. AVDD +3.3V DAC power supply.
Page 72 CE2836 DIGITAL AUDIO SERIAL INTERFACE There are two independent PCM serial ports, one for DAC and one for ADC. The DAC digital serial interface consists of 3 serial input pins, DIN1, DIN2, DIN3, one serial clock input/output pin, DABCK, and one left/right indicator input/output pin, DAFS.
Page 73 CE2836 Figure 1. Audio Serial Input Data Format 1/fs left Channel right channel DIN,DOUT Right Justified Input Format left Channel right channel DIN,DOUT Left Justified Input Format left Channel right channel DIN,DOUT I S Input Format DIN,DOUT data = 0 Channel 0 Channel 1 Last Channel...
Page 74 CE2836 DAC INFINITE ZERO DETECTION The CE2836 DAC has an Infinite Zero Detection circuit which detects zero in the Audio Serial Port that lasts for approximately 0.2 sec. By default, the zero detection circuit is on. DAC Digital Attenuation Each DAC contains an Digital Attenuation block. The attenuation values are hold in the Volume Control Registers. The Value 80H corresponds to Full Scale, 0dB.
Page 75 CE2836 ADC Noise Gate Noise Gate remove hissing noise during silence period. It is useful for recording noisy program. While Noise Gate is enabled the ADC digital output will be zeroed if the signal level below a predetermined value for about 0.5 seconds. The noise Gate is controlled by the same ADC PROC.
Page 76 CE2836 SERIAL PORT CONTROL REGISTER ASSIGNMENT There are 8 registers dedicated to the CE2836 for chip functional programming, The register addresses assignments are Address Default Register Register Function (decimal) Value CREG0[7:0] DAC Control REG0: Data input format, de-emphasis filter selection CREG1[7:0] DAC Control REG1: Input format and PLL output fre- quency selection...
Page 77 CE2836 CONTROL REGISTERS DESCRIPTION CREG0, DAC Control Register 0 ( =hex00, default=hexA0) ADRS CREG0[7:0] ADDR[3:0] BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Hex 00 FMT[1:0] NBIT[1:0] AMUTE DEEMP FSMPL[1:0] Default Value FMT[1:0] Digital Serial Bus Format Select 00: - Normal or Right Justified Format.
Page 78 CE2836 CREG1, DAC Control Register 1( =hex01, default=hex80) ADRS CREG1[7:0] ADDR[3:0] BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Hex 01 SRC[1:0] CKDIV2 MUTE56 MUTE34 MUTE12 AUTODET Default Value AUTODET Automatically detects the serial audio input data sampling rate clock frequency. 0: - do not use auto-detect 1: - automatically detects the serial audio input data sampling rate and clock frequency.
Page 79 CE2836 CREG2 - 7, DAC Volume Registers for channel 1 to 6, ( =hex02 - hex07, default=hex80) ADRS Volume Registers ADDR[3:0] BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Hex 02 Channel 1 left volume register, VOLREGL1[7:0] Hex 03 Channel 1 right volume register, VOLREGR1[7:0] Hex 04...
Page 80 CE2836 CREG 8, ADC Proc Register ( =hex08, default=hex82) ADRS CREG0[7:0] ADDR[3:0] BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Hex 08 NGATE NGTH[1:0] ALCHTM ALCEN ALC[2:0] Default Value NGATE: Noise Gate 0: - Noise Gate Disabled.
Page 81 CE2836 CREG9, ADC Control Register ( =hex09, default=hexA0) ADRS CREG0[7:0] ADDR[3:0] BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Hex 09 FMT[1:0] NBIT[1:0] SRC[1:0] CKDIV2 Default Value MT[1:0] Digital Serial Bus Format Select for ADC. 00: - Normal or Right Justified Format.
Page 82 CE2836 CREGA, Chip Control Register ( =hex0A, default=hex00) ADRS CREG1[7:0] ADDR[3:0] BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Hex 0A DAPWD ADMSTR ADPWD ZCBYP HPFBYP DAMSTR Default Value DAMSTR: Configure the DAC PCM Serial Port. 0: - Slave Mode 1: - Master Mode.
Page 83 CE2836 CREGB, ADC Input Enable ( =hex0B, default=hex01) ADRS CREG1[7:0] ADDR[3:0] BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Hex 0B AMUX[4:0] Default Value AMUX[4:0]: ADC Input Channel Enable. 00001: - AIN1 00010: - AIN2 00100: - AIN3 01000: - AIN4...
Page 84 CE2836 APPLICATION CONNECTION EXAMPLE: Analog 3.3 Volt 180 Ohm 100 uF 220 uF Digital AVDD DAVH 3.3 Volt DVDD DAVL 22 uF DGND CE2836 10 uF +3.3 Volt AOR1 680 ohm 10 uF AOL1 I C Serial 10 uF Interface AOR2 10 uF AOL2...
Page 85 CE2836 SUGGESTED ANALOG RECONSTRUCTION FILTER A second Sallen Key low pass reconstruction filter is recommend to remove the high frequency sigma delta modulator noise. The filter’s component values and characteristic are shown in the following figures. Sallen Key 2nd order LP filter 1000 pF 4.7 uF 2.7 K...
Page 86 CE2836 The ADC converters have a input buffer. The buffers have a equivalent input resistance of 20K ohm. To ensure the performance it is recommended that the applications should have a simple low pass filter to remove the high frequency noise. Recommended ADC input circuits 20 K...
Page 87 CE2836 TIMING DIAGRAM Figure 3. Audio Serial Interface Timing Requirement tbck tbck tbck DIN, DOUT Figure 4. Serial Command Port Write Timing Requirement tSCL tHIGH tLOW SDA, SCL tHD,dat tSU,dat tSU,sta tSU,stp tHD,sta stop start start stop 85／137...
Page 88 CE2836 ABSOLUTE MAXIMUM RATINGS Symbol Characteristics Units Power Supply Voltage (Measured to GND) -0.5 +7.0 Digital Input Applied Voltage GND-0.5 Digital Input Forced Current -100 Digital Output Applied Voltage GND-0.5 +0.5 Digital Output Forced Current -100 TDsc Digital Short Circuit Duration (single output high state to Vss) Analog Short Circuit Duration (single output to VSS1) infinite Ambient Operating Temperature Range...
Page 89 CE2836 ELECTRICAL CHARACTERISTICS Parameter Characteristics Units Power Supply AVDD Analog power supply voltage DVDD Digital power supply voltage Analog Current Digital Current Audio DAC Characteristics Full Scale Output Voltage to a 10K load 1.02 Vrms Reference voltage VDD/2 Digital Characteristics Digital Input Voltage, Logic HIGH, TTL Compatible Inputs.
Page 90 CE2836 Parameter Characteristics Units Audio FS Hold Time With Respect To Rising Edge of BCK Serial Command Port fSCL SCL Clock Frequency tSU,sta Start condition set up time tHD,sta Start condition hold time tSU,stp Stop condition set up time SCL Low time HIGH SCL High time SCL &...
Page 91 CE2836 PACKAGING INFORMATION (LQFP 48 PIN) Dimensions SYMBOLS SYMBOLS norm norm 1.68 9.0 BSC 0.05 0.15 7.0 BSC 1.35 1.45 0.45 0.65 0.75 0.17 0.22 0.27 0.63 1.03 0.09 0.20 1.00 REF 9.0 BSC 7.0 BSC LQFP 48 (7 X 7 mm) 89／137...
Page 92 90／137...
Page 93 91／137...
Page 94 92／137...
Page 95 93／137...
Page 96 94／137...
Page 97 95／137...
Page 98 96／137...
Page 99: Panel Information
Panel Information Product Description: T315XW02 TFT-LCD PANEL AUO Model Name: T315XW02 V7 Customer Part No/Project Name Customer Signature 97／137...
Page 100 1. General Description This specification applies to the 31.51 inch Color TFT-LCD Module T315XW02 V7. This LCD module has a TFT active matrix type liquid crystal panel 1366x768 pixels, and diagonal size of 31.51 inch. This module supports 1366x768 XGA-WIDE mode (Non-interlace).
Page 101 2. Absolute Maximum Ratings The following are maximum values which, if exceeded, may cause permanent damage to the unit. Item Symbol Unit Conditions Logic/LCD Drive Voltage -0.3 [Volt] Note 1 Input Voltage of Signal -0.3 5.25 [Volt] Note 1 BLU Input Voltage VDDB -0.3 [Volt]...
Page 102 3. Electrical Specification The T315XW02 V7 requires two power inputs. One is employed to power the LCD electronics and to drive the TFT array and liquid crystal. The second input power for the BLU, is to power inverter.. 3-1 Electrical Characteristics Parameter Values Unit...
Page 103 3. Measurement condition : Trush = 470 uS 4. VCIM = 1.2V VCIM 5. The performance of the Lamp in LCM, for example life time or brightness, is extremely influenced by the characteristics of the DC-AC Inverter. So all the parameters of an inverter should be carefully designed so as not to produce too much leakage current from high-voltage output of the inverter.
Page 104 3-2 Interface Connections LCD connector : S41B-PH-SM3-TB LVDS Transmitter: DS90C385 (NS). PIN No. Description PIN No. Description DC Power Supply LVDS Clock+ DC Power Supply Ground DC Power Supply RxIN3- DC Power Supply Rxin3+ DC Power Supply Ground Ground Ground Ground Reserved Ground...
Page 105 Block diagram for TFT-LCD module 1366 x 768 3-3 BACKLIGHT CONNECTOR PIN CONFIGURATION – 3-3.1Electrical specification ITEM SYMBOL CONDITION MIN TYP MAX UNIT Note Input Voltage VDDB=18V 4.75 Input Current (Stable Condition) VDDB=18V 77.4 85.5 93.6 Input Power (Stable Condition) VDDB=18V ON/OFF Control Voltage BLON...
Page 106 3-3.2 Input specification CN1: S14B-PH-SM3-TB(JST) Symbol Description VDDB (Main Power) DC input 18.0 VDC VDDB (Main Power) DC input 18.0 VDC VDDB (Main Power) DC input 18.0 VDC VDDB (Main Power) DC input 18.0 VDC VDDB (Main Power) DC input 18.0 VDC Ground Ground Ground...
Page 107 3-3.3. Backlight Diagram) Ground CCFL 1 To Back HOT 1(PINK) CCFL 2 Chassis HOT 2(PINK) CCFL 3 HOT 3(PINK) CCFL 4 HOT 4(PINK) CCFL 5 HOT 5(PINK) CCFL 6 HOT 6(PINK) CCFL 7 HOT 7(PINK) CCFL 8 HOT 8(PINK) CCFL 9 HOT 9(PINK) CCFL 10 HOT 10(PINK)
Page 108 3-4 Signal Timing Specifications This is the signal timing required at the input of the User connector. All of the interface signal timing should be satisfied with the following specifications for it ’s proper operation. 1 Timing Table DE only Mode Signal Item Symbol...
Page 109 3-5 Signal Timing Waveforms 107／137...
Page 110 3-6 Color Input Data Reference The brightness of each primary color (red, green and blue) is based on the 8 bit gray scale data input for the color; the higher the binary input, the brighter the color. The table below provides a reference for color versus data input.
Page 111 3-7 Power Sequence for LCD Module 3-7.1 Power Sequence for LCD Power Supply For LCD (+5V) t1 t2 t5 t6 Interface Signal Valid Data (LVDS data & CLK) Backlight on/off control signal (VBLON) Parameter Values Units Min. Typ. Max. 550 (Note 2) 0.47 Note 1: Apply the lamp voltage within the LCD operation range.
Page 112 4. Optical Specification Optical characteristics are determined after the unit has been ‘ON’ and stable for approximately 45 ℃ minutes in a dark environment at 25 . The values specified are at an approximate distance 50cm from the LCD surface at a viewing angle of Φ and θequal to 0°. Fig.1 1 presents additional information concerning the measurement equipment and method.
Page 113 Note: 1. Contrast Ratio (CR) is defined mathematically as: Surface Luminance of Contrast Ratio= Surface Luminance of off1 2. Surface luminance is luminance value at point 1 across the LCD surface 50cm from the surface with all pixels displaying white. From more information see FIG 2. When VDDB = 17.5V, IDDB = TBD L =Lon1 ,Where Lon1 is the luminance with all pixels displaying white at center 1 location.
Page 114 FIG.3 Response Time The response time is defined as the following figure and shall be measured by switching the input signal for “any level of gray(bright) “ and “any level of gray(dark)”. Any level of gray(Bright) Any level of gray(Dark) Any level of gray(Bright) L0,15,L31,….L255 L0,15,L31,….L255...
Page 115 5. Mechanical Characteristics The contents provide general mechanical characteristics for the model T315XW02 V7. In addition the figures in the next page are detailed mechanical drawing of the LCD. Horizontal 760.0mm Outline Dimension Vertical 450.0mm Depth 47.7mm Bezel Opening Horizontal 702.8mm Vertical 398.4mm...
Page 116 Front 114／137...
Page 117 Back 115／137...
Page 118 6. Reliability Environment test condition Test Item Condition High temperature storage test Ta=60℃ 300h judge Low temperature storage test Ta=-20℃ 300h judge High temperature operation test Ta=50℃ 80%RH 300h judge Low temperature operation test Ta=-5℃ 300h judge Wave form: Random Vibration level: 1.5G RMS Vibration test Bandwidth: 10-300Hz...
Page 119 7. International Standard 7-1. Safety (1) UL6500, Underwriters Laboratories, Inc. (AUO file number : E204356) Standard for Safety of Information Technology Equipment Including electrical Business Equipment. (2) CAN/CSA C22.2 No. 950-95 Third Edition, Canadian Standards Association, Jan. 28, 1995 Standard for Safety of Information Technology Equipment Including Electrical Business Equipment.
Page 120 8. Packing Panel label: Carton Label : 118／137...
Page 121 Carton : 878(L)mm *283(W)mm * 535(H)mm 119／137...
Page 122 Palletizing sequence: (1) By air : (4*1) *2 layers, one pallet put 8 boxes, total 32 pcs module. (2) By sea : HQ container (4*1) * 4 layers, one pallet put 16 boxes, total 64 pcs module. Specification Packing Item Remark Qty.
Page 123 9. PRECAUTIONS Please pay attention to the followings when you use this TFT LCD module. 9-1 MOUNTING PRECAUTIONS (1) You must mount a module using holes arranged in four corners or four sides. (2) You should consider the mounting structure so that uneven force (ex. Twisted stress) is not applied to module.
Page 124 9-3 ELECTROSTATIC DISCHARGE CONTROL Since a module is composed of electronic circuits, it is not strong to electrostatic discharge. Make certain that treatment persons are connected to ground through wrist band etc. And don ’t touch interface pin directly. 9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE Strong light exposure causes degradation of polarizer and color filter.
Page 125: Exploded View
123／137...
Page 126: Spare Part List
(T315XW02 V7) AV120V/60HZ USA BLACK/SILVER HORIZONTAL ATV/ 1> G510-L32AE03-01AKA ROHS CARTON BOX (H) AKAI 1.000000 Piece LCT32Z4ADP 2> G580-K00201-05BPA ROHS IB E FOR AKAI W/DVD K002 1.000000 Piece (OMNIPOTENCE) REMOTE CONTROL USA(CHENG YI) 3> G580-L32AE2A-01APA ROHS IB E FOR AKAI LCT32Z4ADP 1.000000 Piece...
Page 127 Spare part list for LCT32Z4ADP 18> G310-423850-07VA ROHS BAG LAMIFILM 1.000000 Piece 42"X38"X0.5MM AO LANG 19> G420-L32AE11-01SA ROHS L32AE MAIN BKT "L"(TOMEI) 1.000000 Piece 20> G420-L32AE12-01SA ROHS L32AE MAIN BKT"R"(TOMEI) 1.000000 Piece 21> G426-L37AD01-01SA ROHS AC LINE BRACKET(TOMEI) 1.000000 Piece 22>...
Page 128 Spare part list for LCT32Z4ADP 38> G579-L27AD09-01A ROHS CAUTION LABEL ENG AKAI 1.000000 Piece (QIAN SE) 39> G579-L32AD03-02A ROHS CLASS I LASER PRODUCT 1.000000 Piece LOGO(QIAN SE) 40> G579-L32AD09-02APA ROHS FCC STATEMENT LABEL 1.000000 Piece 77X20MM(QIAN SE) 41> G579-L32AE03-01APA ROHS POP LABEL ONE 1.000000...
Page 129 Spare part list for LCT32Z4ADP 57> GE4801-124001A ROHS SPEAKER 8 OHM 10W D3" 2.000000 Piece YD78-1(JUN LANG) 58> GE6203-31AD01 ROHS DISPLAY LCD31.5" AUO 1.000000 Piece (T315XW02 V7) 1366X768 530CD/ M2 1200:1 59> GE7301-010002A ROHS BATTERY AAA R03P1.5V <2> 2.000000 Piece (CHAO YANG) 60>...
Page 130: If You Forget Your V-Chip Password
If you forget your V-Chip Password:  Using the “U.S. Movie Ratings” item After entering the “Program Block” menu, press ▲ or ▼ button to highlight the “U.S. Movie Ratings” item. Press ► or Enter button to enter. Press ▲ or ▼ button to select an item, then press the Enter button to lock (display “ ”) or unlock (display “...
Page 131: Software Upgrade
Software Upgrade Process of update MT537X Preparing : Connect the Plasma/LCD TV and PC with the Board.Please find the 1． Software Upgrade details for connecting refering to the appendix at the end of this file. 2． Store the MtkTool into the PC . Downloading : Turn on AC power of the TV and then press the button “standby”...
Page 132 Choose the bit rate as 115200. 6． Select the update binary by pressing browse button. For example,the binary file name is 7． (this update firmware will be sent to your PDP42XX_V06_LGX3SMC_20061230.bin. side) 130／137...
Page 133 Press Upgrade button and start update process. 8． The update process is successful as the progress bar is 100%. After the update process is ok, 9． turn off power and wait indicator light is off. Turn on power and TV can work. Checking It is needed to check the version of the firmware for MT5371 which has been download into the TV .
Page 134 Press Menu button of the remote control，following input “5371”of the remote control and OSD menu for Factory Setting is appeared on the screen . Use the remote control and select the item of “Version Info” and then press “Enter” button of the remote control. It is easy to be found the version of the current firmware for MT5371 is as the following : “Model Name : PDP42Z5TA / Version:V17_LGX3SMC_20070119 ”...
Page 135 2.2 Connect RS232-VGA cable (#4) (RS232 side) to the board (#1) Connect RS232-VGA cable (#4) (VGA side) to the TV 2.3 Connect USB cable (#5) to the board (#1) 133／137...
Page 136 Connect another side of USB cable (#5) to PC 3. Cables Standard for Upgrade Board 134／137...
Page 137 135／137...
Page 138 136／137...
Page 139 137／137...
