Summary of Contents for Sentera Controls GTEE1
- Page 1 GTEE1 ELECTRONIC TEMPERATURE CONTROLLER Mounting and operating instructions...
-
Page 2: Table Of Contents
ARTICLE CODES INTENDED AREA OF USE TECHNICAL DATA STANDARDS WIRING AND CONNECTIONS OPERATIONAL DIAGRAM MOUNTING INSTRUCTIONS IN STEPS OPERATING INSTRUCTIONS VERIFICATION OF INSTALLATION TRANSPORT AND STORAGE WARRANTY AND RESTRICTIONS MAINTENANCE MIW-GTEE1-XX-DT-EN-000 - 09 / 06 / 2023 2 - 8 www.sentera.eu... -
Page 3: Safety And Precautions
In case there are any questions that are not answered, please contact your technical support or consult a professional. MIW-GTEE1-XX-DT-EN-000 - 09 / 06 / 2023 3 - 8 www.sentera.eu... -
Page 4: Product Description
ELECTRONIC TEMPERATURE CONTROLLER PRODUCT DESCRIPTION The GTEE1 fan speed controller automatically regulates the speed of single phase voltage controllable motors (230 VAC / 50—60 Hz) according to the measured temperature values and controls a heater according to a temperature setpoint. -
Page 5: Wiring And Connections
9 - Vmax speed 180—230 VAC potentiometer OPERATIONAL DIAGRAM Operational diagrams speed Heater control Relay Fan speed control [VAC] Heater T [°C] T [°C] MIW-GTEE1-XX-DT-EN-000 - 09 / 06 / 2023 5 - 8 www.sentera.eu back to the table of contents... -
Page 6: Mounting Instructions In Steps
ELECTRONIC TEMPERATURE CONTROLLER MOUNTING INSTRUCTIONS IN STEPS Before you start mounting the GTEE1, read carefully “Safety and Precautions” and follow these steps. Choose a smooth solid surface for installation (a wall, panel, etc.). Follow these steps: Drill holes into the surface and secure the fastenings (hooks, wall plugs, etc.) into them. -
Page 7: Operating Instructions
External fuses need to be installed for protection: ■ For the heater: 16 A or according the heater power ■ For the controller: GTEE1-30-DT − 5 A / GTEE1-60-DT − 8 A VERIFICATION OF INSTALLATION ATTENTION Use only tools and equipment with non-conducting handles when working on electrical devices. -
Page 8: Transport And Storage
In case of heavy pollution, clean with a non-aggressive product. In these circumstances the unit should be disconnected from the supply. Pay attention that no fluids enter the unit. Only reconnect it to the supply when it is completely dry. MIW-GTEE1-XX-DT-EN-000 - 09 / 06 / 2023 8 - 8 www.sentera.eu...
