Summary of Contents for SCA PLU 632324
- Page 1 2000KG MAXIMUM VEHICLE LOAD ELECTRIC MOTORISED JOCKEY WHEEL PRODUCT MANUAL PLU 632324...
- Page 2 WARNING Always pay attention to the Electric Motorised Jockey Wheel. If the Electric Motorised Jockey Wheel abnormally warps / twists / bends, stop working immediately. Apply blocks to the wheels of the trailer, camper, boat or caravan when on an incline. The height of the Electric Motorised Jockey Wheel is able to be manually adjusted for easy hitching to the tow vehicle, Only move with the jockey wheel in lowered position.
- Page 3 SAFETY PRECAUTIONS 1. Please read this manual carefully before use. Keep manual in a safe place for future reference. 2. Please observe the surrounding area when operating the Electric Motorised Jockey Wheel. 3. Please disassemble the Electric Motorised Jockey Wheel when not in use. 4.
- Page 4 INSTALLATION OF THE ELECTRIC MOTORISED JOCKEY WHEEL Step 1: Connect the Upper Handlebar and the Lower Handlebar using the M8 Lock Bolt. Upper Handlebar M8 Lock Bolt Lower Handlebar Step 2: Attach the Assembled Handlebar to the main body using the M8 Lock Knob. Connect the Plug of the Handle Cable into the Control Box.
- Page 5 Step 3: Insert the Latch Pressure Plate into the Latch Fixed Plate, then attach the Latch Fixed Plate to the drawbar of vehicle by the using 2 x M12-120 Hex Bolts, 2 x M12 Flat Washers and 2 x M12 Nylon Lock Nuts. M12 Nylon Lock Nut Latch Pressure Plate M12 Flat Washer...
- Page 6 Step 5: Connect the Power Cable into the Power Socket on the Control Box. Connect the RED end to the Positive Terminal and connect the BLACK end to the Negative Terminal. Connect the 50 Amp Connector to the 12V DC Power Source. 50 Amp Connector Step 6: After all the installation are completed, press the ON/OFF Power Switch to power ON or OFF the Electric Motorised Jockey Wheel.
- Page 7 OPERATION GUIDE * Take time to assess your situation and plan your movement. * Mount the Electric Motorised Jockey Wheel to the drawbar of the vehicle. Locking pin and cover (not included) are recommended. * Assemble the Handlebar, connect the Power Cable into the Power Socket on the Control Box and connect the 50 Amp Connector of the Power Cable to the 12V DC Power Source.
- Page 8 SPECIFICATIONS: INPUT VOLTAGE: 12V DC PEAK WORKING CURRENT: 30 Amp NORMAL WORKING CURRENT: 15-27 Amp RECOMMENDED BATTERY SIZE: 24Ah MAXIMUM VEHICLE LOAD: 2,000kg (4,400lb) MAXIMUM JOCKEY WHEEL LOAD: 272kg MINIMUM HEIGHT: 680mm MAXIMUM HEIGHT: 970mm EXTENSION: 290mm GEAR RATIO: 326:1 OPERATION: Forward &...
