- Page 1 SITE ALERT RF SITE EVACUATION ALARM USER MANUAL Models: SA02M, SA02S, SA02HD DO NOT DISCARD – ESSENTIAL INFORMATION IS CONTAINED IN THIS MANUAL Issue 3 15/01/2017...
- Page 2 WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE Purpose The SITE ALERT RF is designed to alert the occupants of a building or site in the event of an emergency such as a fire. The SITE ALERT RF is a self-contained, battery operated alarm unit which can be linked wirelessly with up to 30 other units, so that the operation of one unit will cause all other linked units to sound.
- Page 3 WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE Since heat rises to the highest point first, the detector should be securely mounted horizontally, as close as possible to the ceiling. Avoid mounting the detectors within 500mm of a wall, light fitting or other obstruction (e.g.
-
Page 4: Spare Parts
WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE Testing: The SITE ALERT RF system should be tested after installation and weekly thereafter to ensure correct operation. Push and hold the switch on any unit until the alarms sound. Reset the system by pushing the switch on any unit three times in succession. - Page 5 WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE DIP Switch Channel Address Diagram white squares indicate the switch positions. Channel Channel Channel Channel Channel Channel Channel Channel Typical Site Layouts = Subsidiary unit Master unit Multi-storey Block Open-Plan site Stair-core P a g e...
- Page 6 WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE DIP Switch Address Diagram white squares indicate the switch positions. Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address: Address:...
- Page 7 WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE HOW TO READ THE SIGNALS These two LEDs illuminate if the 9V (PP3) battery needs replacing The screw to open the unit is located here The LED in the switch pulses The LED in the regularly and switch flashes...
-
Page 8: Master Unit
WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE INSIDE THE SITE ALERT MASTER UNIT DIP Switch for addressing – the address for the Master unit should be the same as the highest number Subsidiary unit on the system (see p. 4) Connector blocks from D cell battery packs Screws to access battery pack –... - Page 9 WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE DETECTOR Screw to access battery pack and DIP switches 9V (PP3) Alkaline battery for the detector behind this flap Connector lead for the detector LED indicator light. The LED in the switch flashes intermittently (…...
-
Page 10: Troubleshooting
WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE Trouble Shooting 1) Site Alert Subsidiary not sounding when system activated It is likely that there is a problem with the location of Problem solved. Test the Site the Site Alert. Try Is the LED in the switch pulsing Alert by pressing the switch regularly? - Page 11 WIRELESS EVACUATION ALARM SITE ALERT RF INSTRUCTIONS FOR USE 3) Site Alert Master Switch LED is flashing One or more Subsidiary units are disconnected from the Is the LED pulsing regularly and Press the Master switch 3 times Master. Locate the Subsidary constantly? to reset the system Unit(s) which are pulsing and...
-
Page 12: Technical Data
IMPORTER: Howler UK, Inspiration Place, 1-4 Mitchell Road, Wimborne, Dorset, BH21 7SG Technical Assistance For further information and technical assistance contact: Howler UK T: +44 (0)330 7000 777 info@howleruk.com P a g e | 11...
