Summary of Contents for Renew RPS1MH66BD Series
- Page 1 SOLAR PV MODULE Installation Manual B I F A C I A L M O D U L E R P S 1 M H 6 6 B D X X X R P S 1 M H 6 0 B D X X X R P S 2 M H 7 2 B D X X X M O N O F A C I A L M O D U L E R P S 1 M H 6 6 M B X X X...
-
Page 2: Table Of Contents
Table of contents Overview Laws and Regulations General Information a. Module Identification b. Wiring methodology c. Electrical Performance Safety d. Operation Safety e. Fire Safety Installation Conditions a. Installation safety b. Climatic condition c. Site and tilt angle selection Mechanical Installation a. -
Page 3: Overview
1. Overview Thank you for choosing ReNew PV modules. This manual briefly elaborates on the installation and safety use information for our modules. Since solar PV modules generate electricity when exposed to light, there are certain safety precautions that need to be regulated. -
Page 4: Wiring Methodology
Figure 1 : Module (with frame) 3.2. Wiring Methodology In case where a cable connection method is not included in the below table confirm the suitable cable length with any ReNew sales representative. Orientation Recommended wiring connection Portrait (1P) An extension cord is required at the last module... -
Page 5: Electrical Performance Safety
Landscape Required cable length will be mentioned in the product datasheet 3.3. Electrical Performance Safety The module’s solar cell will generate direct current (DC) when it is exposed to direct sunlight or other light sources, and direct contact with electricity live parts of the module, such as terminals, can result in injury or death, irrespective of whether or not the module and the other electrical equipment are connected. -
Page 6: Operation Safety
entraîneront également un arc électrique ou un choc électrique. Gardez les connecteurs secs et propres et assurez-vous qu'ils sont en bon état de fonctionnement. Broken glass either in front or rear can become an electrical safety hazard (may cause electric shock or fire). These modules cannot be repaired and should be removed and replaced immediately. - Page 7 Les piles de modules ne doivent pas contenir plus de 12 modules et les cadres doivent être alignés. ·Ne placez pas de charges excessives sur le module et ne tordez pas le cadre du module. Follow unpacking instructions when opening packaging carton. Suivez les instructions de déballage lors de l'ouverture du carton d'emballage.
-
Page 8: Fire Safety
Please refer to regional laws and regulations before installing modules and abide by the building's fire safety standards and requirements. According to the corresponding certification standards, the fire rating of ReNew modules is IEC Class C. Solar PV Module Installation Manual... -
Page 9: Installation Conditions
à la protection contre les incendies des bâtiments. Selon les normes de certification correspondantes, la résistance au feu du module photovoltaïque ReNew modules est la classe CEI C. Adopt proper module accessories such as fuse, circuit breaker and grounding connector according to local regulations. -
Page 10: Climatic Condition
Do not touch the junction box or the connectors with bare hands during installation or under sunlight, regardless if the module is connected to or disconnected from the system. Do not drill holes in the frame without authorization from ReNew, which may cause corrosion or other negative e ects to the module. - Page 11 Do not install modules at places that are possible to be flooded. Make sure that installed modules are not subjected to wind or snow pressure that exceeds the permissible maximum load limit. Do not install the PV module in a location where it would be immersed in water or continually exposed to water from a sprinkler or fountain etc.
-
Page 12: Mechanical Installation
ReNew suggests that the tilt angle of module installation be no less than 10°, so that dust accumulated on the module surface can be easily washed away by rainfall and the frequency of cleaning modules is also reduced. This also makes it easy for accumulated water to flow away, avoiding water marks on the glass due to prolonged ponding which might a ect the module appearance and performance. -
Page 13: Bolt Mountings
5.2. Bolt Mountings 4 inner mounting holes, M6 bolts 8 outer mounting holes, M8 bolts Bolt Washer Aluminum frame Bracket Washer Spring washer Figure 3: Mounting with bolt Mounting Hole Mounting Hole Bolt Size Bolt Size Tightening Torque Tightening Torque 14mm x 9mm 22-30 N*M 10mm x 7mm... - Page 14 Figure 4: Mounting hole position of bolt mounting for 2400Pa Figure 5: Mounting hole position of bolt mounting for 5400Pa Solar PV Module Installation Manual Page 13...
-
Page 15: Electrical Installation
60904-3) and BSTC (AM 1.5, T = 25 °C, Irradiance = 1000W/m + φ•135W/m Maximum allowable system voltage for ReNew PV modules is 1500V, Class for protection against electrical shock, in accordance with Clause 4 of IEC 61730-1:2016 is CLASS II. - Page 16 a) If modules are connected in series, the total voltage is equal to the sum of individual voltages. The recommended system voltage is as below, System voltage ≥ N*V [1+TcV * (Tmin-25)] Where: N - module numbers in series - Open circuit voltage (refer to product data sheet) - Temperature coe cient of open circuit voltage (refer to product datasheet) - Minimum ambient temperature b) If the modules are connected in parallel, the recommended number of modules in...
-
Page 17: Cables And Wiring
Make sure all connectors are fully locked. Only compatible connectors that can be mated, i.e. from the same vendor and model, shall be used. For approved connector make of each PV model as per IEC CDF, kindly connect with the ReNew technical team. Solar PV Module Installation Manual... -
Page 18: Bypass Diode
Notice, bypass diode is not the overcurrent protection device. If the diode is suspected to be defective, the installer or system maintenance supplier shall contact ReNew. Please do not try to open the module junction box on your own. -
Page 19: Operation And Maintenance
8. Operation and Maintenance It is the user’s responsibility to carry out regular inspection and maintenance of modules, especially during the period of limited warranty; and inform the supplier within two weeks when modules are found broken. 8.1. Cleaning Accumulation of dust or dirt on the module front face will result in a decreased energy output. Clean the module preferably once every year, (more frequently in dusty conditions), using a soft cloth (dry /damp). -
Page 20: Cleaning Precautions
8.2. Cleaning Precautions Do not use high pressure water. Do not use harmful chemicals. Do not use cold water when the module glass temperature is high. Do not use hot water to clean cold panel. Thermal shock from the di erence in temperature between the glass surface and water can result in fracturing or breaking of the glass. -
Page 21: Product Electrical Parameters
9. Product Electrical Parameters RPS1MH66MBxxx RPS1MH60MBxxx RPS2MH72MBxxx Type name or model no. (xxx= 650-670Wp in step (xxx= 580-600Wp in step (xxx= 535- 550Wp in step of 1) of 1) of 1) Nominal maximum output power at 650 - 670 580 - 600 535 - 550 STC [W] in steps of 1... -
Page 22: Disclaimer Of Liability
Kindly refer to respective product datasheets for the final electrical parameters 10. Disclaimer of liability The information contained in this manual is subject to change by ReNew without prior notice. ReNew gives no warranty of any kind whatsoever, either explicitly or implicitly, with respect to the information contained herein. - Page 23 F O R Q U E R I E S / M O R E I N F O R M A T I O N , P L E A S E C O N T A C T : ReNew Photovoltaics Private Limited...
