Airtel BMF-422 User Manual

4g hotspot
Hide thumbs
Table of Contents

Advertisement

Quick Links

Airtel 4G Hotspot
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BMF-422 and is the answer not in the manual?

Questions and answers

Related Manuals for Airtel BMF-422

Summary of Contents for Airtel BMF-422

  • Page 1 Airtel 4G Hotspot User Manual...

  • Page 2: Table Of Contents

    Contents Safety precautions ........................3 1.. Web.UI.configuration ......................4 1.1. Log.into.the.configuration.page ..................4 1.2 Icon description ........................4 Connection ..........................5 2.1 Connection information ....................5 2.2 Usage information ......................6 2.3 Signal & technology information ..................6 2.4 Battery information ......................6 2.5 Connected devices information..................6 3.. 4G.Data.Usage ........................6 3.1 Usage information ......................6 3.2 Usage setting ........................6 3.3 Clear history ........................6...

  • Page 3: Safety Precautions

    Safety precautions Read the safety precautions carefully to ensure the correct and safe use of your wireless device. Do not switch on your device when the device use is prohibited or when the device use may cause interference or danger. Follow the rules or regulations in hospitals and health care facilities.

  • Page 4: Web.ui.configuration

    1. Web.UI.configuration 1.1 Log.into.the.configuration.page Open the browser and enter this address http://192.168.1.1. The default login password is admin. After.login.password.input,.Airtel.configuration.webpage.will.be.launched. 1.2 Icon.description Icons on the webUI: Category Icon Display Signal strength From no signal to excellent Network status .Disconnect,. .Connected,. Roaming .Normal,.

  • Page 5: Connection

    Connection .Connected,. Disconnected status Usage Usage data Wi-Fi status Wi-Fi active with connected devices LED on the device: Icon Icon.display Network indicator LED is constant blue when connected to the 4G internet. LED blinks in blue when connected to the 3G internet. LED is rose red when connected to the 2G internet.

  • Page 6: Usage Information

    2.2 Usage.information A current usage time and data is displayed: Total time duration for current connection in HH:MM (e.g: 12Hrs 02 Mins). Total data for current connection in MB or GB. 2.3 Signal.&.technology.information Signal.icon: Shows the signal strength. The icon is grey when there is no service. Network.technology:.2G,.3G,.3G+,.4G.in.different.networks..Icon.is.empty.in.disconnected.

  • Page 7: Phonebook

    3.4 Phonebook 1. Local: Edit or delte contact info stored in device or SD Card. 2. SIM Card: Edit or delte contact info stored SIM Card. 3. Add: Add new phone number in local or SIM Card. 4. Message Click the SMS.area.to.enter.the.Message.interface,.the.following.items.are.included: +New.message: Create new SMS.
  • Page 8 Wi-Fi.Settings: Set the parameters related to Wi-Fi. •. 802.11.Mode:.Select.the.mode.used,.such.as.802.11.b/802.11.g/802.11.n. •. SSID:.This.is.the.name.of.the.Wi-Fi.network,.which.was.used.to.identify.your.Wi-Fi.network.. The length of the SSID should be 1-32 characters including “_”. •. SSID.Broadcast: The default setting is “Enable”. •. Wi-Fi. Channel: Different domains have different channels (Channel 1~11 in FCC (US)/IC (Canada);.Channel.1~13.in.ETSI.(Europe);.Channel.1~13.in.MKK.(Japan)).

  • Page 9: More

    •. DHCP Lease Time: Amount of time that a Wi-Fi enabled device can use its assigned IP address before it is required to renew the lease. MAC.Filter:.MAC.Filter.is.used.to.control.specific.MAC.addresses.to.access,.including.Disable,. Allow,.and.Deny. Note: The maximum allowed MAC list is 10. Port Forwarding: About: Display your device basic information. •.
  • Page 10 9. Q&A Q: Which.browser.does.the.device.support? A: It. supports. Windows. IE. 8. and. later,. Google. Chrome. (Win,. Mac),. Firefox. (Win,. Mac),. Opera.(Win,.Mac),.Safari.(Mac). Q: Which.OS.does.the.device.support? A: It.supports.Windows.XP/Vista/7/8/10,.Mac.OS.10.6.X.-.10.10.X. Q: How.to.connect.to.the.device? A: Open your wireless network connection list and select the relative SSID. Windows: Right-click Wireless network connection.on.the.task.bar,.and.select.View. Available Networks.
  • Page 11 z Check the device Status Display for error messages or information. z Refresh your network list on your computer. Windows: Click Refresh Network List on the left side of the Wireless Network Connection screen. If that does not work you can try the following: 1.

  • Page 12: Warning.and.precautions

    10. Warning.and.precautions Electronic.Device Turn off your device near high-precision electronic devices. The wireless device may affect the performance.of.these.devices..Such.devices.include.hearing.aids,.pacemakers,.fire.alarm.system,. automatic. gates,. and. other. automatic. devices. can. be. affected.. If. you. are. using. an. electronic. medical.device,.consult.the.device.manufacturer.to.confirm.whether.the.radio.wave.affects.the. operation of this device. Hospital Pay attention to the following points in hospitals or health care facilities: •.
  • Page 13 •. When.switched.on,.this.device.emits.electromagnetic.waves.that.can.interfere.with.the.vehicle’s. electronic.systems.such.as.ABS.anti-lock.brakes.or.airbags..To.ensure.that.there.is.no.problem,. do not place this device on top of the dashboard or within an airbag deployment area. •. Check with your car dealer or the car manufacturer to make sure that the dashboard is adequately shielded from this device RF energy. Conditions.of.Use •.
  • Page 14 Before.a.device.model.is.available.for.sale.to.the.public,.compliance.with.national.regulations.and. standards must be shown. The highest SAR value for this USB model when tested is 0.612 W/ kg for use close to the body. While.there.may.be.differences.between.the.SAR.levels.of.various.devices.and.at.various.positions,. they.all.meet.the.government.requirement.for.RF.exposure..For.body-worn.operation,.the.device. meets FCC RF exposure guidelines provided that it is used with a non-metallic accessory with the handset at least 15 mm from the body.
  • Page 15 headset or USB data cable. If you are using another accessory ensure that whatever product is used is free of any metal and that it positions the device at least 15 mm away from the body. Specific.Absorption.Rate.(ICNIRP) Proof of compliance with international standards (ICNIRP) or with European Directive 1999/5/EC (R&TTE) is required of all modem models before they can be put on the market.
  • Page 16 This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The entire copy of the Declaration of Conformity for your device can be obtained through our Website: www.alcatel-mobile.com Alcatel is a trademark of Alcatel-Lucent used under license by TCL Communication Ltd. All rights reserved ©...
