Installation Guide – DULUX
UL Type A LED Pin Base Lamps
LED High Output Pin Base, ballast compatible replacement lamps for use with electronic compact
fluorescent ballasts.
For warranty coverage, please register at www.ledvanceUS.com/warrantyregistration.
PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
This product complies with Part 18 of the FCC rules but may cause interference to radios, televisions, wireless
telephones, and remote controls. If interference occurs, move the product away from these devices or plug it into a
different outlet (or fixture). Do not install this product near maritime safety communications equipment or other
critical navigation or communication equipment operating between 0.15-30MHZ. For additional information, see
www.ledvanceUS.com/fccpart18
Note: These lamps are intended to replace 4-pin horizontal and vertical mounts and is a direct replacement for 32W &
42W lamps with GX24q bases (ANSI 32W/5.7T4/TR/GX24q-3 and 42W/6.1T4/TR/GX24q-4). They can also be used to
replace 26W, 32W and 42W CFL lamps with G24q and GX24q bases (check size before installation).
Parts/Components included:
• Installation Manual
• UL Type A - LED High Output, Plug & Play, Pin Base Lamp
Safety Precautions:
Important: Read all safety information and instructions carefully before installation. Retain for future reference.
UL Type A Installation (Plug & Play, Ballast Compatible)
To avoid personal injury and/or possible product damage, the following cautions must be followed:.
• CAUTION RISK OF FIRE – IF THE LAMP OR LUMINAIRE EXHIBITS UNDESIRABLE OPERATION
(BUZZING, FLICKERING, ETC), IMMEDIATELY TURN OFF POWER, REMOVE LAMP FROM
LUMINAIRE AND CONTACT MANUFACTURER.
•
DO NOT INSTALL THIS LAMP IN A PRE-HEAT LUMINAIRE.
•
THIS LAMP ONLY OPERATES ON ELECTRONIC BALLASTS. IF LAMP DOES NOT LIGHT WHEN THE
LUMINAIRE IS ENERGIZED, REMOVE LAMP FROM LUMINAIRE AND CONTACT LAMP
MANUFACTURER OR QUALIFIED ELECTRICIAN.
•
THIS DEVICE IS NOT INTENDED FOR USE WITH EMERGENCY EXITS.
4087563 / 20211103
®
SubstiTUBE
WARNING
®
