SERVICE MANUAL
DVD STEREO SYSTEM
SYSTEM
XR–DV826
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
NSX-DV826 (HR), (S/M Code No. 09-009-436-7T1).
• If requiring information about the CD mechanism, see Service Manual of
AZG-D ZBAPAM, (S/M Code No. 09-00A-350-6N2).
XR-DV826
BASIC TAPE MECHANISM : 2ZM–3MK2 PR7NM
BASIC DVD MECHANISM : AZG–D ZBAPAM
CD
SPEAKER
CASSEIVER
SX–NDV824
SX–R277
CX–NDV826
SX–C607
S/M Code No. 09-00A-436-7R1
REMOTE
CONTROLLER
RC–AAS03
HR
