Abatement Technologies AIRE GUARDIAN AG8000 Instruction Manual

Hard-sided mobile containment unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
AIRE GUARDIAN
AG8000
Hard-sided Mobile Containment Unit
INSTRUCTION MANUAL
Covered by one of more of the following:
U.S. Patent No. 9,574,399
U.S. Patent No. 10,195,979
Canada Patent No. 2,895,016
Abatement Technologies
Abatement Technologies, Inc.
Abatement Technologies Limited
Georgia, USA
Ontario, Canada
+1 800 634 9091
+1 905 871 4720
www.abatement.com
AG8000_MN-FC
2023.12.06

Advertisement

Table of Contents
loading

Summary of Contents for Abatement Technologies AIRE GUARDIAN AG8000

  • Page 1 Covered by one of more of the following: U.S. Patent No. 9,574,399 U.S. Patent No. 10,195,979 Canada Patent No. 2,895,016 Abatement Technologies Abatement Technologies, Inc. Abatement Technologies Limited Georgia, USA Ontario, Canada +1 800 634 9091 +1 905 871 4720 www.abatement.com...

  • Page 2: Table Of Contents

    ©Abatement Technologies 2014 All Rights Reserved. No reproduction of any portion of this work is permitted without the express written permission of Abatement Technologies, Inc. READ AND SAVE THESE INSTRUCTIONS! Note: 1. Read and understand all operating instructions before using the AIRE GUARDIAN®...
  • Page 3 Inspect for damage before each use. Be sure all parts are present and in working order. Abatement Technologies strongly urges all users of the AIRE GUARDIAN® AG8000 to follow the most recent guidelines and/or standards published by the Occupational Safety and Health Administration, Environmental Protection Agency, and all other federal, state, provincial, local and employer regulations.

  • Page 4: General Information

    GENERAL INFORMATION The AIRE GUARDIAN® AG8000 is a mobile containment unit designed to capture and contain particulate during ceiling access work on ceiling heights up to 10'-2". Ceiling heights up to 12'-2" can be reached with the Extension (P/N: AG8000-EXT24, sold separately).

  • Page 5: Feature Identification

    Note: To reduce the risk being locked out of the mobile cart, Abatement Technologies suggests making a copy of the key and storing the master in a secure place.
  • Page 6 Header. The manual refers to this part as the header, which is raised and lowered using the provided hand crank or a power drill with clutch (not provided). Fabric enclosure. The fabric enclosure provides a flexible barrier that can accommodate the raising and lowering of the header.
  • Page 7 Pressure monitor mounting bracket. An Abatement Technologies’ RPM series pressure monitor can be installed inside the unit on this mounting bracket. This mounting bracket is included with all units (pressure monitor sold separately).

  • Page 8: Optional Accessories

    OPTIONAL ACCESSORIES An optional Side Access Panel can be purchased for wall access projects (P/N: AG8000-SA). Once installed, the Side Access Panel and the original clear polycarbonate panel are interchangeable. An optional Extension can be purchased to reach ceiling heights of 12'-2"...

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS BASIC OPERATION Raising and lowering the header The AG8000 uses a mechanical system to raise and lower the entire header at a single operating point which is located on the back of the unit. Since this is a mechanical system, electricity is not required for this operation.
  • Page 10 Warning: Pinch hazard! Do not use hands or fingers to unlock swivel casters or personal injuries such as severe pinching or cuts could result. Use work shoe to lock and unlock casters. Supplying Power to the Unit Power needs to be supplied to the unit in order for any of the electrical outlets to be functional, including the powering of the PAS750, if applicable.
  • Page 11 After the fabric top is unzipped and the ceiling tile is removed, the ladder can be extended above the ceiling, if necessary. Important: The ladder must be placed within the recesses in the floor to secure the feet of the ladder and to maintain the minimum 75⁰ angle required per OSHA requirements.
  • Page 12 Warning: Only use Abatement Technologies Portable Air Scrubber units with the variable speed control. Other units may not be compatible with the variable speed control and can result in fire, electrical shock, or personal injuries.
  • Page 13 Transporting and positioning the AG8000 underneath ceiling tiles Transport the AG8000 in the fully collapsed position and use the handles located at the corners of the unit to move the mobile containment unit. Position the mobile containment unit in Raise the header within a few inches of the the approximate location where ceiling ceiling, ensuring that the unit can still be access is required.
  • Page 14 Removing the fabric enclosure and top cover Both the top cover and the fabric enclosure are fastened to the mobile containment unit via hook and loop. To remove the top cover, simply separate the hook and loop along the perimeter of the top cover. To remove the fabric enclosure, detach the hook from the loop from each of the four telescoping members as shown above.

  • Page 15: Suggested Operating Procedure

    Warning: If using an air scrubber that is not manufactured by Abatement Technologies, do not use the remote variable speed control in conjunction with the air scrubber. Abatement Technologies air scrubbers have been tested to work with the variable speed control; other units may not be compatible.

  • Page 16: Care Of The Unit

    13. When finished with the ceiling work, replace the ceiling tile and close the top cover by zipping up the two zippers and engaging the hook and loop on the short edge near the ladder. 14. Undo the hook and loop straps that secured the top of the ladder and then fully collapse the ladder.
  • Page 17 Top fabric is included with unit and secured by hook Top fabric and loop (P/N: AG8000TOP-FR). Fabric fire retardant standard ASTM-E84/NFPA701 16' three-section fiberglass extension ladder with Ladder 300 lbs weight capacity (P/N: LADDER03). Ladder weight 40.5 lbs (18.4 kg) Exterior finish Anodized aluminum Mechanical system raises/lowers entire header with...

  • Page 18: Certification Of Mobile Containment Units

    (NRTL). LIMITED WARRANTY Abatement Technologies (AT) warrants that goods sold to the original user shall be free from defects in material and workmanship for a period of 1 year, except such as are commercially acceptable. AT does not warrant that the goods sold are merchantable or fit for any particular purpose.

  • Page 19: Extension Ladder Warning And Instruction Labels

    EXTENSION LADDER WARNING AND INSTRUCTION LABELS...

  • Page 20: Ag8000 Wiring Diagram

    AG8000 WIRING DIAGRAM Starting Serial Number: C800019402727...
